9/21 1200 S

eries Electric Water Coolers Page 1 of 21

1455 Kleppe Lane (775) 359-4712 Sparks, NV 89431-6467  Fax (775) 359-7424

E-mail: haws@hawsco.com website: www.hawsco.com

No.

0510000866 (6)

Electric Water Cooler and Bottle Filling Stations

MODELS 1201S / 1201SF / 1211S / 1211SF / 1202S / 1202SF / 1212S / 1212SF

1201SFH, 1202SFH, 1211SH, 1211SFH, 1212SH, 1212SFH

INSTALLATION, OPERATION

MAINTENANCE INSTRUCTIONS

SAFETY PRECAUTIONS

CAUTION: Disconnect electrical power to outlet before installing or servicing.

NOTICE:

A. The electrical receptacle must have code-approved ground-fault circuit

interrupter (GFCI) protection for personnel.

B. Care should be taken not to damage refrigeration system lines or

electrical wires during installation.

C. Installation must conform to all applicable codes and standards.

D. Maintain 8 inches (20cm) separation from filter circuit board (antenna) at

all times.

NOTE TO INSTALLER: Please leave this information with the Maintenance Department.

FULL-SCALE ROUGH-IN TEMPLATE PN 0510001007 AVAILABLE UPON REQUEST.

SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS

MODEL PLEASE CALL:

TECHNICAL SUPPORT: 1-800-766-5612

FOR CUSTOMER SERVICE: 1-888-640-4297

9/21 1200 S

eries Electric Water Coolers Page 2 of 21

REQUIRED TOOLS (OR EQUIVALENT):

□Adjustable Wrench

□1/4” Bit-holding screwdriver (7-3/4” max length)

□1/4” Bit-holding screwdriver (4” max length, required for installs at Child ADA height only)

□#2 Phillips bit and a Flat-blade bit

□T15, T20, T25 Torx bits (supplied when required)

□5/16” Nut driver bit (not necessary but will make some steps easier)

□Trimming tool for ABS pipe (necessary for some retrofits)

□Small bubble level

□Tape measure and tools for properly marking and measuring wall

□Clean cloth or paper towels

□Tubing cutter for polyethylene tubing

□Small diagonal cutting pliers (required for high/low units only)

□Permanent Marker

REQUIRED PARTS (NOT SUPPLIED):

□P-trap (1-1/4” recommended) with appropriate seal for 1-1/4” OD tailpiece

□Suitable trap adapter (if not already installed – see installation drawing for details)

□Suitable angle stop valve with 3/8” compression outlet (if not already installed – see installation

drawing for details)

□1/4” fasteners suitable for fastening water cooler to structural material in wall.

□Plastic cup (for bleeding air out of system following install)

LOCATION OF UNIT: The Model 12XX Series are suitable for indoor use only. These units

are unsuitable for corrosive environments (such as enclosed chlorinated pool areas) or very

dusty areas. The ambient air temperature must be maintained between 40°F and 104°F at all

times. Installation into a location not meeting these limitations will void the warranty.

SUPPLY LINE: The min recommended size is 1/2“IPS with 30-90 psig (2-6 ATM) flowing

pressure. Where sediment or mineral content is a problem, an upstream water pre-filter is

recommended.

PLUMBING CONNECTIONS: Inlet is 3/8” OD polyethylene tubing. A suitable plastic ferrule

and metal insert are provided to allow direct connection to a 3/8” compression water stop

valve. Tailpiece is 1-1/4” OD ABS.

ELECTRICAL CONNECTION: 120VAC/60HZ GFCI-Protected electrical receptacle, min 15A

service. Use standard size 4.5” X 2.75” wall plate. Dedicated circuit recommended.

INSTALLATION PROCEDURE

GENERAL NOTES:

Certain installation sections below may not apply to your specific model. Skip to the

next h

eading in such cases.

For all plastic push-in type fitting connections, only connect NSF-61 so

ft-copper or

plastic tu

bing. These instructions must be followed to ensure a watertight connection:

If tubing needs to be shortened, cut tubing square and clean.

b. Mark from end of tube the depth of insertion (See table below).

Push tube into the fitting until it bottoms ou

To remove, depress collet and pull tubing out.

Tube OD Size OD Tolerance Insertion Depth

1/4” ±.004” 11/16”

3/8” ±.004” 3/4”
