1) Push the power button for 2 seconds to turn the unit on.

(Safe Mode is the default.)

2) Set the timer you want. 5, 10, 15 minutes.

Default time is 5 minutes.

3) Place Vray over the area you wish to sanitize.

(It will beep every 10 seconds during use.)

4) After using, push the power button for approximately

2 seconds to turn off.

Safe Mode ON

1) Push the power button for 2 seconds to turn on.

2) Push the safety button for 2 seconds to deactivate

the safe mode. The light on the button turns off.

3) Place Vray over the area you wish to sanitize.

(It will beep every 10 seconds during use.)

4) You can sanitize bulky items (desks, chairs, rugs, etc.)

5) When you are done, push the safety button to

activate the safe mode or push the power button

more than 2 seconds to turn off.

Safe Mode OFF

1st Alarm of Low Battery:

‘Lo (Low battery)’ appears

on the LED monitor and the power button turns red.

2nd Alarm of Low Battery:

If the battery is running

down after 1st alarm, the ‘Lo’ and red color on power

button will blink.

Charging:

Beep to let you know the beginning of

charging and the power button is red during charging.

Charge Completion:

Beep to let you know the finish

and the light of power button is turned off

Charging the Battery

Instruction Manual

5. How to use

When using Vray in portable mode, the most effective distance to use is 4-8 inches from the item.

4. Safe Mode Safety Sensor

A safety sensor has been added to this unit to detect the proper angle of

the Vray, and protect from accidental exposure of UV-C light. Equipped

with this safety sensor, Vray can detect when there is danger of light being

exposed towards the user. Safe mode is the default status when Vray is

turned on. In safe mode, Vray will automatically turn off when tilted 30

degrees in either direction. For the user's convenience, safe mode can

also be turned off with the click of a sensor button for 2 seconds. When

safe mode is off, the light will stay on, even if Vray is held at an angle.

30˚

3. Specifications

Model Number: HYGENX-VRAY

Safety Features: Safety sensor, Timer, Overcharge

Protection Circuit, Over Discharge Protection Circuit,

Overcurrent protection circuit, Anti-Shatter UV-C Lamp:

Anti-shatter coating prevents glass from shattering and

keeps pieces of glass inside the coated lamp tube.

Size: 19"W x 2.7"L x 4.3"H

Weight: 1.11 lbs.

Lamp: 8W UV-C Lamp, at 253.7 Wavelength

Battery: Li-Ion Rechargeable

Adapter: 100-240V, 50-60Hz, 12V 2.0A

Charging Time: Approx. 2 hours

Operation Time: Approx. 3 hours

Please fully charge the unit before first usage.

HamiltonBuhl's Vray is a cordless UV-C Sanitizer that is safe, convenient, easy to use and keeps

you and your family healthier by killing the bacterium that cause diseases. Vray sanitizes 99.9%

of common bacteria such as Escherichia Coli (E-Coli), Colon Bacillus, Klebsiella Pneumoniae, Pseudomonas,

Staphylococcus Aureus, and Staphylococcus and (MRSA) in just 5 seconds. It can sanitize against the

Influenza A virus, Adenovirus, Human Rhinovirus, and Human Coronavirus. Vray also detects direct

exposure to UV-C radiation and prevents any possible exposure by shutting itself off automatically.

Vray is the safe and easy way to sanitize items, such as: pens/pencils, scissors, desk/chair surfaces,

books, staplers, laptop PCs, iPad, smartphones, rugs, toys, and more. Vray is convenient, cordless, portable,

hands-free, lightweight and rechargeable.

1. Product

Effective Design

High Quality

Safe and Easy to Use

2. Components

LED

Monitor

Safety

Button

UV-C Lamp

Protection Cover

Power

Button

Adapter

1) If Vray does not turn on:

- Lightly press the power button and hold for 2 seconds or

more. This is part of a safety feature for children.

- Fully charge the unit and try again.

2) If the lamp doesn't turn on:

- Please charge the unit.

- As a safety feature, the lamp will automatically turn off

when the main body is tilted more than 30°.

- Try placing the unit on the floor, and try again.

3) If you hear a noise inside when you shake Vray:

- This sound is normal. The safety sensor makes that sound.

- There is an amalgam piece inside the lamp. This is normal.

7. FAQ

1) Loosen the screws of the bracket both sides of the

protection cover and lift it up by using both hands.

2) Turn the lamp 90 to the right and remove. °

Insert a new lamp, and then turn 90 to the left.°

3) Cover the protection cover and tighten the screws.

4) We highly recommend you use the Anti-shatter

8W UV-C Lamp provided by HamiltonBuhl/

PRIMETECH. Using another lamp may cause

breakdown.

6. How to Change the UV Lamp

Bracket

Protection cover

UV-C Lamp

• Do not expose directly onto any person or animal.

• Do not expose directly to eyes or skin. Overexposure of UVC induces

skin erythema and keratoconjunctivitis.

• Keep out of reach of children.

• When using Vray in overhead areas such as on tables, shelves, etc.,

please make sure children are not within UV-C ray range.

• Avoid direct sunlight and store indoors.

• Vray is not a waterproof product. If it is exposed to humidity or gets

wet, it may cause the unit to break down. Do not use with wet hands.

• When cleaning this product, Do NOT use water or chemicals.

Please wipe gently with a soft cloth.

• Please charge the unit regularly, when not in use.

• Do not disassemble the Vray except to replace the UV lamp, when

needed. Dissassembling the unit further will void the warranty.

The most focused sanitize area is approximately 12" center to center.

Use Vray at intervals of 12" (recommended).

www.HamiltonBuhI.com

80 Little Falls Road

Fairfield, NJ 07004

Made in Korea

Printed in Korea for HamiltonBuhI

One Year Limited Warranty.

Due to ongoing improvements, actual product may have slight variations from the product described in this manual.

12"12"

For more instructions and test results, visit https://www.hamiltonbuhl.com/content/Vray-App-Instructions.pdf
