Quick Guide

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button with indicator light

3. WASH CYCLE PROGRESS indicator lights

4. DOOR LOCKED indicator light

5. FUNCTION buttons with indicator lights

6. DRYING ONLY button with indicator light

7. button DRYING LEVELS

8. TIME DRYING button

9. TEMPERATURE button

10. WASH CYCLE knob

11. PUSH & GO button

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump

7. Adjustable feet (4)

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

DETERGENT DISPENSER DRAWER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the

“max” level indicated on the central pin.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at

temperatures over 60°C.

! Follow the instructions given on the detergent

packaging.

Maximum load 7 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Drying

Maximum

load for dry-

ing (Kg)

Detergents and

Additives Recommended

detergent

Residual

dampness % (*)

Energy

consumption kWh

Total water lt

Laundry

temperature °C

Wash cycle

Temperature Maximum

spin

(r.p.m.)

Maxi-

mum

load for

washing

(Kg)

Dura-

tion

(h : m)

Wash Fabric

softener

Powder Liquid

Setting Range 2 3

1 Mixed 40°C – 40°C 1000 7,0 1:00 5,0   – – – – –

2 Cotton (2) 40°C – 60°C 1200 7,0 3:40 5,0     50 1,0 75 45

3 Synthetics (3) 40°C – 60°C 1200 4,0 2:55 4,0     35 0,9 60 43

4 White 60°C - 90°C 1200 7,0 2:30 5,0     52,1 1,4 75 55

5 Colours 40°C – 40°C 1200 7,0 1:30 5,0   – – – – –

6Eco 40-60 (1)

(Wash) 40 °C 40°C

1151 7,0 3:25 5,0     53 1,04 48 38

1151 3,5 2:40 2,5     53 0,68 45 36

1151 1,75 2:10 -     53 0,52 39 36

7 Sport 40°C – 40°C 600 3,5 1:30 3,5   – – – – –

8 20°C 20 °C - 20 °C 1200 7,0 1:50 5,0   – 52 0,2 64 22

9 Anti Odour 40°C - 40°C 1000 3,0 1:40 3,0     – – – –

10 Delicates 30°C – 30°C 0 1,0 1:20 3,0   – – – – –

11 Wool 40°C – 40°C 800 1,5 1:15 1,5   – – – – –

12 Rapid 30’ 30°C – 30°C 800 3,5 0:30 - -   – 73 0,2 31 27

13 Wash&Dry 45 min 30°C 1200 1,0 0:4530°C 1,0   – – – – –

14 Air Fresh - - - - 0:30  - - - - - – – – –

Rinse + Spin - - 1200 7,0 0:55  5,0 -  - - – – – –

Spin + Drain - - 1200 7,0 0:10  5,0 - - - - – – – –

  Required dosage Optional dosage

6Eco 40-60 (4)

(Wash&Drying) 40 °C 40°C 1151 5,0 9:50 5,0     0 4,50 75 38

1151 2,5 5:40 2,5     0 2,50 52 38

2) Long cotton programme: set the “2“ programme with a temperature of 40°C.

3) Synthetic program along: set the “3“ programme with a temperature of 40°C.

After programme end and spinning with maximum selectable spin speed, in default

programme setting.

Note: for the Eco 40-60 program in the WASH CYCLE TABLE the value of the maximum eective

spin is shown.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

the programmes, without options.

The values given for programmes other than the Eco 40-60

programme are indicative only.

For all Test Institutes

1) Eco 40-60 (Wash)- Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most

efficient programme in terms of energy and water consumption for washing normally soiled cotton

laundry.

4) Eco 40-60 (Wash&Drying)-

Test

wash&

drying cycle in compliance with EU Ecodesign

regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash programme

and set “Drying” option level to

“ ”.

The most ecient programme in terms of energy and

water consumption for washing and drying normally soiled cotton laundry. At the end of

cycle the garments can be immediately stored to the cupboard.

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

White

For heavily soiled whites and resistant colours.

Colours

A 30°C cycle that helps to preserve colours, suitable for cotton or

synthetic coloured garments. It allows for reducing electricity

consumption for heating the water while guaranteeing good washing

results. Suitable for lightly soiled garments.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at

40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

Sport

A cycle designed for washing lightly soiled sports clothing (tracksuits,

shorts, etc.); for best results, we recommend not exceeding the maximum

load indicated in the “Wash Cycle Table”. We recommend using liquid

detergent and adding the amount suitable for a half-load.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Anti Odour

use programme for washing garments with bad odours (e.g. smoke,

sweat, fried food). The programme is designed to remove bad odours

while preserving the fabric bres. Synthetics fabrics or mixed loads should

be washed at 40°, and resistant cotton fabrics at 60°.

Delicates

use programme to wash very delicate garments. It is advisable to turn the

garments inside out before washing them. For best results, use liquid

detergent on delicate garments.

When selecting an exclusively time-based drying function, a drying cycle is

performed at the end of the wash cycle that is particularly delicate, thanks

to light handling and appropriate temperature control of the water jet.

The recommended durations are:

1 kg of synthetic garments --> 150 min

1 kg of synthetic and cotton garments --> 180 min

1 kg of cotton garments --> 180 min

The degree of dryness depends on the load and fabric composition.

