Assembly Instructions: (Payton)1157-4P/6P

IMPORTANT:

• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture. Dry with a lint-free or microber cloth.

For Customer Service, contact

the place of purchase

Smooth / Black /

Transparent (L)

Black (Hot)

Ribbed / White /

Transparent (N)

Bare Copper / Transparent with

Green Interior / Green

White (Neutral)

Green

(Ground)

PREPARING FOR INSTALLATION

Carefully remove all of the contents from the carton. See the important notes above.

Shutoffthepoweratthecircuitbreakerandcompletelyremovetheoldxturefromthe

ceiling, including the old mounting strap.

From the parts bag remove the mounting strap assembly. One end of nipple (F) should

beattachedtomountingstrap(A)withhexnuts(C,D)inplace.Theotherendshould

have canopy loop (H) attached. Match the threaded holes of mounting strap (A) to the

spacingoftheholesonthejunctionbox.Attachmountingstrap(A)tothejunctionbox

using mounting screws (B) and a screwdriver. Tighten securely. Unscrew canopy loop

collar (I) from canopy loop (H). Pass canopy (G) over the mounted canopy loop to test

theheight.Approximatelyhalfofthecanopyloop’sexteriorthreadsshouldbeexposed,

andthecanopyloopcollarshouldtsnuglyontothecanopyloop.Removecanopy

(G) and adjust the height of nipple (F) and canopy loop (H) until the desired height is

reached.

ASSEMBLING THE FIXTURE

Rod(P)andtopassembly(Q),withtoploop(L)areonthexture’swires.Pullthewires

untiltaut.Screwrod(P)intothecenterofxturebody(O)andthentoploop(L)onto

the threads of top assembly (Q). By measuring, determine the correct number of chain

links needed for proper hanging height. If necessary, use a pair of pliers to open and

removeanyexcesschain.Attachonechainconnector(K)toeachendofchain(J).Use

onechainconnector(K)toattachchain(J)totoploop(L)andclosethechainconnector.

Feedthexture’swiresupthroughthechain(everythreelinksorso),pullingthewires

until taut. Slide canopy loop collar (H) and canopy (G) onto the chain and wires. Use the

freechainconnector(K)toattachchain(J)tocanopyloop(H).

CONNECTING THE WIRES

Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutaway

excesswire.Threadthexture’swiresthroughcanopyloopandnipple.Attachthe

xture’swirestothepowersupplywiresfromthejunctionbox.Connectblackto

smooth/black/transparent (L) wire; white to ribbed/white/transparent (N) wire; ground to

ground (green or copper). Twist the ends of the wire pairs together, and then twist on a

wire connector. Make sure all twists are in the same direction. If there is no ground wire

(greenorcopper)fromthejunctionbox,locategroundscrew(E)onmountingstrap(A)

andwrapthexturegroundwirearoundthegreengroundscrew(E).Useascrewdriver

to secure ground screw (E) onto the mounting bracket/mounting strap. Tuck all wires.

FINISHING THE INSTALLATION

Push canopy (G) up to the ceiling and slide canopy loop collar (I) up beneath the canopy. Tightly thread canopy loop collar (I) onto canopy

loop (H) to secure canopy (G) in place.

Notes: Glass edges may be sharp. Wear gloves for installation to avoid injury. Have an assistant help throughout this process.

Use deco nuts (S) to attach bottom rim (T) to metal frame (N). Carefully slide glass panels (U) into metal frame (N). Lower the other top

rim (T) over metal frame (N). Place iron bar (R) against the glass and secure in place with decorative screws (V). If the glass can not be

successfullyplacedintotheframework,pleaseadjustironbar(R).Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

Installbulbs(notincluded)inaccordancewiththexture’sspecications.Donotexceedthemaximumwattage.Withthehelpofyour

assistant, carefully raise the glass and metal cage assembly up to top assembly (Q) and attach the metal cage assembly to the top

assembly using decorative nuts (M).

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
