Side 1/4
1
ENQuick Guide
PROGRAMS TABLE
Program Programs description
Drying
phase
Auto
Door
Available
options
*)
Duration
of wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1.
Eco 50°- Eco program is suitable to clean normally soiled tableware.
that for this use. it is the most ecient program in terms of its com-
bined energy and water consumption. and that it is used to assess
compliance with the EU Ecodesign legislation.
3:10 9.5 0.85
2.
Auto Intensive 65°- Automatic program for heavily soiled dishes
and pans (not to be used for delicate items).
2:00 - 3:10 14.0 - 17.0 1.50 - 1.85
3.
Auto Mixed 55° - Automatic program for normally soiled pans and
dishes.
1:30 - 2:30 14.5 - 16.0 1.15 - 1.30
4.
Glass 45° - Program for delicate items, which are more sensitive to
high temperatures, for example glasses and cups.
1:40 12.0 1.20
5.
Fast&Clean 28’ 45° - Program to be used for half load of lightly-soiled
dishes with no dried food residues. Does not have drying phase.
-
0:28 9.0 0.50
6.
Pre-Wash - Use to refresh crockery planned to be washed later.
No detergent to be used with this program.
- -
0:12 4.5 0.01
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
THANK YOU FOR BUYING AN IGNIS PRODUCT.
CONTROL PANEL
1. On-O/Reset button with indicator light
2. Program selection button
3. Salt rell indicator light
4. Rinse Aid rell indicator light
5. Program number and delay time indicator
6. Tablet (Tab) indicator light
Before using the appliance carefully read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR
APPLIANCE IN ORDER TO HAVE MORE
DETAILED INFORMATION
7. Display
8. Multizone indicator lights
9. Multizone button
10. Delay button
11. START/Pause button with indicator
light / Tablet (Tab)
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel (see gure) and ll the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the rst time you do this: ll the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into the
container during the wash program (this could damage the water softener be-
yond repair). Whenever you need to add salt, it is mandatory to complete the
procedure before the beginning of the washing cycle to avoid corrosion.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse
aid dispenser A should be lled when the RINSE
AID REFILL indicator light in the control pan-
el is lit. NEVER pour the rinse aid directly into the
appliance tub.
A
C
D
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub.
If all-in-one detergents are used, we recommend using the TABLET button,
because it adjusts the program so that the best washing and drying results
are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning e-
ciency. This system regenerates itself with salt, therefore it is required
to rell salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in nal rinse and nishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
3
1
2
854 6 97 10 11
2
Quick GuideEN
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-
sales Service, please state the codes provided on your product‘s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model
identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
TROUBLESHOOTING
Please scan the QR code on your product in order to have more detailed information.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher
does not ll the wa-
ter. Display shows:
H , 6 and On/O
LED is blinking
rapidly
No water in the water supply or the tap is
closed.
Make sure there is water in the water supply or the tap running.
The inlet hose is bent.
Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher
and reboot.
The sieve in the water inlet hose is clogged;
it is necessary to clean it
After having carried out the verication and cleaning, turn o and turn on the
dishwasher and restart a new program.
Dishwasher nishes
the cycle prema-
turely. Display
shows: 15 and On/
O LED is blinking
rapidly
Drain hose positioned too low or siphoning
into home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).Check for
siphoning into home sewage system, install air admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
LOADING THE RACKS
CAPACITY: 14 standard place-settings
More information in the Daily Reference Guide on website.
CLEANING AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)
please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
The lower spray arm may
be removed by pulling it
upwards.
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues
please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period
of either up to 7 or up to 10 years, according to the specic Regulation requirements.
DELAY - The start time of the program may be delayed for a period of
time between 1 and 12 hours.
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be o.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program
(see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
MULTIZONE - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
Please scan the QR code on your product in order to have more detailed information.
AUTO DOOR is a convection drying system which automatically
opens the door during/after drying phase to ensure exceptional dry-
ing performance every day. Door opens at the temperature that is
safe to your kitchen furniture.
LOWER RACK
For pots, lids, plates, sa-
lad bowls, cutlery etc.
Large plates and lids
should ideally be pla-
ced at the sides to avo-
id interferences with
the spray arm.
The lower rack has tip-
-up supports which
can be used in a verti-
cal position when ar-
ranging plates or in a
horizontal position (lo-
wer) to load pans and
salad bowls easily.
(loading example for the
lower rack)
CUTLERY RACK
(loading example for the cutlery rack)
The third rack was designed to
house the cutlery.
UPPER RACK
(loading example for the upper rack)
Load delicate and light dishes: glas-
ses, cups, saucers, low salad bowls.
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
