Side 1/8



PT‐A‐604_INST_2‐19pg.1





TOOLSREQUIRED:

PoweredDrills(3/8”&1/2”)WireCrimpingTool 4½”HoleSaworJigSawStandard

SocketSetDrillbitSet  RatchetingWrench

WireStrippingTool

HARDWAREandpartsforPT‐A‐601/602/603/604

QTY DESCRIPTIONPART#

2/4/6/6 #10x1/2”FlatheadmachinescrewGSM33380

4/8/12/12 #10KepsnutGSM30028

3/6/9/9 #10x3/4”FlatheadsheetmetalscrewGSM33151

2/4/6/6 10‐32x1/2"MachinescrewGSM34447

OnlyonPT‐A‐604(forexteriorcamerabracketmounting)

QTY  DESCRIPTIONPART#

2  #10X3/4"PanHeadSheetmetalscrewSS GSM34170 

MAINVIDEOSYSTEMCOMPONENTS

QTY   DESCRIPTIONPART#

1  PanaviseMonitormountbracket  GSM70040

1  Voyager7”LCDMonitorwithtwo(2)harnesses GSM70003

1/2/3/3  6”Round1/4”LexancoverPRM97353

1/2/3/3  CameramountingbracketKKM007933

2/2/3/4  Voyager25ft.CameracableGSM70021

1/2/3/4  Interior/ExteriorColorCameraGSM70033

PT‐A‐607ClearPolycarbonateguard/Cameramountkit(Optiononly

usedforCustomerSuppliedCameraSystem)

NotneededforPT‐A‐601,602,603and604kitsbecausepartsarealreadyincluded.

QTY  DESCRIPTIONPART#

3  CameramountingbracketKKM007933

3  ClearPolycarbonatedomecovers  PRM97353

12  10‐32KepsnutGSM30028

9  #10x3/4”Flatheadsheetmetalscrew  GSM33151

6  10‐32x1/2"Flatheadsheetmetalscrew GSM33380

2  #10x3/4"SheetmetalscrewGSM34170

6  10‐32x3/8”

MachinescrewGSM34447

PT‐A‐608DigitalVideoRecorderkit(Optional)

QTY  DESCRIPTIONPART#

1  DieselBossDVRwithstandardpartsandcables GSM70004

1  Samsung860EVO2.5InchSATAIIIInternalSSD1TB GSM70005(installedinDVR)

4  4‐PINFemaletoRCAFemaleadaptorcable GSM70025

1  VoyagerMaletoRCAFemaleadaptorcable GSM70026

1  4‐PINMaletoRCA

Maleadaptorcable  GSM70029

4  VoyagerFemaletoRCAMaleadaptorcable GSM70034

4  Voyager“Y”DualMaletoSingleFemaleSplittercable GSM70035

1  EquipmentbracketforHavisConsole  C‐EB30‐DB4‐1P

INSTALLATIONINSTRUCTIONS

PT‐A‐601,602,603,604,607and608

PRISONERTRANSPORTVIDEOSYSTEMEQUIPMENT

**CamerasystemsmustbeusedwithrearcompartmentdomelightsON.**



PT‐A‐604_INST_2‐19pg.2





Wiresystemaccordingtomanufacture

recommendationsincludedwithin

videosystemcomponentboxesandthe

wirediagramsuppliedinthis

instruction

Markholesontheceilingandpre‐

drillwith1/8”drillbit.Reposition

cameraassemblyandmountusing

#10x3/4”Flatheadsheetmetal

screws.

Plugcameracableintooneofthe

cameraassemblies.Turnonsystem.

Positionthecameratoobtainoptimal

visibilitywithinthecompartment.

Youwillneedtwopeopleforthisstep.

PT‐A‐604External

Camera

Compartment

SideDoorFrame

Determinemountinglocationfor

cameraandmarkhole.Besuretomake

surethepolycarbonatedomecoverfits

properlybeforedrilling4½”hole.Take

cautionnottodrillintoanywires.

Repeatstepsfor

remainingcameras.

Onceholeisdrilled,deburrthe

metal.Reachthroughtheopening

andpullthecameracablethrough

theopening.

AttachcameratotheCamera

mountingbracketusingtwo(2)10‐32x

1/2"boltsand10‐32kepsnuts.Attach

thebrackettothecoverwithtwo(2)

10‐32flatheadscrewsandke

snuts.

Viewofthirdcompartmentsetup.

Mountexternalcameraindesired

location.Ifbeingusedforviewingwhen

backingupinstallcameraonbacksideof

roofasclosetocenteraspossible.The

“U”shapebracketincludedwithcamera

shouldworkinmostapplications.

Note:CamerascomestandardwithnightvisionLEDlighting.

HoweverthenightvisionLEDdoesnotworkcorrectlybecause

ofreflectionoffoftheceilingmountedvandalproofguard.

Usingreardomelightswhencamerasareinuseisalways

recommendedtosolvethisissue.
