Side 1/4

Quick Guide

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button and indicator light

3. WASH CYCLE PHASE indicator lights

4. DOOR LOCKED indicator light

5. OPTION buttons and indicator lights

6. CHILD LOCK button and indicator light

7. DELAY TIMER button

8. SPIN button

9. TEMPERATURE button

10. WASH CYCLE SELECTOR KNOB

11. PUSH & GO button

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

2 3

Maximum load 8 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(**)

Energy

consumption

kWh

Total water l

Laundry

temperature °C

Wash cycle Temperature Maxim

spin

(r.p.m.)

Max.

load

(kg)

Duration

(h : m)

Wash Fabric

softener

Powder

Liquid

Setting Range 2 3

1 Cotton 30°C – 30°C 1000 4 1:40   – – – – –

2 Synthetics 30°C – 30°C 1000 4 1:30   – – – – –

3 Colours 30°C – 30°C 1000 4 1:35   – – – – –

4 Delicates 30°C – 30°C 0 1 1:10   – – – – –

5 Rapid 30min 30°C – 30°C 800 4 0:30   – 71 0.18 37 27

6 Cotton (2) 40°C – 60°C 1400 8 3:55     49 1.4 97 45

7 Synthetics (3) 40°C – 60°C 1400 4 2:55     35 0.8 55 43

8 Mixed 40°C – 40°C 1400 8 1:45   – - - - –

40°C9Eco 40-60 (1) 40°C

1351 8 3:35     53 0.77 56 35

1351 4 2:45     53 0.61 50 34

1351 2 2:40     53 0.24 38 26

10 White 60°C – 90°C 1400 8 2:35     55 1.79 89 55

11 Rapid 20°C – 20°C 800 1.5 0:20   – – – – –

12 Duvet 30°C – 30°C 1000 3.5 1:40   – – – – –

13 Wool 40°C – 40°C 800 1.5 1:25   – – – – –

14 20°C 20°C – 20°C 1400 81:50   – 55 0.14 78 22

15 Rinse + Spin – – 1400 8 0:55 –  – – – – – –

16 Spin + Drain * – – 1400 8 0:10 – – – – – – – –

 Required dosage Optional dosage

DETERGENT DISPENSER DRAWER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage.

If powder detergent is used, insert the partition

into slot .B

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the “max”

level indicated on the central pin.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever and pull the drawer outwards.C

For all testing institutes:

2) Long cotton cycle: set cycle 6 at a temperature of 40°C.

3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.

* By selecting the 16 cycle and excluding the spin cycle, the washing machine will drain only.

** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected. The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60

Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.

The most ecient programme in terms of energy and water consumption for washing

normally soiled cotton laundry.

Note: for the Eco 40-60 program in the WASH CYCLE TABLE the value of the maximum

eective spin is shown.

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Cotton

A 30°C cycle for cotton garments. It allows for reducing electricity

consumption for heating the water while guaranteeing good washing

performance. Suitable for lightly soiled garments.

Synthetics

A 30°C cycle for synthetic garments. It allows for reducing electricity

consumption for heating the water while guaranteeing good washing

results. Suitable for lightly soiled garments.

Colours

A 30°C cycle that helps to preserve colours, suitable for cotton or

synthetic coloured garments. It allows for reducing electricity

consumption for heating the water while guaranteeing good washing

results. Suitable for lightly soiled garments.

Delicates

Suitable for washing very delicate garments. It is advisable to turn the

garments inside out before washing them. For best results, use liquid

detergent on delicate garments.

Rapid 30min

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Specic for synthetic items. If the dirt is dicult to remove, the temperature

can be increased up to 60° and powder detergent can be used too.

Mixed

A 40°C cycle for washing cotton and synthetic garments together.

Suitable for lightly soiled underwear.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at

40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

White

For heavily soiled whites and resistant colours.

Rapid

This cycle refreshes your garments in just 20 minutes.

Duvet

For washing clothing padded with goose down, such as double or single

duvets (weighing under 3.5 kg), cushions or down jackets. Duvets should

be loaded into the drum with their edges folded inwards and no more

than ¾ of the total drum volume should be used up. For best results, it is

advisable to use liquid detergent to be poured into the detergent drawer.

Wool - Woolmark Apparel Care - Blue:

The “Wool” wash cycle is approved by the Woolmark

Company for washing wool garments classied as

“hand-washable”, provided that the wash complies with

the instructions appearing on the garment’s label and

with those provided by the manufacturer of this washing

machine.

20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed to spin and drain the water.

WASH CYCLE PHASE INDICATOR LIGHTS

Once the desired wash cycle has been selected and has begun, the

indicator lights switch on one-by-one to indicate which phase of the cycle

is currently in progress.

