Hotpoint FDD914K Manual

Hotpoint Opvaskemaskine FDD914K

Læs gratis den danske manual til Hotpoint FDD914K (20 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 21 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 11 anmeldelser. Har du et spørgsmål om Hotpoint FDD914K, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/20

Instruction booklet

,1509)50-4

Contents

Installation, 2-5

Positioning and levelling

Technical data

Electrical connection

Connecting the water supply

Description of the appliance, 6

Overall view

Control panel

Loading the racks, 7

Lower rack

Cutlery basket

Upper rack

Start-up and use, 8-9

Starting the dishwasher

Loading the detergent

Washing options

Wash cycles, 10

Wash cycle table

Rinse aid and refined salt, 11

Loading the rinse aid

Loading the refined salt

Care and maintenance, 12

Shutting off the water and electricity supplies

Cleaning the dishwasher

Preventing unpleasant odours

Cleaning the sprayer arms

Cleaning the water inlet filter

Cleaning the filters

Leaving the machine unused for extended periods

Precautions and advice, 13-14

General safety

Disposal

Saving energy and respecting the environment

Troubleshooting, 15

After Sales Service, 16

After Sales Service

Essential Contact Information

Parts and Accessories

Appliance Registration

Hotpoint Guarantee, 17

.,, '"

English, 1

Positioning and levelling

1. Remove the appliance from all packaging and check

that it has not been damaged during transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Check the dishwasher by placing it so that its sides or

back panel are in contact with the adjacent cabinets or

even with the wall. This appliance can also be recessed

under a single worktop* (see the Assembly instruction

sheet).

3. Position the dishwasher on a level and sturdy floor. If

the floor is uneven, the front feet of the appliance may be

adjusted until it reaches a horizontal position (the angle of

inclination must not exceed 2 degrees). If the appliance is

levelled correctly, it will be more stable and much less

likely to move or cause vibrations and noise while it is

operating.

4*. Adjust the height of the rear foot from the front of the

appliance* on the central lower part of the dishwasher,

turning a hexagonal spanner (red color) with an opening

of 8 mm in a clockwise direction to increase the height

or in an anticlockwise direction to decrease the height.

Anti-condensation strip*

After installing the dishwasher, open the door and stick

the adhesive transparent strip under the wooden shelf in

order to protect it from any condensation that may form.

Keep this instruction manual in a safe place for

future reference. If the appliance is sold, given away or

moved, please ensure the manual is kept with the

machine, so that the new owner may benefit from the

advice contained within it.

Please read this instruction manual carefully: it

contains important information regarding the safe

installation, use and maintenance of the appliance.

If the appliance must be moved at any time, keep it

in an upright position; if absolutely necessary, it may be

tilted onto its back.

Advice regarding the first wash cycle

After the appliance has been installed, immediately

before running the first wash cycle, completely fill the

salt dispenser with water and add only then

approximately 1 kg of salt (see chapter entitled Rinse aid

and refined salt). The water may overflow: this is normal

and is not a cause for concern. Select the water

hardness value (see chapter entitled Rinse aid and

refined salt). - After the salt has been poured into the

machine, the LOW SALT indicator light* switches off.

If the salt container is not filled, the water softener

and the heating element may be damaged as a result.

* Only available in selected models.

Installation

Technical data

Dimensions

width 60 cm

height 85 cm

depth 60 cm

Capacity 14 standard place-settings

Water supply

pressure

0,05 ÷ 1MPa (0.5 ÷ 10 bar)

7,25 – 145 psi

Power supply

voltage See appliance data plate

Total absorbed

power See appliance data plate

Fuse See appliance data plate

This dishwasher conforms to

the following European

Community Directives:

-2006/95/CE dated 16/01/2007

(Low Voltage) and subsequent

modifications

-89/336/EEC dated 03/05/89

(Electromagnetic Compatibility)

and subsequent modifications

-97/17/EC (Labelling)

-2002/96/ CE Waste Electrical

and Electronic Equipment

(WEEE)

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	FDD914K
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	600 mm
Dybde:	600 mm
Højde:	850 mm
Skærmtype:	LCD
Placering af apparat:	Fritstående
Støjniveau:	42 dB
Antal vaskeprogrammer:	12
Dør farve:	Sort
Vaskeklasse:	A
Vandforbrug pr. cyklus:	13 L
Antal kuverter:	14 kuverter
Tørringsklasse:	A
Vandpåfyldning:	Kold
Tørresystem:	Naturlig
Quick wash:	Ja
