Side 1/24

Precautions 2 ........................................................

About notations 3 ..................................................

Open Source Software 3 .......................................

Trademarks and registered trademarks 3 ...............

Precautions for installation 3 ..................................

Troubleshooting 3 ..................................................

Specifications 4 .....................................................

Optional accessories 4 ..........................................

Standard accessories 4 .........................................

Other items that are needed (not included) 4 .........

Installation Procedure 5 .........................................

Contents

About the user manuals

Product documentation is composed of the following documents.

•

Installation Guide (this document): Provides information about “Precautions”,

“Precautions for installation” and the installation method.

•

Basic Information (Refer to the link on the following support website): Provides

information about “Precautions for use” and “Detail specifications”.

•

Operating Instructions (Refer to the link on the following support website):

Explains how to perform the settings and how to operate this camera.

https://i-pro.com/global/en/surveillance/training-support/documentation-database-list

Model No.

WV-S8574L,WV-S8573L

WV-S8564L,WV-S8563L

WV-S8544L,WV-S8543L

WV-S8544,WV-S8543

av0322-2032

PGQP3398XA

Included Installation Instructions

Network Camera

For professional use only Outdoor use

"<Control No.: C****>" used in these documents should be used to search for information

on our technical information website (https://i-pro.com/global/en/surveillance/training-

support/support/technical-information) and will guide you to the right information.

WV-S8574L

• Before attempting to connect or operate this product, please read these instructions

carefully and save this manual for future use.

• microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.

• The external appearance and other parts shown in this manual may differ from the actual product within the

scope that will not interfere with normal use due to improvement of the product.

For U.S. and Canada:

i-PRO Americas Inc.

https://www.i-pro.com/

For Europe and other countries:

i-PRO Co., Ltd. Fukuoka, Japan

https://www.i-pro.com/

i-PRO EMEA B.V. UK Branch

1010 Cambourne Business Park,

Cambridgeshire CB23 6DP

Authorised Representative in EU:

i-PRO EMEA B.V.

Laarderhoogtweg 25, 1101 EB

Amsterdam, Netherlands

Installation Guide

Disposal of Old Equipment and Batteries

Only for European Union and countries with recycling systems

These symbols on the products, packaging, and/or accompanying documents mean that used

electrical and electronic products and batteries must not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used batteries, please take them to

applicable collection points in accordance with your national legislation.

By disposing of them correctly, you will help to save valuable resources and prevent any potential

negative effects on human health and the environment.

For more information about collection and recycling, please contact your local authority.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.

Note for the battery symbol (bottom symbol)

This symbol might be used in combination with a chemical symbol. In this case it complies with the

requirement set by the Directive for the chemical involved.

NOTE: This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference when the equipment is

operated in a commercial environment. This equip-

ment generates, uses, and can radiate radio frequen-

cy energy and, if not installed and used in accor-

dance with the instruction manual, may cause harm-

ful interference to radio communications.

Operation of this equipment in a residential area is

likely to cause harmful interference in which case the

user will be required to correct the interference at his

own expense.

FCC CAUTION: Changes or modifications not

expressly approved by the party responsible for com-

pliance could void the user's authority to operate the

equipment.

Supplier’s Declaration of conformity

Trade name : i-PRO

Model No. : WV-S8574L, WV-S8573L

WV-S8564L, WV-S8563L

WV-S8544L, WV-S8543L

WV-S8544, WV-S8543

Responsible Party :

i-PRO Americas Inc.

8550 Fallbrook Drive, Suite 200 Houston,

Texas 77064

Support Contact : 1-800-513-5417

For U.S.A.

CAN ICES-3(A)/NMB-3(A)

For Canada

The model number and serial number of this prod-

uct may be found on the surface of the unit.

You should note the model number and serial num-

ber of this unit in the space provided and retain this

book as a permanent record of your purchase to aid

identification in the event of theft.

Model No.

Serial No.

For U.S.A.

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) this device must accept any interference

received, including interference that may cause

undesired operation.

For U.S.A.

Méthode d’installation Vis de fixation recommandée La capacité de traction minimale requise

Quand la caméra vidéo est directement

installée au plafond.

M4 × 16 mm {5/8 pouces}

/ 4 él.*

539 N {121 lbf}

* La longueur de la vis est un exemple lors de l’installation de la caméra au plafond ou sur un mur robuste d’une

épaisseur de 20 mm {25/32 pouces} ou plus.

■ Do not insert any foreign objects.

Fire or electrical shock may be caused if water or any foreign objects, such as metal objects, enter inside the unit.

Turn the power off immediately and contact qualified service personnel for service.

■ Do not use this product in an inflammable atmosphere.

Failure to observe this may cause an explosion resulting in injury.

■

Avoid installing this product in the locations where salt damage occurs or corrosive gas is produced.

Otherwise, the mounting portions will deteriorate and injury or accidents due to a fall of the product may occur.

■ Do not strike or give a strong shock to this product.

Failure to observe this may cause injury or fire.

■ Keep microSD memory cards away from infants and children.

Otherwise, they may swallow the cards by mistake.

In this case, consult a doctor immediately.

■ Do not hang down from this product or use this product as a pedestal.

Failure to observe this may cause injury or accidents.

■

Do not install this product on a place that is greatly influenced by wind.

Installation on a place where the wind speed is 60 m/s {approx. 134 mph} or more may cause a fall of the product

resulting in injury or accidents.

■ Do not sprinkle more water, exceeding the performance limit of waterproof with a high pressure

cleaning machine, etc.

Fire or electrical shock may be caused by immersion.

■ Do not attempt to disassemble or modify this product.

