Ⅱ Charging
ⅠIntroducing CM8
Before using for the first time, please fully charge the gimbal. Use a
5V2A charging adapter and the Type-C charging cable included with
your purchase to charge the gimbal.
A red light indicates that it is charging, and a green light (solid) means
the battery is fully charged.
Ⅳ Calibration
1.Unfold the gimbal.
2.Following the sticker guide on the phone clamp, attach the phone to
the clamp. Ensure the tracking camera is on the bottom(AI Version)
and the phone’s camera is on the left.
3.Adjust the phone's position by sliding it left or right to achieve
balance. If the phone tilts to the left, slide it right; if it tilts to the
right, slide it left until it’s balanced, as shown in the picture.
Ⅵ Firmware Update
Ⅶ Product Specifications
Firmware updates can be done through the Capture 2 app. Before
updating, make sure the gimbal has enough battery. Once connected
to Bluetooth, ensure the app has network connectivity.
Then, in the app's shooting interface, open the settings menu on the
left side, find and click "Gimbal Version" to begin the upgrade. A
progress bar will show the update process, which typically takes
around 3 minutes.
5.V Mode (Inception Mode)
The phone’s camera follows the gimbal’s movements. The joystick controls the
roll of the camera, while push-pull movements create dreamlike visual effects.
Compatible Phone Weight
Compatible Phone Width
Compatible hone Thickness
Mechanical Performance
Battery Model
Battery Capacity
Working Current/Voltage
120g~300g (Phone Balance Needed)
50~90mm
≤13mm
Pan Axis: 335° Roll Axis: 335° Tilt Axis: 335°
18650 Lithium-ion Battery
2600mAh/3.7V
200mA~3000mA/3.5V~4.2V
3~4H
Charging Time
Operating Temperature Range
0℃~45℃
Ⅴ Using the Gimbal
1. Mode Indicator
Switch between five modes: PF, F, L, POV, and V.
Equilibrium state Disequilibrium
The corresponding mode is indicated by the light.
Disequilibrium
4.Press and hold the power button for 3 seconds to power on the
gimbal. The gimbal will start stabilizing (the first mode light and
battery light will stay on).
Ⅲ Unfolding & Folding
Hold the phone clamp with your left hand and the handle with your
right hand, then unfold the arm as shown in the picture.
After use, power off the gimbal. Rotate the tilt motor so that the phone
clamp is facing downward, then fold the arm downward, allowing the
2 Mounting Hole
mounting hole to slide into the mounting lock and lock in place.
5 Joystick
3 Zoom Button
6 Folding Axis
9 Power Button
12 Bottom 1/4” Hole
15 Type-C Charging Port
7 Mode Indicator
10 Shutter Button
13 Folding Lock
16 Roll Motor
8 Battery Indicator
11 M Button
14 Tilt Motor
17 Pan Motor
19 Lanyard Hole
18 Trigger
After powering on, the CM8 gimbal defaults to PF mode, and you can
switch modes using the M button.
Double-click the joystick to switch to portrait mode.
1.PF Mode (Pan Follow)
Automatically enters PF mode after powering on. The phone ’ s camera follows the
gimbal ’ s left-right movement, suitable for walking shots.
2.F Mode (Dual-Axis Follow)
In F mode, the phone ’ s camera follows both the left-right and up-down movements
of the gimbal, ideal for capturing everyday life or object-focused footage.
3.L Mode (Lock Mode)
L mode locks the camera ’ s shooting angle. When you long-press the trigger button,
the gimbal aut omatically enters this mode and will remain locked until you release
it. This mode is for capturing fixed-direction shots.
4.POV Mode (All-Axis Follow)
The phone’s camera follows the gimbal’s movements, great for creative shots.
2. Mode Switch Button
Single press to switch between gimbal
functions (PF, F, L, POV, V); double-click to
switch from right to left.
3.Battery Indicator Light
Shows the remaining battery level:
100%-20%: Green battery indicator stays on.
