INSULATED JACKET

Installation Instructions

AGIJ30 / AGIJ36 / AGIJ42

IMPORTANT - READ ALL INSTRUCTIONS BEFORE YOU BEGIN

INSTALLER SHOULD LEAVE THESE INSTRUCTIONS WITH THE HOMEOWNER

Some parts have sharp edges. Care must be taken when handling the various components to avoid

personal injury. Wear gloves when handling.

TOOLS REQUIRED:

Work gloves

Safety glasses

Electric drill with assorted bits for mounting hardware, masonry anchors, etc. where needed

Phillips screwdriver

Flat-blade screwdriver

Level

Tape measure

Inspect the product to verify that there is no shipping damage. If any damage is detected, call the shipper

and initiate a damage claim. Hestan Commercial Corp. is not responsible for shipping damage. DO NOT

discard any packing material (box, pallet, straps) until the unit has been inspected.

Remove all exterior packaging materials, banding, tape, etc. Remove all protective film from the inside of

your cabinets. You may leave any exterior protective film on until after installation is complete.

ATTENTION

THIS APPLIANCE SHOULD NOT BE INSTALLED OVER, UNDER, OR NEXT TO UNPROTECTED

COMBUSTIBLE CONSTRUCTION. An Insulation Jacket is required when installing your Hestan grill

in an enclosure (island) made of combustible materials (such as wood). Hestan does not recommend

construction of your island using such materials. If your island is constructed of these materails, see the

INSTALLATION section of your Hestan Use & Care manual for cutout dimensions and allowances in your

island. A minimum clearance to vertical combustible material is 12” (30 cm) on the sides and the rear of the

grill is also required.

The minimum vertical clearance to combustible materials means that ALL combustible materials must be

outside this 12” (30 cm) zone. As an example, if you have an island with a stucco or tiled surface and wood-

frame construction beneath, the wood is considered combustible, even though the grill is touching the stucco

or tile surface, which is non-combustible. In extreme circumstances, the wood could potentially get hot

enough to burn. In this case, an Insulation Jacket is required.

VENTILATION OPENINGS

A minimum of three 10 in² (65 cm²) of ventilation openings must be provided for both left and right sides of

your enclosure (island), as well as the back. These openings are required to safely dissipate gas vapors if there

is a leak in your enclosure.

1. Please ensure your island meets the cutout dimensions shown in the Hestan grill manual for proper

fitment of the Insulation Jacket and Grill. The installer will have to build up any internal structural

elements or supports in the island in order to secure the jacket in place.

INSULATED JACKET INSTALLATION

)

2. Slide in the Insulation Jacket as per the image below. The front face of the jacket should be flush to the

face of your island.
