EN -1-
Chart
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute.
If pressed when the dishwasher is switched off it
drains any possible liquids from dishwasher
(1 minute process).
If the indicator flashes repeatedly, see page 6 -
chapter “What to do if...”.
START/RESUME BUTTON
Push this button to start the selected program:
the indicator lights up and goes off at the end of the
program. When the door is opened during a
washing cycle, the cycle is temporarily paused:
the Start indicator blinks. To resume the cycle
close the door and push Start button again.
PROGRAM SELECTION
BUTTON
Push “Programs” button
(repeatedly) until the indicator
of the required program lights
up (see “Table of programs”
below).
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without any options) and may vary depending on
conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the
EN/Standard loading comparison test and other tests, contact the following address: “contact@whirlpool.com”.
* Power consumption in: Left-on mode: 0.70 W / Off-mode: 0.40 W.
Table of programs
Deter-
gent
Consumption
Drying
Phase
P
Programs Loading instructions
Litres kWh
Minutes
1)
1
Pre-Wash cold
Crockery to be washed later. — 5.0 0.02 10 NO
2
Rapid 40°C
Lightly soiled crockery, with no dried-on food. X 13.0 0.70 30 NO
3
Eco
2)
50°C
Normally soiled crockery.
Standard program the most efficient in terms of
its combined energy and water consumption.
X 15.0 1.02 165 Full
4
Baby Care
Program that, combined with the Baby Care
specially designed basket, ensures the best
cleaning results and sanitization of baby
accessories (soother, pacifiers, teats) while
washing also normally or heavily soiled crockery.
X 16.0 1.75 120 Full
5
Intensive 65°C
Recommended program for heavily soiled
crockery, especially suitable for pans and
saucepans.
X 15.0 1.50 140 Full
5019 300 01314
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS
QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY
BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.
Quick reference guide
Whirlpool is a registered trademark of Whirlpool USA
