ALC-DT-BT-WH Dual Tech In-Wall

Occ/Vac Sensor

WARNINGS/SAFETY

WARNING

Risk of Fire or Electric Shock

• Disconnect power at the circuit breaker(s) or disconnect switch(es) before installing or

servicing.

• Installation and/or wiring must be in accordance with national and local electrical code

requirements.

• Only use copper conductors rated 105°C minimum.

• For INDOOR USE ONLY.

Type 1 action, Operating Control, Pollution degree PD2, Impulse Voltage 4000V

INSTALLATION

1. Turn off power to the controlling circuit.

2. Connect wires as shown in wiring diagram.

3. Attach ALC-DT-BT-WH to electrical box with provided screws.

4. Install wall plate

5. Turn power ON to controlling circuit.

6. Once powered, a Green LED indicator light will start ﬂash for 1

minute..

COMPLIANCE

This device complies with part 15 of the FCC. Operation is subject to

the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

FCC NOTE: The manufacturer is not responsible for any radio or TV

interference caused by unauthorized modiﬁcations to this equipment.

Such modiﬁcations could void the user’s authority to operate the

equipment.

NOTE: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Important note: To comply with the FCC RF exposure compliance

requirements, no change to the antenna or the device is permitted.

Any change to the antenna or the device could result in the device

exceeding the RF exposure requirements and void user ’s authority to

operate the device.

This Class B digital apparatus complies with ICES-005 of Canada.

NOTES: For Programming instructions please visit www.Intermatic.

com. The Arista App is available on Apple App and Google Play stores.

(Search for Arista by Intermatic)

Bluetooth Operations have a maximum range of 100’.

PRODUCT OVERVIEW

The ALC-DT-BT-WH is a Dual Technology (PIR and Ultrasonic) Sensor

designed for use with the ARISTA Lighting Controls System by

Intermatic and will control lighting based upon occupancy/vacancy. If

the space is conﬁgured for Occupancy and movement is detected, the

sensor informs the ARISTA controller(s) in the space and the lights will

illuminate. The lights will turn off after the ARISTA controller(s) deem

the space vacant and the timeout period completes. If the space is

conﬁgured for Vacancy, the ARISTA controller(s) in the space will only

react when they are manually activated. The lights will turn off after

the ALC-DT-BT-WH deems the space vacant and the timeout period

completes. The ALC-DT-BT-WH also utilizes a built-in switch that can

be used as a manual override to the programmed ARISTA controller(s).

RATINGS

Operating Voltage - 120-277 VAC, 50/60 Hz

Operating Temperature - 0° - 55° C (32° - 131° F)

Dimensions - 2 3/4” H x 1 3/4” W x 1 2/3” D