20%-0%: Red battery indicator blinks.
Charging:
During charging: Red battery indicator stays on.
Fully charged: Green battery indicator stays on.
4.Shutter Button
Long press: Switch between video and photo mode.
Single press: Capture a photo or start video
recording, depending on the current
mode.
Double press: Switch between the front and rear
cameras.
5.Joystick
Controls the gimbal's pitch and yaw movements.
Double press the joystick to switch between portrait
and landscape orientation.
6.Power Button
Long press (3 seconds): Power the gimbal on or off.
Single press: View the gimbal's battery level.
7.Zoom Wheel
Turn: Perform zooming or focusing actions.
Single press: Switch between zoom and
focus modes.
8.1/4 Screw Hole
For connecting external devices.
9.Type-C Charging Port
9.Insert the charging cable to charge the gimbal.
10.Trigger Button
Double press: Reset the gimbal motors to
their default position.
Long press: Enter the locking mode, where the
corresponding mode indicator light
will turn on.
11.Lanyard Hole
For attaching a lanyard for hanging.
Button Function
Different Mode Usage
ruoy esu ro erots ppa elibom eht ni ”2erutpaC“ rof hcraes esaelP
mobile phone to scan the QR code to install.
1.Properly mount the phone on the gimbal, then press and hold the
gimbal's "Power Button" for 3 seconds to power it on.
2.Turn on Bluetooth on your phone and launch the Capture 2 app.
Tap search and connect to the device named "CM8."
1.Home
2.Camera Professional Settings
3.Video Resolution Settings
4.Beauty Settings
5.Settings
6.Bluetooth Connection Status: Indicates whether the
phone is connected to the stabilizer.
7.Stabilizer Battery Level
8.Phone Battery Level
9.Flashlight
10.Current Stabilizer Mode and Status
*Camera Settings：
Return to the homepage.
Adjust the resolution and frame rate for video recording.
Toggle beauty mode on/off and adjust its intensity.
Displays the current flash status. You can configure the flash settings in the
camera settings menu.
11. Smart Tracking
When enabled, the camera can recognize the following gestures:
( ) → Triggers the current mode's capture action.
( ) → Switches between photo mode and video mode.
Panorama: Provides 180°, Magic Self, and 3x3 panorama modes.
Photo: Take a photo.
Video: Regular video shooting.
Slow Motion: Offers 8x slow-motion video recording at maximum.
Time-Lapse: Divided into Static Time-Lapse and Track Time-Lapse.
*180° Panorama: Capture 5 photos to be stitched together.
*Magic Self: Follow the app's instructions to position the subject in
the frame, then capture 3 photos to be stitched together.
*320° Panorama: Capture 8 photos to be stitched together.
*3x3 Panorama: Capture 9 photos to be stitched together.
*APP Parameters and Version Information
14.Shutter
15.Switch Front/Rear Camera
16.Album
Swipe to select different shooting modes.
12.Gesture Recognition
13.Shooting Modes
*The Capture 2 App requires iOS 11.0 or later, or Android 7.0 or later.
Note:
1. During the upgrade process, do not exit the Capture 2 app or switch to the background.
2. After a successful upgrade, the gimbal will automatically power off. To use it normally, you will
need to power it on again manually.
3. If the upgrade fails, restart both the gimbal and the app, then reconnect the gimbal via Bluetooth
through the app before trying the upgrade again.
