16-Port Fast Ethernet PoE+ Switch

8 x PoE IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE) ports, 8 x Standard RJ45

Ports, Endspan, 19" Rackmount

Part No.: 560771

Deliver Power over Ethernet to remote devices.

The Intellinet PoE+ Oce Switch, Model 560771, is equipped with 16 10/100Base-TX Fast

Ethernet ports, eight of which support 802.3af/at Power over Ethernet (PoE/PoE+). Besides

being a versatile network LAN switch, it also provides a Power over Ethernet option that

supplies power injection to 802.3af/at-compliant devices, such as IP phones, wireless

access points and network cameras.

Power over Ethernet 802.3at

The Intellinet 16-Port Fast Ethernet Rackmount PoE+ Switch supports the IEEE 802.3at protocol and is designed to inject

up to 30 watts of power per port*. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no

additional power, thus eliminating the time and expense of electrical rewiring and minimizing the unsightly clutter caused

by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is

supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well-protected.

For devices that are not 802.3at/af compliant (legacy wireless access points or network cameras), we suggest the use of

an Intellinet PoE/PoE+ Splitter.

Optimum Performance

Besides providing Power over Ethernet functionality, the PoE Oce Switch has some very impressive features as a

switch. For starters, the auto features of this switch make installation Plug and Play and hassle free. No conguration is

required. Auto-MDI/MDI-X crossover on all ports eliminates the need for crossover cables for connection to another

switch or hub. Auto-negotiation on each port senses the link speed of a network device (either 10 or 100) and intelligently

adjusts for compatibility and optimal performance.

* Total PoE budget for this switch is 58 watts. Per-port average power distribution is 7.25 watts; maximum per-port power

usage cannot exceed 30 watts.

Features:

Save time and money by delivering data and power via existing network cables

IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports

8 integrated PoE ports (Ports 9 to 16) with a power output of up to 30 watts per port*

PoE power budget of 58 watts

All RJ45 ports with Auto-MDIX and NWay auto-negotiation support

10/100 auto-sensing ports automatically detect optimal network speeds

Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access

points, VoIP phones, IP cameras)

Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage

protection

Store and forward switching architecture

For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.

Full/half duplex operation

IEEE 802.3x ow control for full duplex

Zero packet loss backpressure ow control for half duplex

Packet ltering/forwarding rates: 148,800 pps (100 Mbps), 14,880 pps (10 Mbps)

Supports 4096 MAC address entries

156 kBytes buer memory

LEDs for power, link/activity and PoE

Three-Year Warranty

Specications:

Standards

• IEEE 802.3 (10Base-T Ethernet)

• IEEE 802.3af (Power over Ethernet 802.3at Type 1)

• IEEE 802.3at (Power over Ethernet 802.3at Type 2)

• IEEE 802.3u (100Base-TX Fast Ethernet)

• IEEE 802.3x (ow control, full duplex mode)

General

• Media support:

- 10Base-T Cat3, 4, 5 UTP/STP RJ-45

- 100Base-TX Cat5 UTP/STP RJ-45

• Ports: 16 RJ45 10/100 Mbps (8 PoE ports)

• Packet lter/forwarding rate:

- 148,800 pps (100 Mbps)

- 14,880 pps (10 Mbps)

• Certications: FCC Class A, CE

LEDs

• Power

• Link/activity for 10 and 100 Mbps

• PoE (Port 9 to 16)

Power

• Input: 100 – 240 V AC, 50 – 60 Hz

• Power consumption: 65 watts (maximum)

Environmental

• Metal housing, 19 in., 1 u

• Dimensions: 440 (W) x 220 (L) x 44 (H) mm (17.3 x 8.6 x 1.7 in.)

• Weight: 3.65 kg (8 lbs.)

• Operating temperature: 0 – 40°C (32 – 104°F)

• Operating humidity: 10 – 90% RH, non-condensing

• Storage temperature: -20 – 90°C (-4 – 194°F)

Package Contents

• 16-Port Fast Ethernet PoE+ Switch

For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
