Thank you

for purchasing the Infinity Kappa Series

10.1t tweeter. We’ve organized this manual to make your installa-

tion as simple and trouble-free as possible. Please read it thor-

oughly before proceeding. Remember to keep your sales receipt

with this manual in a safe place so both are available for future

reference.

A P PA

ERIES

10.1t

I N S T R U C T I O N S

- 2 -

IMPORTANT:

Installation of automotive

stereo components can require extensive

experience with a variety of mechanical and

electrical procedures. Although these

instructions explain how to install a Kappa

10.1t in a general sense, they do not show

the exact installation methods for your par-

ticular vehicle. If you do not feel you have

the experience, do not attempt the installa-

tion yourself, but instead ask your

Authorized Infinity Car Audio Dealer about

professional installation options.

WARNING:

Playing loud music in an automo-

tive environment can permanently damage

your hearing, as well as hinder your ability

to hear traffic. The maximum volume levels

achievable with Infinity speakers, combined

with high power amplification, may exceed

safe levels for extended listening. We rec-

ommend using low volume levels when dri-

ving. Infinity accepts no liability for hearing

loss, bodily injury or property damage as a

result of use or misuse of this product.

S PPEAKER LACEMENT

Kappa speakers are designed to be easily

installed in stock speaker locations. While

mounting your speakers in the original fac-

tory locations will, in most cases, provide

excellent sonic results, the best sounding

installations are a result of adherence to a

few basic rules.

• For the most spacious stereo image,

place the left and right speakers as far

apart as possible.

• For enhanced center image, place the

left and right speakers so they are

equidistant from the listening position.

If possible, try to place them as far

forward as possible.

• For best treble response when tweeters

are flush mounted in the I-Mount™, aim

them at the listening position by adjust-

ing the tweeter angle in the cup, tighten-

ing the small metal locking nut behind

the assembly and rotating the entire

assembly in its mounting location before

tightening the large plastic locking nut

behind the panel (see Fig 1, p.2).

INSTALLATION ARNINGS AND IPSW T

• Always wear protective eyewear when using

any tools.

• Turn off all audio systems and other electrical

devices before you start. Disconnect the (–) neg-

ative lead from your vehicle’s battery.

• Keep components in their package until final

installation. When moving a speaker, always

rest it with the cone or dome facing up. Never

use force to install any speaker.

• Check clearances on both sides of a planned

mounting surface before drilling any holes or

installing any screws. Remember that the

screws can extend behind the surface.

• At the installation sites, locate and make a note

of all fuel lines, hydraulic brake lines, vacuum

lines and electrical wiring. Use extreme caution

when cutting or drilling in and around these

areas.

CAUTION: In some cars, fuel tanks may be

located directly beneath the rear deck. Check

for adequate speaker basket clearance before

considering this location!

• Before drilling or cutting holes, use a utility

knife to remove unwanted fabric or vinyl, to

keep material from snagging in a drill bit or

saw.

• For door installations, check the clearance with

the windows throughout the range of the win-

dow’s travel, and verify that a mounted speaker

will not interfere with the window crank or

power window mechanism.

• If mounting components elsewhere, check for

clearance around rear-deck torsion bars, glove

box or other structural elements.

• Do not mount components where they will get

wet.

Figure 2. Use this template to flush-mount a

Kappa10.1t tweeter.

T IWEETER NSTALLATION

Figure 1. After installing the surface-mount plate, push the

Kappa10.1t onto the mounting plate to snap it into place.

DIAM. = 1.56"

(39.5 mm)

OPENING FOR

FLUSH-MOUNT

CUP

TRIM RING EDGE