Capture 2 App Connection Steps:
Download Capture 2 APP
Introduction to the main interface of the APP
Product Specifications
Ⅷ Disclaimer and Safety Instructions
Disclaimer
Safety Instructions
Troubleshooting
Names and Content of Hazardous Substances
in the Product
1
2
3
4
5
11
12
14
13
15
6 7 8
16
9
10
1
2
3
6
7
8
10
13
4
5
12
1 Phone Clamp
11
4 Zoom Wheel
14
16
17
18
9
15
19
Component
Name
This table is prepared according to SJ/T 11364.
least one homogeneous material of the component exceeds
the environmental requirements of the EU RoHS Directive)
the limit specified in GB/T 26572. (The product complies with
Components
Metal
Shell
Circuit Board
Internal Wires
Accessories
Other
Hazardous Substances
(Hg)
MercuryLead Cadmium
(Cd)
Cadmium
Polybrominated
Biphenyls
(Cr+6)
(PBB)
Diphenyl
ether
(PBDE)
(Pb)
indicates that the content of the hazardous substance in all
homogeneous materials of the component is below the limit
specified in GB/T 26572
X
indicates that the content of the hazardous substance in at
.labmig enohptrams ”8MC“eht gnisahcrup rof uoy knahT
Before using this product, please read this document carefully as it
concerns your safety and legal rights. Follow the instructions in this
document for proper use and settings of the product. Failure to follow
the instructions may result in harm to you, people around you, or
gnidnuorrus ro labmig enohptrams”8MC“ eht ot egamad
products.
By using this product, you acknowledge that you have read the
user manual, understood, accepted, and agreed to all terms and
conditions, especially the disclaimer and safety instructions. Douying
Technology will not be held responsible for any damages, injuries, or
legal liabilities caused by direct or indirect misuse of the product.
Users should follow all safety guidelines mentioned in the text.
In case of updates, no separate notification will be given. Please
visit the official website WWW.VEVOR.COM for the latest product
information.
1. The phone gimbal is not waterproof. Do not expose it to any liquids.
Do not use the product in rainy or humid environments and do not
immerse it in water or make it wet. Exposure to liquid may cause
corrosion reactions, battery self-ignition, or even explosions.
2. In the event of a fire, extinguish it immediately to prevent
severe damage.
Fault
Phenomenon
Red light flashes
when powered on.
Low battery. Charge for 3-4 hours.
slowly unpon startup.
The AI tracking module
the subject.
This occurs due to
excessive or rapid
movement during
shooting.
fails and cannot follow
In low-light conditions,
face and human
tracking performance
may be affected.
Move the device to a well-lit environment or
turn on the fill light to brighten the workspace.
When faces or subjects
are too close to the
phone,only partial
recognition is possible.
The optimal tracking range is 1-5 meters,
with the AI camera positioned ate shoulder
height for best results.
Both gimbal operation and tracking are
designed for low-speed use, making them
suitable for regular live streaming and
filming-not for fast-motion capture.
Reduce the movement speed of faces and
human figures,keeping it within a
specified range.
The phon is not
Five green lights flash balanced,and the
motor is in prote
ction
mode.
Follow the instruction in the manual to
demonstrate the corret operation:Clam
the phone in the holder and adjust it to
the balanced position.
Fault Cause Solution
3. Please use the product within the temperature range of 0℃ to
45℃. Do not heat the product as excessive temperatures may
shorten its lifespan.
4. Pay attention to the safe use of the product. Mechanical impact,
crushing, or throwing heavy objects on the product is strictly
prohibited.
5. It is strictly prohibited to disassemble the product in any way.
Piercing the battery during disassembly may cause leakage of
internal liquid, fire, or explosion.
6. When not in use for a long time, discharge the battery to a remaining
capacity of 40% to 65% before storage. Do not store the product after
completely discharging the battery for a long time, as it may lead to
over-discharge and damage to the battery cells, making it unusable.
It is recommended to recharge and discharge the battery every three
months to maintain battery activity.
7. Dropping the product from heights may damage the motor. Please
note that.
8. The charging port is not waterproof, Liquid contact may cause
product failure.
