Side 1/60

English,1

WASHER-DRYER

! This symbol reminds you to read this instruction manual.

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washer-dryer, 4-5

Control panel

Display

How to run a wash cycle or a drying cycle, 6

Wash cycles and options, 7

Table of programmes and wash cycles

Wash options

Detergents and laundry, 8

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Precautions and advice, 9

General safety

Disposal

Care and maintenance, 10

Cutting off the water and electricity supplies

Cleaning the washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

PWDE 7124 W

Instructions for use

Français,13

Español,25

Português,37

Italiano,49

! This instruction manual should be kept in a safe place for

future reference. If the washer-dryer is sold, transferred or

moved, make sure that the instruction manual remains with

the machine so that the new owner is able to familiarise

himself/herself with its operation and features.

! Read these instructions carefully: they contain vital

information relating to the safe installation and operation of

the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packaging.

2. Make sure that the washer-dryer has not been damaged

during the transportation process. If it has been damaged,

contact the retailer and do not proceed any further with the

installation process.

3. Remove the 4 protective

screws (used during

transportation) and the

rubber washer with the

corresponding spacer,

located on the rear part of

the appliance ( ).see figure

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need them

again if the washer-dryer needs to be moved to another

location.

! Packaging materials should not be used as toys for

children.

Levelling

1. Install the washer-dryer on a flat sturdy floor, without

resting it up against walls, furniture cabinets or anything

else.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening

or loosening the adjustable

front feet ( ); see figure

the angle of inclination,

measured in relation to the

worktop, must not exceed

2°.

Levelling the machine correctly will provide it with stability,

help to avoid vibrations and excessive noise and prevent it

from shifting while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow a sufficient

ventilation space underneath the washer-dryer.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the inlet hose

by screwing it to a cold

water tap using a 3/4 gas

threaded connection (see

figure).

Before performing the

connection, allow the

water to run freely until it is

perfectly clear.

2. Connect the inlet hose

to the washer-dryer by

screwing it onto the

corresponding water inlet

of the appliance, which is

situated on the top right-

hand side of the rear part of

the appliance . (see figure)

3. Make sure that the hose is not folded over or bent.

! The water pressure at the tap must fall within the range

of values indicated in the Technical data table (see next

page).

! If the inlet hose is not long enough, contact a specialised

shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	PWDE 7124 S
Bredde:	595 mm
Dybde:	551 mm
Højde:	850 mm
Vægt:	66000 g
Produktfarve:	Sølv
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Energieffektivitetsklasse (gammel):	B
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1200 rpm
Antal vaskeprogrammer:	16
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hand/wool, Quick, Delicate/silk
Energiforbrug ved vask:	- kWh
Tromle volumen:	52 L
Vaskeklasse:	A
Forsinket start (maks.):	24 t
Indikator for resterende tid:	Ja
Rense plus funktion:	Ja
Justerbar centrifugeringshastighed:	Ja
Tørreevne:	5 kg
Vaske kapacitet:	7 kg
Årligt energiforbrug ved vask og tørring:	1134 kWh
Årligt vandforbrug ved vask og tørring:	18400 L
Energiforbrug pr. vask og tørring:	- kWh
Vandforbrug pr. vask og tørring:	- L
Minimum centrifugeringshastighed:	1200 rpm
