48-Port Gigabit Ethernet Web-

Managed Switch with 4 SFP

Ports Quick Install Guide

Model 561334

INT- 561334_QiG-0516_REV- 5.01

Important: Read before use. • Importante: Leer antes de usar.

intellinetnetwork.com

48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports English

This guide presents the basic steps to set up and operate this device. For detailed

instructions and specications, refer to the user manual enclosed with this product

or at intellinetnetwork.com.

Placement

Prior to use, it is recommended that the switch be placed/positioned:

• On a level surface that can support the weight of the switch

(and any other items that need to be considered);

• With a minimum of 25 mm (approx. 1”) of clearance on the top and sides

for adequate ventilation;

• Away from sources of electrical noise: radios, transmitters, broadband ampliers, etc.;

• Where it cannot be aected by excessive moisture.

The switch includes brackets and screws for optional rack mounting.

1. Disconnect any cables from the switch.

2. Position a bracket over the mounting holes on one side of the switch

and secure it in place with screws.

3. Repeat Step 2 on the other side of the switch.

4. Position the switch in the rack and screw the brackets to the rack.

5. Reconnect any cables.

Connections

• All ports on the switch support Auto-MDI/MDI-X functionality, so you can use

straight or crossover UTP/STP cables to connect the RJ45 ports to PCs, routers,

hubs, other switches, etc.

• Use the included power cable to connect the receptacle on the back of the switch

to a power outlet, and conrm that the Power LED lights.

Basic Web-Based Browser Management

1. Open your Web browser.

2. Enter “http://” and the IP address of the switch in the Address eld.

The default management IP address is 192.168.2.1.

3. Press <Enter> to display the login screen. In the Username eld, enter “admin”;

in the Password eld, enter “1234.” Click OK.

2English

Produkt Specifikationer

Mærke:	Intellinet
Kategori:	Ikke kategoriseret
Model:	561334
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	440 mm
Dybde:	335 mm
Højde:	44 mm
Vægt:	4200 g
Brugervejledning:	Ja
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-20 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Driftstemperatur (T-T):	0 - 40 °C
Sikkerhedsalgoritmer:	SNMP, SSH-2
Husmateriale:	Metal
Kabler inkluderet:	Vekselstrøm
Certificering:	FCC A, CE
Strømforbrug (maks.):	36 W
Netværksstandarder:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Understøttede netværksprotokoller:	IPv4, IPv6
Webbaseret administration:	Ja
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Activity, Link, Power, Speed
Harmoniseret systemkode (HS):	85176990
Fiber optisk strømstik:	MiniGBIC
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ingen
Switch-type:	Administreret
Switch lag:	L2
10G understøttelse:	Ingen
Spanning tree protokol:	Ja
Auto MDI/MDI-X:	Ja
VLAN understøttelse:	Ja
Flowkontrol support:	Ja
Port-spejlning:	Ja
Link aggregering:	Ja
Kobber ethernet kabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Broadcast stormkontrol:	Ja
Vituelle LAN funktioner:	Tagged VLAN, Port-based VLAN
Basis omskiftning RJ-45 Ethernet porte, antal:	48
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
IGMP snooping:	Ja
Opbevar-og-frem:	Ja
MAC adresselabel:	8000 entries
Switch kapacitet:	104 Gbit/sek.
Jumbo Frames support:	Ja
Jumbo rammer:	9000
Multicast-understøttelse:	Ja
Antal SFP modulslots:	4
Begrænsning af hastighed:	Ja
Auto-forhandling:	Ja
Pakke bufferlager:	1.5 MB
Rack monteringskit:	Ja
Understøttede kabeltyper:	Cat3, Cat4, Cat5, Cat5e
Pakke videresendelsesrate (1 Gbps):	1488000 pps
Pakke videresendelsesrate (100 Mbps):	148800 pps
Pakke videresendelsesrate (10 Mbps):	14880 pps
