Package Contents

• Solar Panel

• Wall Mounting Bracket

• Extension Cable

• Mounting Screws and Anchors (×4)

• Drillbit

• Cable Guides (×3)

• Cable Guide Screws and Anchors (×3)

STEP 2: Select an Install Method

1. Loosen the adjustment ring to

position the mount head at the

optimal angle determined in

STEP 1. Twist the solar panel

onto the mounting bracket (see

Figure 1).

2. Tighten the adjustment ring,

then tighten the screw under

the mounting point using

a Phillips screwdriver (not

included - see ).Figure 1

3. Set the mounting bracket in the

desired mounting position and

mark holes for screws.

4. Drill the holes using the included

drillbit.

5. Insert the included anchors,

then attach the bracket to the

mounting surface using the

provided screws (see Figure

2). Make sure all screws are

fastened tightly.

Figure 1

Safety Precautions

• Ensure you can safely drill into your selected mounting

location, and the mounting surface can support at least 3

times the combined weight of the solar panel, wall mount

bracket, and camera.

• The solar panel may require periodic cleaning to ensure it is

capturing light effectively. Use a damp cloth only. Do not use

chemical cleaners.

• Do not dispose of the battery in regular garbage. Handle

as hazardous waste. Dispose according to local hazardous

waste programs.

STEP 3A: Installation (CONTINUED)

6. Feed the cable from the

solar panel through the

cable gland on the base

of your wire-free camera

(not included - see

Figure 3).

7. Lower the camera base

onto the mounting

bracket. Align the 2 tabs

in the mounting bracket

with the 2 slots in the

camera base. Push down

on the camera base

to lock into place (see

Figure 3).

8. Connect the cable from

the solar panel to the

USB port on your wire-

free camera’s Power

Pack.

NOTE: Check the LED

indicator on the Power

Pack to ensure it is

receiving power. The

LED glows red if the

Power Pack is charging,

and green for fully

charged.

9. Ensure the rubber plug

cover is ﬁtted over

the USB connector. To

ensure a weatherproof

seal, twist and push the

plug cover until the end

of the USB connector

is visible (see ). Figure 4

Pull gently on the cable

to ensure it remains

connected.

10. Insert the security screw

through the fastener on

the top of the camera

base, which lines up with

a hole on the mounting

bracket. Tighten using a

Phillips screwdriver (see

Figure 5).

Figure 5

Adjustment

ring

The solar panel supports 2 installation methods:

• STEP 3A: Install your wire-free camera onto the included bracket.

Both the camera and solar panel must be installed in an area with

plenty of direct sunlight exposure.

• STEP 3B: Install your wire-free camera in a sheltered location and

install the solar panel in a separate, exposed location (see the back

of the guide for details).

STEP 3A: Installation

STEP 1: Positioning Tips

• Choose a location for the solar panel with plenty of direct sunlight

exposure. Do not install in a covered or shaded area. Performance is

dependent on temperature and light exposure.

• Position the solar panel in the desired mounting area and check the

LED indicator on the underside of the panel. If the LED turns on, the

solar panel is receiving sufﬁcient light to power your camera.

• The solar panel requires at least 3-4 hours of direct sunlight per

day. Rotate the panel to face the direction where it will get the

most exposure to sunlight.

Figure 2

Mounting

surface

Mounting screws

Anchors

Mounting bracket

Figure 3

Run cable

through

gland

Align slots

with tabs

on bracket

Camera base

To install the panel and

camera in the same location:

Figure 4

Twist and push the

plug cover until

the end of the USB

connector is visible

ACSOL1_QSG_EN_R1

Quick Start Guide

Solar Panel for

Wire-Free Cameras

ACSOL1

ACSOL1_QSG_EN_R1

As our products are subject to continuous improvement, Lorex reserves the right

to modify product design, speciﬁcations and prices, without notice and without

Quick Start Guide

Solar Panel for

Wire-Free Cameras

ACSOL1

Dimensions

4.7"

120mm

4.5" /

115mm

5.4"

137mm

2.9"

73mm

6.9"

176mm

2.9" / 16mm

6.1" /

156mm

Need Help?

Visit us online for up-to-date software

and complete instruction manuals

Click on the Downloads tab

Visit lorex.com

Search for the model

number of your product

Click on your product

in the search results

Resources

1. Loosen the adjustment

ring to position the

mount head at the

optimal angle determined

in STEP 1. Twist the solar

panel onto the mounting

bracket (see ).Figure 5

2. Tighten the adjustment

ring, then tighten the

screw under the mounting

point using a Phillips

screwdriver (not included -

see ).Figure 5

3. Set the mounting bracket

in the desired mounting

position and mark holes

for screws.

4. Drill the holes using the

included drillbit.

5. Insert the included

anchors, then attach

the bracket to the

mounting surface using

the provided screws (see

Figure 6). Make sure

all screws are fastened

tightly.

6. If your wire-free camera

(not included) is already

mounted, detach

the camera from the

mounting plate by

removing the security

screw (see Figure 7 -

Part A). Lift the camera

up and away from the

mounting surface (see

Figure 7 - Part B).

Figure 5

Adjustment

ring

STEP 3B: Installation

Figure 6

Mounting

surface

Mounting screws

Anchors

Mounting bracket

ATTENTION:

Ensure you choose a location for the solar panel that is within reach of your

wire-free camera using the included 10ft (3m) extension cable.

Figure 7

To install the panel in a

different location than the

camera:

STEP 3B: Installation (CONTINUED)

Figure 8

Run cable

through

gland

Align

slots with

tabs on

mounting

plate

Camera base

7. Connect the included

extension cable to

the solar panel cable.

Ensure the cables are

connected tightly for a

weatherproof seal.

8. Feed the cable from the

solar panel through

the cable gland on the

base of your wire-free

camera (see Figure

8).

9. Lower the camera base

onto the mounting

plate, and reattach the

security screw.

10. Connect the cable from

the solar panel to the

USB port on your wire-

free camera’s Power

Pack.

NOTE: Check the LED

indicator on the Power

Pack to ensure it is

receiving power. The

LED glows red if the

Power Pack is charging,

and green for fully

charged.

11. Ensure the rubber plug

cover is ﬁtted over

the USB connector. To

ensure a weatherproof

seal, twist and push the

plug cover until the end

of the USB connector

is visible (see ). Figure 9

Pull gently on the cable

to ensure it remains

connected.

12. [OPTIONAL] Use the

included cable guides

with the cable guide

screws and optional

drywall anchors as

needed (see Figure

10).

Part A

Part B

Anchor

Cable Guide

Screw

Cable Guide

Figure 10

Figure 9

Twist and push the

plug cover until

the end of the USB

connector is visible
