Quick Installation Guide: How to get started?

Installation guide for innovaphone gateways and analogue adapters

innovaphone® AG, Böblinger Straße 76, 71065 Sindelfingen, Germany, Tel +49 7031 7 30 09-0, Fax +49 70 31 7 30 09-99

Errors and omissions excepted. All information, technical specifications and delivery times may be subject to change.

Set-up

When installing the device, please ensure it has sufficient ventilation, especially when the

device is installed in a closed cabinet. A special frame for 19” racks is available for

mounting two devices in one height unit. (product number 01-00999-001).

The device is only designed for use in dry rooms. Operating temperature is between 0 °C

and 40 °C with relative humidity of 10 % to 90 % (non-condensing). Hardware problems

can occur if the device is used in environments outside of this range. Please wait until the

device has adapted to the new environment before carefully putting the device into

operation.

Reduce the risk of accidents by laying the connecting cables carefully. Take care not to

bend, pull or put too much mechanical strain on all connecting cables.

Power supply

The power supply may, depending on the device type, have an internal or external mains

adapter. All innovaphone devices can also use Power over Ethernet (PoE) according to

IEEE 802.3af to get their electricity over the network. All types of electrical power can be

connected simultaneously and can replace each another if one power source fails.

When used with the mains adapter, the device is designed for an AC network with 100V-

240 V and 50 Hz. Never attempt to connect the device to other mains supplies. Use only

the mains adapter and power cable supplied. Other mains adapters and power cables

could damage the device. Please note! Special cables that can be ordered from

innovaphone are necessary for Switzerland, Great Britain and Italy. Please consult the

innovaphone price list for further details.

The device is switched on as soon as it is connected to the power supply and the LED

labelled Ready is illuminated. The device cannot be operated if the network fails. However,

the device maintains its settings.

Configuration

Use the Ethernet cable to connect the device to your network. Device configuration takes

place over a web browser using the device’s IP address.

There are various different ways of putting a device into operation and assigning an IP

address to it. Initially, the device will try to establish a connection to the DHCP server. If

this is possible and the device is in the same subnet, the NetBIOS method can be used.

The NetBIOS name is made up of the device model and part of the MAC address as

follows: IPXXX-YY-YY-YY, whereby the symbol X should be replaced with the device

model name and the symbol Y with the last three Byte of the gateway's MAC address(e.g.

IP6010-06-15-B2 or IP28-05-14-B1). The MAC address can be found on the sticker at the

back of the device.

If your device is in a different subnet, access can take place over the IP address. You can

determine which IP address has been assigned with the help of the MAC address from the

DHCP lease.

If it is not possible to set up a connection to a DHCP server, it is necessary to short press

the Reset button. This assigns a static IP address to both Ethernet ports – either

192.168.0.1 (ETH0) or 192.168.1.1 (ETH1). Attention: the computer has to be in the

same subnet.

Quick Installation Guide: How to get started?

Installation guide for innovaphone gateways and analogue adapters

innovaphone® AG, Böblinger Straße 76, 71065 Sindelfingen, Germany, Tel +49 7031 7 30 09-0, Fax +49 70 31 7 30 09-99

Errors and omissions excepted. All information, technical specifications and delivery times may be subject to change.

Wizard

Your innovaphone device's configuration is password protected. As soon as you have

entered the NetBIOS_name or the IP address in the browser, a login window opens

automatically. You must enter your user name and password here. The user name is

admin and the password is ip6010, ip800, ip305 or ip24, dependent on the device. The

browser goes to the configuration wizard the first time it is accessed. The wizard will help

you in the initial configuration steps providing support for the essential basic configuration

of your innovaphone device.

On the first page of the Wizard you can define the log-in parameters for the network IP

address, network mask, standard gateway and VLAN ID. If these fields are left empty, the

gateway is configured as a DHCP client. To avoid unauthorised access you should also

change the configuration log-in details on this page.

The second page of the wizard enables the license file to be imported. If you do not have

a current license, it is possible to input this at a later date in the web interface

general/license area.

If you are configuring a gateway for operating an innovaphone PBX, you can now use the

wizard to undertake initial configurations on the PBX. For example, you can determine the

master / slave mode for a device. In the master mode you assign a system name for all

the installations in the PBX network and an own name for this PBX. It is also possible to

assign a prefix for an external line and to set up the first subscribers. In the slave mode

you enter the log-in parameters for the master. The next pages show how to configure

the different interfaces on your device and a trunk access via SIP.

The settings are again shown to you on the last page of the wizard. Please check them.

You are able to go back and make changes to settings made on previous pages. End the

Wizard by pressing Finish. After the reset you will be forwarded to the device’s general

administration.

Further information on the configuration of your gateway can be found under

http://wiki.innovaphone.com.

Reset

There are three ways of resetting an innovaphone gateway or analogue adapter.

A short reset reboots the device. The reset button should not be pressed for longer than

one second. The configuration data are retained.

Press the reset button for ca. 2 to 3 seconds for the medium reset. This does not reboot

the device, instead the device is transferred to TFTP mode, in order to execute commands

over gwload (see innovaphone Wiki). There are two ways to leave the TFTP mode: either

unplug the device for a few seconds or perform a short reset.

In order to perform a long reset, it is necessary to press the reset button for longer than

5 seconds. This deletes the flash memory and restores the factory settings. The device

then goes into TFTP mode. This can take up to 60 seconds depending on the flash

memory size and usage – the LED on the device flashes until the memory has been

completely deleted. Please do not reset the device while this is in progress and do not

remove the power supply.

Attention! Please be careful how long you press the reset button to avoid restoring the

factory settings by mistake!

Produkt Specifikationer

Mærke:	Innovaphone
Kategori:	Ikke kategoriseret
Model:	IP800
Vægt:	1050 g
Wi-Fi:	Ingen
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Driftstemperatur (T-T):	0 - 45 °C
Intern hukommelse:	32 MB
Dimensioner (BxDxH):	210 x 184 x 32 mm
Kabelteknologi:	10/100Base-T(X)
Netværksstandarder:	IEEE 802.3af
VPN-support:	PPTP
Understøttede netværksprotokoller:	PPPoE, NAT, H.323-NAT, RSTP, NTP
Firewall sikkerhed:	Ja
LED-indikatorer:	Ja
Indgangsspænding:	100 - 240 V
Grænseflade:	ISDN BRI
Indgangsstrøm:	0.2 A
Flashhukommelse:	8 MB
Voice codecs:	CNG, G.711, G.729ab
Strøm over Ethernet (PoE):	Ja
Indgangsfrekvens:	50 Hz
Administrationsprotokoller:	SNMP
Understøttede protokoller:	H.323 v5\r\nSIPv2 (RFC 3261)\r\nSIP over UDP, TCP, TLS, SIPS\r\nRTP, SRTP, RTCP\r\nT.38
Dataoverførselshastighed:	0.1 Gbit/sek.
Understøttede dataoverførselshastigheder:	10, 100Mb/s
Godkendelsesmetode:	802.1x