Wool - Woolmark Apparel Care - Blue:

The “Wool” wash cycle is approved by the Woolmark

Company for washing wool garments classied as

“hand-washable”, provided that the wash complies with

the instructions appearing on the garment’s label and

with those provided by the manufacturer of this washer-

dryer (M1126).

Rapid 30’

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Wash&Dry 45 min

select programme for washing and drying lightly soiled garments (Cotton

and Synthetic) in a short time. This cycle may be used to wash and dry a

laundry load of up to 1 kg in just 45 minutes. To achieve optimum results,

use liquid detergent and pre-treat cus, collars and stains.

AirFresh

ideal cycle to refresh garments and remove bad odours, in particular

smoke, from cotton and synthetic items in 30’ (max 1.5kg) without the

washing phase.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed to spin and drain the water.

WASH CYCLE PHASE INDICATOR LIGHTS

Once the desired wash cycle has been selected and has begun, the

indicator lights switch on one-by-one to indicate which phase of the cycle

is currently in progress.

Wash

Rinse

Spin/Drain

Drying

END End of Wash Cycle

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door. To open the door while a cycle is in progress, press the START/PAUSE

button; if the indicator light is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the

“Auto-Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

Rapid programming - Turn the washer-dryer on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER

section”.

- Close the door.

- Press the PUSH & GO button to start the wash cycle.

Traditional programming - Turn the washer-dryer on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- Set the WASH CYCLE knob to the desired cycle.

- Modify the temperature: pressing the button allows for gradually

reducing the temperature down to the cold wash level ( ).

- Select the desired wash cycle.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative

indicator light will light up steady green and the door will lock ( indicator

light on).

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash . If the indicator light is not lit, the door may be

opened. To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the indicator light turns on to signal that the door

cannot be opened. While a wash cycle is running, the door remains

locked. To open the door while a cycle is under way, for example, to add

or remove garments, press the START/PAUSE button to pause the

cycle; the indicator light will ash . If the indicator light is not lit, the

door may be opened. Press the START/PAUSE button again to

continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washer-dryer

using the START/PAUSE button (the relative indicator light will ash ),

then select the desired cycle and press the START/PAUSE button

again. ! To cancel a cycle that has already begun, press and hold the ON/OFF

button.

The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

Once the cycle terminates the indicator light will light up; when the END

indicator light switches o, the door may be opened. Open the door,

unload the laundry and switch o the machine.If you do not press “ON/

OFF” button, the washer-dryer will switch o automatically after about

a 10 minutes. Close the water tap, open the door and unload the washer-

dryer. Leave the door ajar to allow the drum to dry.

FUNCTIONS

- If the selected option is not compatible with the set wash cycle, the

indicator light will ash and the option will not be activated.

- If the selected option is not compatible with another previously

selected option, the indicator light will ash accompanied by a buzzer,

and only the latter option will be activated; the indicator light

corresponding to the activated option will turn on.

Stain removal

This option allows for selecting the type of dirt so as to optimally adjust the

cycle for removing the stains. The following types of dirt can be selected:

- Food: for stains caused by foodstus and beverages, for example.

- : for grease and ink stains, for example.Work

- : for mud and grass stains, for example.Outdoor

! The wash cycle duration varies according to the type of selected dirt.

Slow Spin

By selecting this function, reduces the spin speed.

Extra rinse

By selecting this option, the eciency of the rinse is increased and

optimal detergent removal is guaranteed. It is particularly useful for

sensitive skin.

Temperature

Each wash cycle has a pre-dened temperature. To modify the

temperature, press the button.

Drying

Drying may be set as follows:

- Based on the desired laundry dryness level:

Iron “ ”: suitable for clothes which will need ironing afterwards. the

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	BI WDIL 75125 UK N
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	545 mm
Højde:	820 mm
Vægt:	67000 g
Produktfarve:	Hvid
Kontroltype:	Buttons,Rotary
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.5 m
Placering af apparat:	Indbygget
Dørhængsel:	Venstre
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	- rpm
Støjniveau (centrifugering):	74 dB
Støjniveau (vask):	74 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Colour,Cotton,Delicate/silk,Eco,Mix,Outdoor,Sport,Synthetics,White,Wool
Børnesikring:	Ja
Justerbare fødder:	Ja
Tromle volumen:	52 L
Dør farve:	Hvid
Balance system:	Ja
Spin-tørre klasse:	B
Energieffektivitetsskala:	A til G
Vandpåfyldning:	Kold
Støjemissionsklasse:	B
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Visningsvindue:	Ja
Tørreprogrammer:	Cotton,Mix,Outdoor/sport,Sport,Synthetics,White clothes
Tørreevne:	5 kg
Vaske kapacitet:	7 kg
Støjniveau (tørring):	74 dB
Cyklustid vask og tørring:	590 min.
Vandforbrug pr. vask:	44 L
Vandforbrug pr. vask og tørring:	66 L
Lydalarm:	Ja
Energieffektivitetsklasse (vask):	E
Energieffektivitetsklasse (vask og tørring):	F
Energiforbrug pr. 100 cyklusser (vask):	78 kWh
Energiforbrug pr. 100 cyklusser (vask og tørring):	370 kWh
Cyklustid vask:	205 min.
Tænd/sluk-knap:	Ja
Dørgrebets farve:	Hvid
