kappa series

40.2cs, 50.2cs,

60.2cs 652.2cs&

Thank you for purchasing an Infinity Kappa Series 2-Way

Component System. We’ve organized this manual to make your instal-

lation as simple and trouble-free as possible. Please read it thoroughly

before proceeding. Remember to keep your sales receipt with this

manual in a safe place so both are available for future reference.

instructions

- 2 -

IMPORTANT: Installation of automotive stereo

components can require extensive experience

with a variety of mechanical and electrical proce-

dures. Although these instructions explain how to

install a Kappa Series 2-Way Component System

in a general sense, they do not show the exact

installation method for your particular vehicle. If

you do not feel you have the experience, do not

attempt the installation yourself, but instead ask

your authorized Infinity car-audio dealer about

professional installation options.

WARNING: Playing loud music in an automobile

can permanently damage your hearing, as well as

hinder your ability to hear traffic. The maximum

volume levels achievable with Infinity speakers,

combined with high power amplification, may

exceed safe levels for extended listening. We

recommend using low volume levels when

driving. Infinity accepts no liability for hearing

loss, bodily injury or property damage as a

result of use or misuse of this product.

S PPEAKER LACEMENT

Kappa speakers are designed to be easily

installed in stock speaker locations. While mount-

ing your speakers in the original factory locations

will, in most cases, provide excellent sonic

results, the best-sounding installations are a

result of adherence to a few basic rules.

• For the most spacious stereo image, place the

left and right speakers as far apart as possible.

• For enhanced center image, place the left and

right speakers so they are equidistant from the

listening position. If possible, try to place them

as far forward as possible.

• For best treble response when tweeters are

flush-mounted in the I-Mount™(pat. 5,859,917),

aim them at the listening position by adjusting

the tweeter angle in the cup, tightening the

small metal locking nut behind the assembly,

and rotating the entire assembly in its mount-

ing location before tightening the large plastic

locking nut behind the panel (see Figure 6,

page 3).

INSTALLATION ARNINGS ANDW TIPS

• Always wear protective eyewear when using

any tools.

• Turn off all audio systems and other electrical

devices before you start. Disconnect the (–)

negative lead from your vehicle’s battery.

• Keep components in their package until final

installation. When moving a speaker, always

rest it with the cone or dome facing up. Never

use force to install any speaker.

• Check clearances on both sides of a planned

mounting surface before drilling any holes or

installing any screws. Remember that the

screws can extend behind the surface.

• At the installation sites, locate and make a note

of all fuel lines, hydraulic brake lines, vacuum

lines and electrical wiring. Use extreme caution

when cutting or drilling in and around these

areas.

CAUTION: In some cars, fuel tanks may be

located directly beneath the rear deck. Check

for adequate speaker basket clearance before

considering this location!

• Before drilling or cutting holes, use a utility

knife to remove unwanted fabric or vinyl, to

keep material from snagging in a drill bit

or saw.

• For door installations, check the clearance with

the windows throughout the range of the win-

dow’s travel, and verify that a mounted speaker

will not interfere with the window crank or

power-window mechanism.

• If mounting components elsewhere, check for

clearance around rear deck torsion bars, glove

box or other structural elements.

• Do not mount components where they will

get wet.

C IROSSOVER NSTALLATION

squeeze

sides

and lift

cover

P as s iv e C ross ov er S ystem

40.2 XP

Figure 1
