Assembly Instructions: 0839-M1L

IMPORTANT:

• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important

notes above. Shut off the power at the circuit breaker and

completely remove the old xture from the ceiling, including the

old mounting strap.

1. From the parts bag remove the mounting strap assembly. One end

of nipple (F) should be attached to mounting strap (A) with washer

and hex nuts (C & D) in place. The other end should have canopy

loop (H) and canopy loop collar (I) attached.

2. Attach mounting strap (A) to the junction box using mounting

screws (B) and a screwdriver. Tighten securely.

3. Unscrew canopy loop collar (I) from canopy loop (H) and slide

down. Pass canopy (G) over the mounted canopy loop (H) to test

thextureheight.Approximatelyhalfoftheexteriorthreadsofthe

canopy loop (H) should be exposed, and the canopy loop collar

shouldtsnuglyontothecanopyloop.Ifneedbe,removecanopy

(G) and adjust the height of nipple (F) and canopy loop (H) until the

desired height is reached.

ASSEMBLING THE FIXTURE

4. Measure to determine the correct length of chain needed for

proper hanging height. If necessary, use a pair of pliers to open and

remove any excess chain. Attach one chain connector (K) to each

endofthechain(J).Passthexturewiresthroughtoploop(L).Pull

the wires until taut.

5. Attach one end of the chain with chain connector to the top loop

(L).Feedthexturewiresupthroughthechain(everythreelinksor

so), pulling the wires until taut. Use the remaining free chain end with

chain connector to attach chain to canopy loop (H). Close the chain

connector on both ends to secure.

6. Slide canopy loop collar (H) and canopy (G) down onto the chain/

wires. Pull the wires until taut. Trim the wires to the desired length

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe

down the xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, please

contact the place of purchase.

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

Hot Neutral Ground

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

CONNECTING THE WIRES

7.Haveanassistantsupporttheweightofthexturewhilecompletingthewiring.Cutawayexcesswire.Attachthexture’swiresto

thehousewireswhichwerepulledearlierfromthejunctionboxthroughthemountingstrap(B).Connectblacktoblack(orsmooth);

whitetowhite(orribbed);groundtoground(greenorcopper).Twisttheendsofthewirepairstogether,andthentwistonawire

connector.Makesurealltwistsareinthesamedirection.Ifthereisnogroundwire(greenorcopper)comingfromthejunction

box,locategroundscrew(E)onthemountingstrapandwrapthexture’sgroundwirearoundthegreengroundscrew(E).Usea

screwdrivertosecuregroundscrew(E)ontothemountingbracket.Tuckallwiresneatlyintothejunctionbox.

FINISHING THE INSTALLATION

8. Push canopy (G) up to the ceiling and slide canopy loop collar (I) up beneath the canopy. Tightly thread canopy loop collar (I) onto

canopy loop (H) to secure canopy (G) in place.

9.Threadthetoploop(L)ontothenipple(M)ofxturebody(N).Hand-tightenuntilsnug.

Installalightbulb(notincluded)inaccordancewiththexture’sspecications.Donotexceedmaximumrecommendedwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
