Side 1/10

Operating Instructions

METRALINE RCDCHECK

RCD Test Instrument 3-349-694-03

4/3.21

2 Gossen Metrawatt GmbH

Contents Page

1 Introduction ...................................................................... 2

1.1 Scope of Delivery ...........................................................................2

1.2 Optional accessories ......................................................................2

1.3 Safety Precautions .........................................................................2

1.4 Applications ..................................................................................3

1.5 Applicable Standards .....................................................................3

1.6 Environment ..................................................................................3

2 Device Description ........................................................... 3

2.1 Housing ........................................................................................3

2.2 Operation and OLED Display ...........................................................4

2.3 Initial Start-Up ...............................................................................4

3 Performing Measurements .............................................. 4

3.1 Switching the Instrument On and Off ...............................................4

3.2 Instructions and Principles with Validity for

All Measurements ..........................................................................4

3.3 Adjustable Parameters ...................................................................5

3.4 Measuring the Individual Parameters of an RCD ...............................6

3.4.1 Touch Voltage Uc ...........................................................................6

3.4.2 Time to Trip – TIME .......................................................................6

3.4.3 Tripping Current I ..........................................................................7

3.5 Further Device Functions ................................................................7

3.6 Device Reset Function ....................................................................7

4 Technical Data ................................................................. 8

4.1 Measuring Functions ......................................................................8

4.2 General Data .................................................................................8

5 Maintenance .................................................................... 9

5.1 Device Power Supply .....................................................................9

5.1.1 Inserting and Replacing the Batteries ..............................................9

5.1.2 Recharging the Batteries ................................................................9

5.1.3 Fuse Replacement .........................................................................9

5.2 Cleaning .......................................................................................9

5.3 Recalibration ...............................................................................10

6 Repair and Replacement Parts Service,

Calibration Center and Rental

Instrument Service ......................................................... 10

7 Product Support ............................................................. 10

1 Introduction

1.1 Scope of Delivery

1 Test instrument with mobile test probe

4 Batteries (AAA)

1 Pouch

1 Condensed operating instructions

1 CD ROM with operating instructions in available languages

1 Factory calibration certificate

1.2 Optional accessories

4 ea. rechargeable AAA NiMH batteries (Z507B)

1 battery charger (Z507A)

1.3 Safety Precautions

Read the operating instructions thoroughly and carefully before

using your instrument. Follow all instructions contained therein.

Make sure that the operating instructions are available to all users

of the instrument.

Meanings of Symbols on the Instrument

This device is equipped with double

or reinforced insulation.

Danger of injury due to electrical current,

warning regarding dangerous electrical voltage

Warning concerning a source of danger

(attention, observe documentation!)

Indicates European Conformity: This instrument fulfills all

requirements of applicable European directives.

Before using the instrument, it must be assured that it is safe. Do

not use if:

• Visible damage is apparent

• The battery compartment lid is missing

• The device has been stored under unfavorable conditions for

a lengthy period of time

• The device has been handled impermissibly, e.g. has been

dropped from a height of 1 meter or more

• The test instrument does not function as described in these

operating instructions (if this is the case, we recommend

resetting the device as described in section 3.6 on page 7)

CAUTION

• Do not touch electrically conductive parts, test probes etc.

when the device is switched on and voltage might still be con-

ducted by a test probe – DANGER OF INJURY!

• Only use test probes which are included with the instrument

or are available as accessories.

• The device must be switched off and no voltage may be

applied when exchanging accessories.

• It is absolutely essential to adhere to all safety precautions,

regulations and standards when performing measurements.

• No keys may be pressed when connecting the instrument to a

device under test.

• The test instrument may not be subjected to the influence of

aggressive substances, gases, vapors, liquids or dust.

• The test instrument may only be used under the conditions

listed in the technical data in section 4 on page 8.

• If the device is moved from a colder to a warmer room, con-

densation may occur, in which case a brief period of acclima-

tization is advisable.

• We recommend removing the batteries during lengths periods

of storage.

• Two relatively strong magnets are integrated into the test

instrument. Avoid close proximity to magnetically sensitive

objects such as watches, credit cards and the like.

• The illustrations in these operating instructions are drawings

and may therefore deviate from reality.
