Side 1/2

CR1-2-3B-FS(-L)

3/19/15

Item # 13274

c. reserves the right to change

specifications without notice.

*AutoCad available on KCL

Item #

Project:

Qty:

• Stainless steel exterior front and sides

• Energy efficient, vacuum formed, seamless, one piece ABS interior liner

• Refrigerant flow is controlled with a TXV expansion valve

• Unique “ducted” air distribution system

• Solid state digital controller with temperature alarms and LED display (Fahrenheit or Celsius)

• Cabinet and doors are insulated with 2-3/8” of R-134a, CFC free, foamed in place polyurethane

• Doors are constructed of stainless steel exterior, an ABS interior liner and are standard with locks

• Exclusive "stepped" door design to protect recessed door gasket

• Spring assisted self closing doors with stay open feature

• Sturdy 8 gauge stainless steel hinge plate with welded hinge pin

• One piece, full length, extruded aluminum flush mount door handle

• Field reversible doors (with optional kit)

• Enamel coated evaporator coil

• Automatic hot gas condensate evaporator

• Stainless steel shelf supports

• (3) Epoxy coated wire shelves per section adjustable 1” on center

• Standard with 4" factory installed casters (two with brakes)

• Stackable (two units high) to conserve warehouse floor space

• Three years parts and labor warranty

• Five year compressor warranty

• 8 ft. cord and plug

* CR2B-FS is ENERGY STAR qualified

CRB-FS Dimensions

W x D x H

Section - 27.5” x 33.6” x 79.63”*

2 Section - 55” x 33.6” x 79.63”*

3 Section - 84” x 33.6” x 79.63”*

with 4” casters

Electrical/Refrigeration

Voltage 115/60/1

ACR Breaker

& 2 Section - 15.0

3 Section - 20.0

Electrical Connection (NEMA)

1 & 2 Section - 5-15P

3 Section - 5-20P

Voltage Range 104-126

Ambient Temp. Range 45˚-100˚F

Control Setpoint Range 34˚ to 52˚F

*Refrigerant R-134a

Warranty

Valid in United States, Canada, Puerto Rico,

and U.S. Territories. Contact factory for

warranty in other countries.

• Three Year - Parts & Labor on entire

machine.

• Five Year - Parts on: Compressor.

Options

• Door reversal kit

• Additional epoxy shelves

• Stainless steel shelves

• Combination universal tray/pan slides

• Foot pedal door opener

• Air filter

Dimensions / Capacity

Electrical & Refrigeration Data

Model # One Section

CR1B-FS(-L)

Two Section

CR2B-FS

Three Section

CR3B-FS

Nominal Storage Capacity (CF) 23.3 ft

51.0 ft

74.3 ft

Interior Storage Capacity (CF) (AHAM) 20.9 ft

47.2 ft

68.2 ft

Overall Width x Depth 27.5” x 33.6” 55” x 33.6” 84” x 33.6”

Height (including 4” casters) 79.63” 79.63” 79.63”

Door Opening Width x Height 22.8” x 59.6” 22.8” x 59.6” 22.8” x 59.6”

Depth with Door open at 90° 59.6” 59.6” 59.6”

Adjustable Shelves 3 6 6 (Left) 3 (Right)

Shelf Dimensions (W x D) 21.25” x 26” 23.9” x 24.6” 23.9” x 24.6” 21.25” x 26”

Crated Shipping Weight 345 lbs 540 lbs 875 lbs

Crated Height x Width x Depth 83” x 31.5” x 39.5” 83” x 59” x 39.5” 83” x 90.5” x 39.5”

Model # One Section

CR1B-FS(-L)

Two Section

CR2B-FS

Three Section

CR3B-FS

Amperage

3.7 7.0 12.0

Energy Consumption (kwh/day)

ENERGY STAR

2.52 3.05 5.57

Heat Rejection (BTU/Hr.) @ NSF

450 866 866 (Left) 450 (Right)

Approx. Nominal Compres. BTU/HR(HP)

1625(.2HP) 2373(.25+HP)

2373(.25+HP) 1625(.2HP)

CR1-2-3B-FS(-L)

Commercial Series Refrigerators

618 Hwy. 74 S., Peachtree City, GA 30269

TEL 800-438-6087

FAX 800-345-1325

www.hoshizaki.com