Failure to observe this may cause fire or electric shock. Consult the dealer for the repair or inspections.

■ Do not install or clean the camera, or touch this product, the power cable or the connected cables

during thunder storms.

Failure to observe this may cause electric shock.

■ Refer installation work to the dealer.

Installation work requires technique and experience. Failure to observe this may cause fire, electric shock, injury,

or damage to the product.

Be sure to consult the dealer.

■ Stop the operation immediately when something is wrong with this product.

When smoke goes up from the product, the smell of smoke comes from the product, or the exterior of the product

has deteriorated, continued use will cause a fire or fall of the product resulting in injury, or damage to the product.

In this case, turn the power off immediately and contact qualified service personnel for service.

■ Select an installation area that can support the total weight.

Selecting an inappropriate installation surface may cause this product to fall down or topple over, resulting in

injury or accidents. Installation work shall be started after sufficient reinforcement.

Caution:

• The network camera is only intended for a connec-

tion to an ethernet or PoE+ network without routing

to the outside plant.

• This product has no power switch. Be sure to install

disconnect devices such as a circuit breaker to shut

down the main power of power supplying equip-

ment to this product.

• Before attempting to connect or operate this prod-

uct, please read these instructions carefully.

Notice:

• This product is not suitable for use in locations

where children are likely to be present.

• Do not install this product in locations where ordi-

nary persons can easily reach.

• This product is a professional equipment.

• For information about screws and other parts

required for installation, refer to the corresponding

section of this document.

Precautions

: Direct current symbol

WARNING:

• Operation of this product in a residential environment could cause radio interference.

■ Periodic inspections shall be conducted.

Rust on the metal parts or screws may cause a fall of the product resulting in injury or accidents.

Consult the dealer for the inspections.

■ The exclusively designed mount bracket shall be used.

Failure to observe this may cause a drop resulting in injury or accidents.

Use the exclusively designed mount bracket for installation.

■ The screws and bolts must be tightened to the specified torque.

Failure to observe this may cause a drop resulting in injury or accidents.

■ Turn the power off when do wiring of this product.

Failure to observe this may cause electric shock. In addition, short circuit or wrong wiring may cause fire.

■ Install this product in a location high enough to avoid people and objects from bumping the

product.

Failure to observe this may cause injury.

■ Do not install this product in locations subject to vibration.

Loosening of mounting screws or bolts may cause a fall of the product resulting in injury or accidents.

■ Correctly perform all wiring.

Short circuits in the wiring or incorrect wiring may cause fire or electrical shock.

■ The measures of protection against snowfall shall be taken.

Weight of snow may cause a fall of the product resulting in injury or accidents. Protect the product against

snowfall by installing it under eaves.

■ Install the product securely on an installation surface in accordance with the installation

instructions.

Failure to observe this may cause injury or accidents.

■ Turn the power off when cleaning this product.

Failure to observe this may cause injury.

■ Do not rub the edges of metal parts with your hand.

Failure to observe this may cause injury.

Produkt Specifikationer

Mærke:	I-PRO
Kategori:	Overvågningskamera
Model:	WV-S8543L
Type:	IP-sikkerhedskamera
Højde:	90 mm
Produktfarve:	Hvid
Kompatible hukommelseskort:	MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC
Wi-Fi:	Ingen
Bluetooth:	Ingen
Formfaktor:	Kuppel
Relativ luftfugtighed ved drift (H-H):	10 - 100 %
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Webbrowser:	Ja
Understøttede lydformater:	AAC-LC, G.711, G.726
Driftstemperatur (T-T):	-40 - 60 °C
Maksimal opløsning:	2688 x 1520 pixel
Husmateriale:	Aluminium, Polycarbonate (PC)
Understøttede grafikopløsninger:	320 x 180,640 x 360,1280 x 720 (HD 720),1920 x 1080 (HD 1080),2560 x 1440,2688 x 1520
Forbindelsesteknologi:	Ledningsført
Strømkilde type:	PoE
Monteringstype:	Loft
Diameter:	300 mm
Indbygget kortlæser:	Ja
Indbygget HDD:	Ingen
Understøttet placering:	Udendørs
Antal brugere:	24 bruger(e)
Bæredygtighedscertifikater:	CE, Federal Communications Commission (FCC)
Hvidbalance:	ATW, AWC
Sensortype:	CMOS
Samlet antal megapixels:	4 MP
Optisk zoom:	2.5 x
Autofokus:	Ja
Maksimal størrelse på hukommelseskort:	512 GB
Minimumsbelysning:	0 Lux
Antal sensorer:	3
Optisk sensorstørrelse:	1/2.7 "
Zoom kapacitet:	Ja
Nattesyn:	Ja
LED type:	IR
Billedhastighed:	30 fps
Ethernet-grænsefladetype:	Gigabit Ethernet
Antal kameraer:	1
Brændviddeområde:	2.9 - 7.3 mm
Kameraets lukkerhastighed:	1/10000 - 16/25 sek./side
Nattesyn, afstand:	20 m
Dynamisk interval:	108 dB
Strømforbrug (Power over Ethernet (PoE)):	25.4 W
Kompensation for baggrundslys:	Ja
Highlight Compensation (HLC):	Ja
Audiosporing:	Ja
Registringsafstand (bred):	45.1 m
Observeringsafstand (bred):	18 m
Genkendt afstand (bred):	9 m
Identifikationsfstand (bred):	4.5 m
Registringsafstand (tele):	136.5 m
Observeringsafstand (tele):	54.6 m
Genkendt afstand (tele):	27.3 m
Identifikationsfstand (tele):	13.6 m
Antal områder med Privacy-maskering:	8
