Canopy 1ea Mounting

Screws 2ea Top loop 1ea

Chain 6ft Threaded ring 1ea Wire connectors 2ea

Chain connector 2ea Canopy loop 1ea Nipple 1ea

Mounting Strap 1ea Hex Nut 1ea Finial 1ea

Part Needed Quantity

Reason why ( missing, scratched, broken glass, bent, bad nish)

Comments

F A IIXTURE SSEMBLY NSTRUCTIONS

For Customer Service, contact the place of purchase to arrange for replacement parts.

NOTE: INSTALL THE GLASS ASSEMBLY

AFTER THE FIXTURE IS HUNG.

1. Feed the xture wires through the Top loop (J)

and pull the wires until taut.

2.Then screw the Top Loop (J) to the top of Frame

(K) until tight.

8106-9 CDB

Read and review installation instruction sheet before

assembling the xture.

Fig 1

Notice: Please review the parts listing and check for all parts before assembling the xture. If any parts are

missing or damaged, please note onthis sheet and contact the place of purchase to arrange for

replacement parts.

PARTS LIST Company Name:_______________________Co. Account #:_____________

to be lled out by retailer

PARTS & ASSEMBLY SHEET

This xture assembled PO:__________ Date: ________

Fixture Name: Torbellino 8106-9 CDB

CHAIN

For Customer Service, contact the place of purchase to arrange for replacement parts.

8. By measuring determine correct number of links

needed for proper hanging height. Use a pair of

pliers to open one link of the Chain (C2) then

remove the excess Chain (C2) and discard it.

9. Use one chain connector(E2) to attach one end

of the chain to the Top loop (D2) and close the

chain connector.

10. Feed the xture wires through the Chain (every

three links) and pull the wires until taut.

11. Slip Canopy loop collar (B2) over the chain,

then do the same with the canopy (F2).

12. When ready to complete the installation Use the

other chain connector and attach the other end of

the chain to the canopy loop (A2) and close the

chain connector.

13. Make sure the weight of the chandelier is

supported by the chain-not the electrical wire.

* You may now install the xture.

Fig 3

3. Unscrew the Deco screws (L,M) from the

Frame (K) and save.

4. Several of the arms are already attached to the

Frame. Gently spread the remaining arms until

evenly spaced.

5. Align the hole in lower side of Frame arm (K) with

hole Frame (K). Secure in place with the Deco

screw (M).

6. Repeat with remaining arms both upper and

lower, secure with the Deco screws (L, M).

* NOTE: The Finial can be scratched or broken if

the full weight of the xture is placed on it. To avoid

damage attach Finial after hanging the xture.

7. Attach Finial (O) to the base of xture Frame (K)

by threading the Finial (O) onto the threaded rod

(N) until tight.

Fig 2

PARTS & ASSEMBLY SHEET

Fixture Name: Torbellino 8106-9 CDB

Note: Complete these remaining steps after the

xture is hung.

14. Place the Glass Shade (Q) over the Threaded

Socket (P),place the Socket washer (R) over the

threaded socket (P) then secure the Glass Shade

(Q) by threading by the Socket Ring (S) until tight.

15. Install the light bulbs in accordance with the

xture's specications.

(DO NOT EXCEED THE MAXIMUM WATTAGE RATING)

Fig 4
