Before using the appliance carefully read Health and Safety guide.

APPLIANCE

PRODUCT DESCRIPTION

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance, please

You can download the Safety Instructions and the

Use and Care Guide, by visiting our website

docs.hotpoint.eu and following the Instructions on

the back of this booklet.

1. Upper rack

2. Foldable aps

3. Upper rack height adjuster

4. Upper spray arm

5. Lower rack

6. Space Zone

7. Cutlery basket

8. Lower spray arm

9. Filter Assembly

10. Salt reservoir

11. Detergent and Rinse Aid dispensers

12. Rating plate

13. Control panel

1. On-O/Reset button with indicator light

2. Program selection button with indicator light

3. Zone Wash 3D button with indicator light

4. Short Time button with indicator light / Key lock

5. Eco program indicator light

6. Key lock indicator light

7. Display

8. Program number and remaining time indicator

DAILY REFERENCE

GUIDE

CONTROL PANEL

9. Tablet (Tab) indicator light

10. Closed water tap indicator light

11. Rinse Aid rell indicator light

12. Salt rell indicator light

13. Extra Dry button with indicator light

14. Tablet (Tab) button with indicator light

15. Delay button with indicator light

16. Start/Pause button with indicator light / Drain out

0000 000 00000

S i :erv ce

1112

9 16

14 15

65 7 8 11 12 1310

3 ’’

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the reta-

ining elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and should be lled when the

SALT REFILL

indicator light in the control panel is lit .

1. Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2. -Only the rst time you do this: ll the salt re

servoir with water.

3. Position the funnel (see gure) and ll the salt

reservoir right up to its edge (approximately

1 kg); it is not unusual for a little water to leak

out.

4. Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for average (3) water hardness.

• Switch on the appliance by pressing the button.ON/OFF

• Switch o the appliance by pressing the button.ON/OFF

• Hold down button START/Pause for 5 seconds, until you hear a beep.

• Switch on the appliance by pressing the button.ON/OFF

• The current selection level number and the salt indicator light both ash.

• Press button P to select the desired hardness level (see WATER HARD-

NESS TABLE).

• Switch o the appliance by pressing the button.ON/OFF

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indi-

cator light switches o.

If the salt container is not lled, the water softener and the

heating element may be damaged as a result.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 Hard 17 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser should A

be lled when the indicator light in the control RINSE AID REFILL

panel is lit.

1. Open the dispenser B by pressing and pulling up the tab on the lid.

2. Pour in the rinse aid (max.110 ml), making sure it does not overow

from the dispenser. If this happens, clean the spill immediately with

a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can ad-

just the quantity of rinse aid used.

• Switch the dishwasher on using the button.ON/OFF

• Switch it o using the button.ON/OFF

• Press button START/Pause three times - a beep will be heard.

• Switch it on using the button.ON/OFF

• The current selection level number and rinse aid indicator light ash.

• Press button P to select the level of rinse aid quantity to be supplied.

• Switch it o using the buttonON/OFF

Setting is complete!

If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied. The

LOW RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 4 levels can be set according to the dishwasher model.

The factory setting is specic to the model, please follow instruction

above to check this for your machine.

• If you see bluish streaks on the dishes, set a low number (2-3).

• If there are drops of water or limescale marks on the dishes, set a

mid-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device A.

Introduce the detergent into the dry dispenser B only. Place the

amount of detergent for pre-washing directly inside the tub.

1. When measuring out the detergent

refer to the mentioned earlier infor-

mation to add the proper quantity.

Inside the dispenser there are B

indications to help the detergent

dosing.

2. Remove detergent residues from

the edges of the dispenser and clo-

se the cover until it clicks.

3. Close the lid of the detergent

dispenser by pulling it up until the

closing device is secured in place.

The detergent dispenser automatically opens up at the right time

according to the program.

If all-in-one detergents are used, we recommend using the TABLET

button, because it adjusts the program so that the best washing and

drying results are always achieved.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	HSFO 3T223 W UK
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	450 mm
Dybde:	590 mm
Højde:	850 mm
Vægt:	39500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.3 m
Pakkevægt:	41500 g
Energieffektivitetsklasse (gammel):	A++
Årligt energiforbrug:	212 kWh
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Inverter-teknologi:	Ja
Installationsrum bredde:	600 mm
Installationsrum dybde:	590 mm
Tilsluttet belastning:	1900 W
Støjniveau:	43 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	8
Forsinket start-timer:	Ja
Børnesikring:	Ja
Justerbare fødder:	Ja
Dør farve:	Hvid
Vaskeklasse:	A
Vandforbrug pr. cyklus:	9 L
Bestik rum type:	Kurv
Farve på kontrolpanel:	Hvid
Antal kuverter:	10 kuverter
Cyklustid:	240 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Auto,Eco 50°C,Intensive,Normal,Silent,Soak
Tørringsklasse:	A
Årligt vandforbrug:	2520 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.74 kWh
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Indikator for resterende tid:	Ja
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Slimline (45 cm)
Wi-Fi kontrolleret:	Ingen
Brugerdefineret panel klar:	Ingen
Temperatur (maks):	70 °C
Saltindikator:	Ja
Kurves indstillelige placering:	Lower,Upper
Strømforbrug (fortsat-tændt):	5 W
Tørresystem:	Statisk
Maksimal varmtvandsforsyning temperatur:	60 °C
Varighed af tilstanden fortsat-tændt:	12 min.
Aftagelig overside:	Ja
