DAILY REFERENCE

GUIDE

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance, please

You can download the Safety Instructions and the Use

and Care Guide, by visiting our website

docs.hotpoint.eu and following the Instructions on the

back of this booklet.

Before using the appliance carefully read Health and Safety guide.

PRODUCT DESCRIPTION

APPLIANCE

1. Upper rack

2. Foldable flaps

3. Upper rack height adjuster

4. Upper spray arm

5. Lower rack

6. Space Zone

7. Cutlery basket

8. Lower spray arm

9. Filter Assembly

10. Salt reservoir

11. Detergent and Rinse Aid dispensers

12. Rating plate

13. Control panel

0000 000 00000

Service:

CONTROL PANEL

1. On-Off/Reset button with indicator light

2. Program selection button

3. Salt refill indicator light

4. Rinse Aid refill indicator light

5. Program number and remaining time indicator

6. Delay indicator light

7. Display

8. Zone Wash 3D indicator light

9. Delay button

10. Zone Wash 3D

11. tablet (tab) indicator light

12. Turbo button with indicator light

13. Extra Dry button with indicator light

1 2 3 4 5 6 7 8 9 10 12 1311

1 2 3 4 5 6 7 8 9 10 11

1 2 3 4 5 6 7 8 9 10 11 12 13

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher (see

PROGRAMS DESCRIPTION) and should be filled when the SALT REFILL

indicator light in the control panel is lit.

1.Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2. Only the first time you do this: fill the salt

reservoir with water.

3. Position the funnel

(see figure)

and fill the salt

reservoir right up to its edge (approximately 1 kg);

it is not unusual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the

opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, we recommend carrying out the

procedure before the washing cycle is started.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for average (3) water hardness.

• Switch on the appliance by pressing the ON/OFF button.

• Switch off the appliance by pressing the ON/OFF button.

• Hold down button P for 5 seconds, until you hear a beep.

• Switch on the appliance by pressing the ON/OFF button.

• The current selection level number and the salt indicator light both flash.

• Press button P to select the desired hardness level (see WATER

HARDNESS TABLE).

• Switch off the appliance by pressing the ON/OFF button.

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specifically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL

indicator light switches off.

If the salt container is not filled, the water softener and the heating

element may be damaged as a result.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser A should

be filled when the RINSE AID REFILL indicator light in the control

panel is lit.

1. Open the dispenser

by pressing and pulling up the tab on the lid.

2. Carefully introduce the rinse aid as far as the maximum (110 ml)

reference notch of the filling space - avoid spilling it. If this happens,

clean the spill immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satisfied with the drying results, you can ad-

just the quantity of rinse aid used.

• Switch the dishwasher on using the ON/OFF button.

• Switch it off using the ON/OFF button.

• Press button P three times - a beep will be heard.

• Switch it on using the ON/OFF button.

• The current selection level number and rinse aid indicator light flash.

• Press button P to select the level of rinse aid quantity to be

supplied.

• Switch it off using the ON/OFF button

Setting is complete!

If the rinse aid level is set to ZERO (ECO), no rinse aid will be supplied. The

LOW RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 4 levels can be set according to the dishwasher model.

The factory setting is for a medium level.

• If you see bluish streaks on the dishes, set a low number (1-2).

• If there are drops of water or limescale marks on the dishes, set a

high number (3-4).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser

use the opening device A. Introduce

the detergent into the dry dispenser

B only. Place the amount of

detergent for pre-washing directly

inside the tub.

1.1.When measuring out the

detergent refer to the mentioned

earlier information to add the proper

quantity. Inside the dispenser B there

are indications to help the detergent dosing.

2. Remove detergent residues from the edges of the dispenser and

close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the

closing device is secured in place.

The detergent dispenser automatically opens up at the right time

according to the program.

If all-in-one detergents are used, we recommend using the

TABLET

button, because it adjusts the program so that the best washing and

drying results are always achieved.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 Hard 17 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	HIO 3T232 WG E UK
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Energieffektivitetsklasse (gammel):	A+++
Årligt energiforbrug:	238 kWh
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fuldt indbygget
Inverter-teknologi:	Ja
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	42 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	10
Forsinket start-timer:	Ja
Dør farve:	Hvid
Vaskeklasse:	A
Vandforbrug pr. cyklus:	9.5 L
Bestik rum type:	Kurv
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	14 kuverter
Cyklustid:	215 min.
Forsinket start (maks.):	12 t
Opvaskeprogrammer:	Eco 50°C,Intensive,Normal,Quick,Silent,Soak
Tørringsklasse:	A
Årligt vandforbrug:	2660 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.83 kWh
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Glasbeskyttelse:	Ja
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Wi-Fi kontrolleret:	Ingen
Brugerdefineret panel klar:	Ja
Temperatur (maks):	65 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Kurves indstillelige placering:	Lower,Upper
Strømforbrug (fortsat-tændt):	6 W
Tørresystem:	Turbotørring
Maksimal varmtvandsforsyning temperatur:	60 °C
Varighed af tilstanden fortsat-tændt:	12 min.