App Store Google Play
Shenzhen Funsnap Technology Co.,Ltd
201, Building B5, Zhimei Huizhi E-commerce Park,Fuzhou
Avenue, Fuyong Street, Bao'an DistrictShenzhen,China
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
This product is subject to the provision of European Directive
2012/19/EC. The symbol showingawheelie bin crossed through
indicates that the product requires separate refuse collection in the
European Union. This applies to the product and all accessories
marked with this symbol. Products marked as such may not be
discarded with normal domestic waste, but must be taken to a
collection point for recycling electrical and electronic devices
FCC Information:
CAUTION: Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment!
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1) This product may cause harmful interference.
2)This product must accept any interference received, including
interference that may cause undesired operation.
WARNING: Changes or modifications to this product not expressly
approved by the party.respo
nsible f
or compliance could void the
user's authority to operate the product.
Note: This product has been tested and found to comply with the
limits for a Class B digital device pursuant to Part 15 of the FCC
Rules, These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This product generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However
, t
here is no guarantee that interference
will not occur inaparticular installation. If this product does cause
harmful interference to radio or television reception,which can be
determined by turning the product off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures.
· Reorient or relocate the receiving antenna.
· Increase the distance between the product and receiver.
· Connect the product to an outlet on a circuit different from that to
which the receiver is connected.
· Con
sult t
he dealer or an experienced radio/TV technician for
assistance.
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again
if there are any technology or software updates on our product.
MODEL:CM8
Mobile Stabilizer
(English) 1 (English) 2
(English) 3 (English) 4
(English) 5 (English) 6
(English) 7 (English) 8
(English) 9 (English) 10
(English) 11 (English) 12
(English) 13 (English) 14
(English) 15 (English) 16
(English) 17
(1) Panorama lmage Quality: Low, Medium, High. This refers to the pixel quality
when shooting panoramas. If the phone's performance is low, it's recommended to
use low resolution to improve the stitching rate.
(2) initialize Sensor: When the gimbal drifts slowly, click this button to initialize the
sensor. it will function normally after restarting.
(3) Horizontal Fine-Tuning: Adjust the horizontal line in the default state after startup.
(4) Live Streaming, Face Tracking: Click to enable face tracking in other
live-streaming apps.
(5) Gimbal Version: Shows the current gimbal firmware version. When a “Upgrade"
prompt appears in front of the version number, click to upgrade the gimbal firmware.
(6) Bluetooth Version: Shows the current Bluetooth firmware version. When a
"Upgrade" prompt appears in front of the version number, click to upgrade the
Bluetooth firmware.
Set flash, grid, image aspect ratio, joystick sensitivity, and adjust the joystick's speed
to Slow,Medium, or Fast. Left-right reverse and up-down direction change the
joystick's control direction opposite to the default.
AUTO Mode: Automatically adjusts is0 (sensitivity) and Shutter speed, while allowing
manual adjustment of EV (exposure value).
M (Manual) Mode: Allows manual adjustment of iSO and Shutter speed, while EV is
set automatically.
*For Static Time-Lapse, set the interval and duration at the top of
the screen, then press the shutter button.
*For Track Time-Lapse, after setting the interval and duration, you
can select up to5 gimbal position points (controlled by the joystick).
After pressing record, the gimbal will move the phone to the
selected position points and take photos in sequence.
Intelligent Tracking, Modes include face tracking, target tracking and human shape
tracking.
Face Tracking: Automatically locks onto and tracks the most prominent face in the
frame.
Target Tracking: Requires manually selecting, the object to be tracked on the screen
before it can be locked and tracked.
Human Shape Tracking: Automatically detects and tracks the torso of a human body
based on recognition results (does not lock onto a specific person).
Note: After recognizing a face or human shape, a green selection box will appear. A
green selection box will also appear when an object is recognized. lf the target object
is lost, the selection box will turn red.To stop target tracking, during, the tracking
process, click the X icon in the upper right comer of the green box.
MODEL:CM8
Mobile Stabilizer
(language: English)
Referencing the instructional video is essential. Product
operation may be compromised if the shown methods
are not implemented or if warnings are overlooked.
Please scan the QR code to
see a video on how to use it.
8-language version
of the manual.
