INSTRUCTION FOR USE

THANK YOU FOR PURCHASING A HOTPOINT-ARISTON PRODUCT.

To receive more comprehensive help and support, please register your product at:

www.hotpoint.eu/register

Before using the appliance carefully read Health and Safety guide.

PRODUCT DESCRIPTION

APPLIANCE

1. Upper rack

2. Foldable flaps

3. Upper rack height adjuster

4. Upper spray arm

5. Space Zone

6. Lower rack

7. Cutlery basket

8. Lower spray arm

9. Filter Assembly

10. Salt reservoir

11. Detergent and Rinse Aid dispensers

12. Rating plate

13. Control panel

0000 000 00000

Service:

CONTROL PANEL

1. ON/OFF button

2. PREVIOUS button

3. NEXT button

4. Tablet Detergent (All-in-one) button

5. Zone Wash button

6. Zone Wash

indicator light

7. Display

8. Eco program indicator light

9. Start Delay indicator light

10. Program number and remaining time indicator

11. Closed water tap indicator light

12. Rinse Aid refill indicator light

13. Salt refill indicator light

14. Tablet Detergent (All-in-one) indicator light

15. Zone Wash 3D button with indicator light

16. Turbo button with indicator light

17. Extra Dry button with indicator light

18. Start Delay button with indicator light

19. START button with indicator light

5 6 7 8 9 10 11 13121

234

14 15 16 17 18 19

FIRST TIME USE

SETTING MENU AND SALT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

SETTING MENU

1. Switch on the appliance by pressing the ON/OFF button.

2. Switch off the appliance by pressing the ON/OFF button.

3. Hold down START button for 5 seconds, until you hear a beep.

4. The display shows the first available setting (letter "A"), followed by

its value (for example: 3).

5. Press PREVIOUS/NEXT to scroll the list of the available settings

and to see their value (see the below table), then press START if

you want to change the value of the displayed setting: its value will

start blinking.

6. Use PREVIOUS/NEXT buttons to change the blinking value of the

selected settings, then press START to save the new value: it will

stop blinking.

7. To change another settings repeat steps 5-6.

8. To exit settings menu - press ON/OFF button.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher (see

PRODUCT DESCRIPTION) and should be filled when the SALT REFILL

indicator light in the control panel is lit.

1.Remove the lower rack and unscrew

the reservoir cap (anticlockwise).

2.Only the first time you do this: fill the

salt reservoir with water.

3.Position the funnel

(see figure)

and fill

the salt reservoir right up to its edge

(approximately 1 kg); it is not unusual

for a little water to leak out.

4.Remove the funnel and wipe any salt

residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

As soon as this procedure is complete, run a program without loading.

The “Soak” program alone is NOT sufficient.

Residual saline solution or grains of salt can lead to corrosion,

irreparably damaging the stainless steel components.

The guarantee is not applicable if faults are caused by such

circumstances.

After the salt has been poured into the machine, the SALT REFILL

indicator light switches off.

Only use salt that has been specifically designed for dishwashers.

If the salt container is not filled, the water softener and the heating

element may be damaged as a result.

Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is “3” for average water hardness.

To change, follow instructions in section “SETTING MENU”.

LETTER SETTING VALUES

(Default - in bold)

Water Hardness Level

(see “Setting the Water Hardness”

and “Water Hardness Table”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “Adjusting the dosage of Rinse Aid”) 1 | 2 | 3 | 4 | 5

Start Program

To set the cycle to show at switch on of the

appliance.

“E”= Eco, “L”= Last cycle run

E | L

Brightness Level

To adjust the brightness

level of the display.

“Lo”=Low, “Hi”= High

Lo | Hi

Sound Level

To adjust the volume of the sounds.

“OF” = sounds off, “Lo” = low volume,

“Hi” = high volume.

OF | Lo | Hi

Internal Lights

(see “Options and Functions”)

“On” = On, “OF” = Off

On | OF

Light on the Floor

(see “Options and Functions”)

“On” = On, “OF” = Off

On | OF

Factory Settings

To restore to the factory default all the

values of the settings included in the

settings menu. After the activation of this

setting (ON), the machine switches OFF and

restores the factory settings.

“On” = On, “OF” = Off

On | OF

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 Hard 18 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	HIP 4O22 WGT C E UK
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Berøring
Indbygget skærm:	Ja
Skærmtype:	TFT
Strøm:	13 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Energieffektivitetsklasse (gammel):	A++
Årligt energiforbrug:	266 kWh
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fuldt indbygget
Inverter-teknologi:	Ja
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	42 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	10
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Hvid
Vaskeklasse:	A
Vandforbrug pr. cyklus:	9.5 L
Farve på kontrolpanel:	Black, Stainless steel
Antal kuverter:	14 kuverter
Cyklustid:	215 min.
Forsinket start (maks.):	12 t
Opvaskeprogrammer:	Eco 50°C, Intensive, Normal, Quick, Silent, Soak
Tørringsklasse:	A
Årligt vandforbrug:	2660 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.93 kWh
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Glasbeskyttelse:	Ja
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Wi-Fi kontrolleret:	Ingen
Brugerdefineret panel klar:	Ja
Temperatur (maks):	65 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Kurves indstillelige placering:	Lower, Upper
Strømforbrug (fortsat-tændt):	6 W
Tørresystem:	Turbotørring
Ekstra tørt:	Ja
Maksimal varmtvandsforsyning temperatur:	60 °C
Varighed af tilstanden fortsat-tændt:	12 min.