Wash

Rinse

Spin

Drain

End of Wash Cycle

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button; if the indicator light is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the

“Auto-Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

Rapid programming

- Turn the washing machine on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER

section”.

- Close the door.

- Press the PUSH & GO button to start the wash cycle.

Traditional programming

- Turn the washing machine on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- Set the WASH CYCLE knob to the desired cycle.

- Modify the temperature and/or spin: pressing the button allows for

gradually reducing the temperature down to the cold wash level (20°C).

The spin speed may be progressively reduced by pressing the button,

until it is completely excluded (the setting). If these buttons are

pressed again, the maximum values are restored.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative indicator

light will light up steady green and the door will lock ( indicator light on).

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash amber. If the indicator light is not lit, the door

may be opened. To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the indicator light turns on to signal that the door

cannot be opened. While a wash cycle is running, the door remains

locked. To open the door while a cycle is under way, for example, to add

or remove garments, press the START/PAUSE button to pause the

cycle; the indicator light will ash amber. If the indicator light is not lit,

the door may be opened. Press the START/PAUSE button again to

continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash

amber), then select the desired cycle and press the START/PAUSE

button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

Once the cycle terminates the indicator light will light up; when the

indicator light switches o, the door may be opened. Open the door and

switch o the machine. If you do not press ON/OFF button, the

washing machine will switch o automatically after about a 10 minutes.

Close the water tap, open the door and unload the washing machine.

Leave the door ajar to allow the drum to dry.

OPTIONS

- If the selected option is not compatible with the set wash cycle, the

indicator light will ash and the option will not be activated.

- If the selected option is not compatible with another previously

selected option, the indicator light will ash accompanied by a buzzer

(3 beeps), and only the latter option will be activated; the indicator

light corresponding to the activated option will turn on.

Stain removal

This option allows for selecting the type of dirt so as to optimally adjust the

cycle for removing the stains. The following types of dirt can be selected:

- Food: for stains caused by foodstus and beverages, for example.

- : for grease and ink stains, for example.Work

- : for mud and grass stains, for example.Outdoor

! The wash cycle duration varies according to the type of selected dirt.

Extra rinse

By selecting this option, the eciency of the rinse is increased and

optimal detergent removal is guaranteed. It is particularly useful for

sensitive skin.

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	BWA 81485X S UK N
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	615 mm
Højde:	845 mm
Vægt:	71700 g
Produktfarve:	Sølv
Kontroltype:	Rotary,Touch
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	10 A
Ledningslængde:	1.2 m
Pakkevægt:	73200 g
Pakkedybde:	655 mm
Pakkebredde:	645 mm
Pakkehøjde:	890 mm
Energieffektivitetsklasse (gammel):	C
Strømforbrug (standby):	0.5 W
Strømforbrug (slukket):	0.5 W
Timer:	Ja
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	16
Støjniveau (centrifugering):	78 dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ingen
Near Field Communication (NFC):	Ingen
Vaskeprogrammer:	Baby care,Cold,Cotton,Eco,Hand/wool,Mix,Quick,Sport,Synthetics,Spin/drain,Delicate/silk
Børnesikring:	Ja
Justerbare fødder:	Ja
Energiforbrug ved vask:	0.541 kWh
Tromlemateriale:	Rustfrit stål
Tromle volumen:	54 L
Dør farve:	Hvid
Balje materiale:	Plast
Balance system:	Ja
Spin-tørre klasse:	B
Skum kontrol system:	Ja
Restfugtighed:	53 %
Vaskeklasse:	A
Årligt vandforbrug vask:	11594 L
Vandforbrug pr. cyklus:	50 L
Forsinket start (maks.):	24 t
Halv belastning:	Ja
Energieffektivitetsskala:	A til G
Selvrensende:	Ja
Indikator for resterende tid:	Ja
Wi-Fi kontrolleret:	Ingen
Rense plus funktion:	Ja
Støjemissionsklasse:	C
Energieffektivitetsklasse:	C
Energiforbrug pr. 100 cyklusser:	65 kWh
Cyklustid (hurtigt vaskeprogram):	30 min.
Strømforbrug (fortsat-tændt):	8 W
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Visningsvindue:	Ja
Oprindelsesland:	Polen
Anti-krølle funktion:	Ja
Tilføj tøj (pause) -funktion:	Ingen
Bruttovægt:	69800 g
Strømstiktype:	Type G
Minimum centrifugeringshastighed:	1400 rpm
Eksportkontrolklassisfikationsnummer (ECCN):	84502000
Aftagelig overside:	Ja
Nem strygning funktion:	Ja
Tænd/sluk-knap:	Ja
Pletfjerner indstilling:	Ja
Rengøring af tromle:	Ja
Toldproduktkode (TARIC):	84502000
EAN-nummer:	8050147637333
