Side 1/60

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washing machine

and starting a wash cycle, 4-5

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 6

Table of wash cycles

Personalisation, 7

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 8

Detergent dispenser drawer

Bleach cycle

Preparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 9

General safety

Disposal

Care and maintenance, 10

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

IWC 81051

Instructions for use

WASHING MACHINE

English,1

Français,13

FIT

Italiano, 25

Espańol,37

Portuguęs,49

Levelling the machine correctly will provide it with stability,

help to avoid vibrations and excessive noise and prevent it

from shifting while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow a sufficient

ventilation space underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the supply pipe

by screwing it to a cold

water tap using a ¾ gas

threaded connection (see

figure).

Before performing the con-

nection, allow the water to

run freely until it is perfectly

clear.

2. Connect the inlet hose

to the washing machine by

screwing it onto the corre-

sponding water inlet of the

appliance, which is situa-

ted on the top right-hand

side of the rear part of the

appliance . (see figure)

3. Make sure that the hose is not folded over or bent.

! The water pressure at the tap must fall within the values

indicated in the Technical details table (see next page).

! If the inlet hose is not long enough, contact a specialised

shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

! This instruction manual should be kept in a safe place for

future reference. If the washing machine is sold, transferred

or moved, make sure that the instruction manual remains

with the machine so that the new owner is able to familiari-

se himself/herself with its operation and features.

! Read these instructions carefully: they contain vital infor-

mation relating to the safe installation and operation of the

appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not been

damaged during the transportation process. If it has been

damaged, contact the retailer and do not proceed any

further with the installation process.

3. Remove the 4 protective

screws (used during tran-

sportation) and the rubber

washer with the correspon-

ding spacer, located on the

rear part of the appliance

( ).see figure

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need them

again if the washing machine needs to be moved to ano-

ther location.

! Packaging materials should not be used as toys for

children.

Levelling

1. Install the washing machine on a flat sturdy floor, without

resting it up against walls, furniture cabinets or anything

else.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening

or loosening the adjusta-

ble front feet ( ); see figure

the angle of inclination,

measured in relation to the

worktop, must not exceed

2°.

Installation

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	IWC 81051 C ECO(EU)
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	600 mm
Højde:	850 mm
Vægt:	73400 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ingen
Strøm:	10 A
Ledningslængde:	1.7 m
Pakkevægt:	75000 g
Pakkedybde:	650 mm
Pakkebredde:	640 mm
Pakkehøjde:	890 mm
Energieffektivitetsklasse (gammel):	A+
Strømforbrug (typisk):	1850 W
Strømforbrug (slukket):	1 W
Timer:	Ja
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Maksimal centrifugeringshastighed:	1000 rpm
Antal vaskeprogrammer:	16
Støjniveau (centrifugering):	74 dB
Støjniveau (vask):	61 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hygiene/anti-allergy, Black, Eco, Jeans/denim, Quick, Sport, Delicate/silk
Energiforbrug ved vask:	1.236 kWh
Årligt energiforbrug vask:	223 kWh
Døråbningsvinkel:	150 °
Tromlemateriale:	Rustfrit stål
Tromle volumen:	62 L
Dør farve:	Hvid
Balje materiale:	Plast
Balance system:	Ja
Spin-tørre klasse:	C
Cyklustid (maks.):	187 min.
Restfugtighed:	62 %
Vaskeklasse:	A
Årligt vandforbrug vask:	10532 L
Vandforbrug pr. cyklus:	- L
Indikator for resterende tid:	Ja
Vandpåfyldning:	Kold
Overløbsbeskyttelse:	Ja
Justerbar centrifugeringshastighed:	Ja
