UB 10DL
English
1
2 3 4
1
2
3
4
5
6
7
8
9
0
A
B
C
Français
Tête
Interrupteur
Batterie
Boîtier avant
Lentilles
Ampoule
Témoin d’état de batterie
Verrou
Enlever
Fixer
Réflecteur
Courroie
English
Head
Switch
Handle
Battery
Front cover
Lens
Bulb
Remaining battery
indicator lamp
Latch
Remove
Attach
Reflector
Strap
Español
Cabezal
Interruptor
Asa
Batería
Tapa frontal
Lente
Bombilla
Lámpara indicadora de
batería restante
Seguro
Retirar
Conector
Reflector
Correa
CAUTION
Do not look at the light directly.
Do not open the front cover immediately after using the
flashlight because the bulb is very hot.
Be sure to turn the switch OFF before replacing the bulb
or when not using.
Do not expose the flashlight to rain.
CORDLESS FLASHLIGHT UB10DL INSTRUCTION MANUAL
HOW TO USE
1. Battery insert/removal
Insert the battery in direction A until it clicks. To remove,
extract it in direction B while holding down the latch. (Fig. 2)
2. Head angle adjustment
The angle of the head can be adjusted according to use.
The head rotates from 0° to 180° and can be fixed in 8
steps. (Fig. 3)
3. Bulb replacement
Turn the flashlight so that the lens is facing downward,
taking care not to drop the bulb, and remove the front
cover, lens and reflector. After changing the bulb, replace
the front cover, lens and reflector. (Fig. 4)
4. Attach the strap as required. (Fig. 1)
CAUTION:
If the battery indicator lamp lights when the torchilight is
turned on, the battery power is low. Replace or recharge
the battery. Failure to do so may result in the light
suddenly going off due to the over discharge protection
circuit. It is advisable to occasionally check the battery
indicator lamp status during use.
SPECIFICATIONS
Charger UC10SFL (sold separately) [Charging time : Approx. 40 min.]
Battery BCL1015 (sold separately)
Bulb 12.5 V 0.25 A
Operating time Approx. 4.5 hours (Using full charged BCL1015 battery)
Dimensions (without battery) 2-19/64” (58 mm) (diameter) × 7-11/64” (182 mm) (length)
Weight (without battery) 0.4 lbs. (170 g)
Do not shock or disassemble the flashlight.
Do not allow the flashlight to contact gasoline, thinner etc.
Do not leave the flashlight in a car or the like that tends to
be exposed to be searching heat of the sun (above 60°C).
Otherwise, troubles can result.
5
7
1
6
3
9
C
8
2
4
9
A
B
180°
6
B
0
5
7
A
