Order Number: 330566-002US
Intel® Solid-State Drive DC P3700 Series
Product Specification
Capacities: 400GB, 800GB, 1 TB, 2TB .6
Components
– Intel® 20nm MLC NAND Flash Memory
Form Factors
– 2.5-inch Form Factor
15mm Z-height
8639-compatible connector
– AIC Form Factor
Half-height, Half-length
Single slot p1-x4 connector
PCIe* Gen3 X4
Performance1,2
– Seq R/W: Up to 2800/ 00MB/s20 3
– IOPS Rnd 4KB4 70/30 : Up to 2 K R/W 65
– IOPS Rnd 4KB4 : Up to 46 K R/W 0/175
– Seq Latency (typ) R/W: 20/20µs
Operating System Support:
– Windows* Server 2012 R2, 2012,
2008 R2 x64
– RHEL* 6.5, 7.0
– UEFI 2.3.1
Reliability
– Uncorrectable Bit Error Rate (UBER):
1 sector per 1017 bits read
– Mean Time Before Failure (MTBF):
2 million hours
– T10 DIF protection
– Variable Sector Size: 512, 520, 528,
4096, 4104, 4160, 4224 Bytes
Compliance
– NVM Express* 1.0
– PCI Express Base Specification Rev 3.0
– Enterprise SSD Form Factor Version 1.0a
– PCI Express Card Electro-Mechanical
( ) Specification Rev 2.0 CEM
Certifications and Declarations
– UL*, CE*, C-Tick*, BSMI*, KCC*,
Microsoft* WHQL*, VCCI *
Power
– 2.5-inch: 3.3V and 12V Supply Rail
– AIC: 3.3V and 12V Supply Rail
– Enhanced power-loss data protection
– Active/Idle (TYP): Up to 25W/4W (TYP)
En rance Rating du
– Up to 36 PBW (Petabytes Written).5 5
10 Drive Writes/day (JESD219 workload)
Temperature Specification
– Operating:
AIC: to 55° C ambient with 0
specified airflow
2.5-inch: 0 to 35° C ambient,
0 to 70° C case with specified airflow
– Non-Operating6: -55 to 95° C
– Temperature monitoring (In-band and b y
way of SMBUS)
– Thermal throttling
Airflow
– AIC (55° C airflow towards IO bracket7)
4 GB: 200 LFM 00
800GB, 6TB, 2.0TB: 300 LFM 1.
– 2.5-inch (Airflow towards the connector)
4 GB: 250/300 LFM (25/35° C) 00
800GB: 350/500 LFM (25/35° C)
1. 50/ 006TB, 2 :4TB 6 LFM (25/35° C)
Weig ht
– AIC: 400/800GB up to 185gm
1.6TB 2TB up to 195gm ,
– 2.5-inch 400/800GB up to 115gm :
1.6TB, 2TB up to 125gm
Shock
– 2.5-inch: 1,000 G/0.5msec
– AIC: 50 G Trapezoidal, 170 in/s
Vibration
– Operating: 2. G17 RMS (5-700Hz)
– Non-Operating: 3.13 GRMS -800Hz) (5
Altitude (Simulated)
Operating: -1,000 to 10,000 ft
Non-Operating: -1,000 to 40,000 ft
Product Ecological Compliance
– RoHS
1. Performan value vary by capacity and form factorce s
2. Performance specifications apply to both compressible and incompressible data
3. MB/s = 1,000,000 bytes/second
4. 4KB = 4,096 b es; 8KB = 8,192 bytes yt
5. 1PB = 1015 Bytes
6. Please contact your Intel representative for details on the non-operating temperature range
7. Airflow out of server through PCIe Card Slot
