Side 1/4

Thank you for purchasing Infinity’s Kappa Series multi-

element automotive loudspeakers. We’ve organized this manual to

make your installation as simple and trouble-free as possible. Please

read it thoroughly before proceeding. Remember to keep your sales

receipt with this manual in a safe place so both are available for

future reference.

A P PA

ERIES

42.1i, 52.1i, 62.1i, 63.1i, 652.1i, 692.1i,

693.1i, 32.1cf, 462.1cf, 572.1cf

I N S T R U C T I O N S

- 2 -

IMPORTANT: Installation of automotive stereo

components can require extensive experience

with a variety of mechanical and electrical proce-

dures. Although these instructions explain how to

install Kappa Series speakers in a general sense,

they do not show the exact installation method

for your particular vehicle. If you do not feel you

have the experience, do not attempt the installa-

tion yourself, but instead ask your Authorized

Infinity Car Audio Dealer about professional

installation options.

WARNING: Playing loud music in an automotive

environment can permanently damage your hear-

ing, as well as hinder your ability to hear traffic.

The maximum volume levels achievable with

Infinity speakers, combined with high power

amplification, may exceed safe levels for

extended listening. We recommend using low

volume levels when driving. Infinity accepts no

liability for hearing loss, bodily injury or property

damage as a result of use or misuse of this

product.

S PPEAKER LACEMENT

Kappa speakers are designed to be easily

installed in stock speaker locations. While mount-

ing your speakers in the original factory locations

will, in most cases, provide excellent sonic

results, the best sounding installations are a

result of adherence to a few basic rules.

• For the most spacious stereo image, place the

left and right speakers as far apart as possible.

• For enhanced center image, place the left and

right speakers so they are equidistant from the

listening position. If possible, try to place them

as far forward as possible.

• For best treble response, aim each speaker

so that its sound waves will converge at the

listener’s ears. This will take advantage of the

tweeter’s directional nature and provide the

best on-axis high-frequency response.

• For models with UniPivot™ tweeters (52.1i,

62.1i, 652.1i, 692.1i and 572.1cf) aim the tweeter

at the listening position by rotating it up to 355

degrees.

INSTALLATION ARNINGS AND IPSW T

• Always wear protective eyewear when using

any tools.

• Turn off all audio systems and other electrical

devices before you start. Disconnect the (–) neg-

ative lead from your vehicle’s battery.

• Keep speakers in their package until final instal-

lation. When moving a speaker, always rest it

with the cone or dome facing up. Never use

force to install any speaker.

• Check clearances on both sides of a planned

mounting surface before drilling any holes or

installing any screws. Remember that the

screws can extend behind the surface.

• At the installation sites, locate and make a note

of all fuel lines, hydraulic brake lines, vacuum

lines and electrical wiring. Use extreme caution

when cutting or drilling in and around these

areas.

CAUTION: In some cars, fuel tanks may be

located directly beneath the rear deck. Check for

adequate speaker basket clearance before

considering this location!

• Before drilling or cutting holes, use a utility

knife to remove unwanted fabric or vinyl, to

keep material from snagging in a drill bit or

saw.

• For door installations, check the clearance with

the windows throughout the range of the win-

dow’s travel, and verify that a mounted speaker

will not interfere with the window crank or

power window mechanism.

• If mounting speakers elsewhere, check for clear-

ance around rear deck torsion bars, glove box

or other structural elements.

• Do not mount speakers where they will get wet.

Mounting Ears Removed

Two-Screw Mounting Configuration

Figure 2

INSTALLATION

Figure 1

Grille

Screen

Trim Ring

Car Door

Typical installation of the Kappa i Series speakers

with grilles as shown in Figure 2.

NOTE:The cf Series is designed for direct replace-

ment of factory speakers. Therefore they do not

contain the grilles and trim shown in Figure 2.

Installation of these models simply entails

reversing the steps taken to remove the original

speakers.
