Side 1/4

• Disconnectpoweratthecircuitbreaker(s)

 ordisconnectswitch(es)beforebeginning

 installationandbeforeservicing.

• Morethanonecircuitbreakeror

 disconnectswitchmayberequiredto

 de-energizetheequipmentbefore

 servicing.

• Donotusethemanualoffpositionofthe

 timerforequipmentservice.Always

 disconnectthepoweratthecircuit

 breaker(s)ordisconnectswitch(es).

TheCT2000Timerprovidesrepetitivecycling

forfans,misters,foggers,feeders,process

equipmentandothershortcycleapplications.

Thetimerisfieldadjustableforapercentage

oftotalcycleduration.CycleTimes

(durations)canbesetfrom30secondstoa

maximumof4hrs.withONdurationsfrom1

secondupto232minutes.Thepercentageof

totalONtimeisselectedusingtherotary

knob,whichprovides30separatedetent

positionsforpreciseselection.Indicatorsare

providedforeachCycleTime.CycleTimes

are:30seconds,1,3,5,10,or30minutes,1

or4hours.

Powerinputtothetimermaybeanystandard

120or240volt60HzACsupply.Aninternal

switchallowsquickandeasyconfiguration.

NOTE:Timerisshippedin240Vposition.

Thetimerenclosureincludestwomounting

holeson5-3/16”centersandaknockoutfor

1/2”conduitconnection.

Safety Precautions

•Theconnectionandinstallationof 

electricaldevicesmayonlybecarried

outbyaqualifiedelectrician.

•Interventionsinandchangestothe 

devicewillvoidthewarranty.

•Observeyournationalregulationsand 

therespectivesafetyprovisions.

INSTALLATION

1.Determinedesiredmountinglocation.

2.Loosencoverscrew,liftoffcoverand

disconnectthecircuitboardcable.

3.Mounttimersecurelyusing1or2screws

ofappropriatelength,with#8mindia.

(screwsnotsupplied)Useadrilltoopenthe

lowerholeinbaseifnecessary.Thelower

holemustbesecuredwithascrewafter

opening.Tightenscrewsasrequired,butdo

notovertighten.

4.Connectconduithubstoconduitbefore

connectingthehubstothebracket.After

insertinghubsintobracket,carefullytighten

hublocknut.Donotover-torque.

5.WireinaccordancewithNationalandLocal

Codes.Makesurethewiringconnectionsfor

ClockPowerareasshownfor120or240

voltsACinput.PositionSW1intheproper

positionfor120Vor240VClockPower

operation.(Timerisshippedin240Vposition.)

6.Makeloadconnectionsasshown.Note

thattheredwiresareconnectedtoisolated

relaycontactstoallowtheloadtobe

poweredfromadifferentcircuit/voltagethan

the“ClockPower”.Youmustsupplypower

tooneoftheRedwiresandconnecttheother

Redwiretoyourload.

7.Grounding:Terminateallgroundwiresto

thegroundlug/screwonthebracket.

8.Reversestep2toreplacecover.Besureto

reconnectthecircuitboardconnector.Secure

coverwithcoverscrew;donotovertighten.

9.Restorepowertotimeratdisconnector

breakerpanel.

CYCLE TIME SETUP

ToProgramCycleTimer:

1.Turnknobuntilthe“SelectCycleTime”

arrowalignswithtriangletochoosetotal

cycletime.

2.PushtheSelectCycleTimebuttontoscroll

throughcycletimes.

3.Pushandholdbuttontosavedesiredtime

(LEDBlinks).

4.Turnknobuntildesiredpercentageof

cycletimealignswithtriangle.

Turningknobtoany%positionwillinitiatea

newONperiodfortheselectedCycleTime.

Higherpercentagepositionsprovide

additionalONtime,andlessOFFtime,as

shownbelow.

ApermanentONandapermanentOFF

positionareprovidedtoallowmanual

overrideofthecycleatanytime.

DonotusethemanualOFFpositionfor

equipmentservice.Alwaysdisconnectpower

atthedisconnectswitch(es)orbreakerpanel.

TheOFFindicatorwillbesteadyREDinthe

OFFpositionandduringtheOFFportionof

thecycles.

TheONindicatorwillbesteadyGREENinthe

ONpositionandduringtheONportionofthe

cycles.

TheyellowCycleTimeindicatorwillbeON

exceptwheninthepermanentONorOFF

positions.

CT2000 SERIES

CYCLE PERCENTAGE TIMER

  

Cycle Time Selector ON Time OFF Time

Duration Knob %

30sec. 10% 3sec. 27sec.

30sec. 50% 15sec. 15sec.

30sec. 80% 24sec. 6sec.

10min. 10% 1min. 9min.

10min. 50% 5min. 5min.

10min. 80% 8min. 2min.

1hour 10% 6min. 54min.

1hour 50% 30min. 30min.

1hour 80% 48min. 12min.

4hours 10% 24min.216min.

4hours 50%120min.120min.

4hours 80%192min.48min.

Risk of Electric Shock

WARNING

Risk of Electric Shock

WARNING

SPECIFICATIONS

InputVoltage:120VACor240VAC,60Hz

Thistimerhasanenvironmentaloperating

temperaturerangeof-10˚C(14˚F)to+60˚C

(140˚F).

Theinputisprotectedforupto6000volt

3000amppowersurges.

Overalldimensions:31/2inchesx65/8

inchesx31/4inches.

Voltage Load N.O.Contact

240VAC GeneralPurpose 20A

120VAC Motor 1HP

240VAC Motor 2HP

240VAC Tungsten 5A

240VAC PilotDuty  470VA

277VAC Ballast  10A

28VDC Resistive  20A

CLOCK

POWER

120/240

VAC

BLK

WHT

RED

LOAD

POWER

LINE

N/LINE

Upper

MountingHole

Lower

Mounting

Hole

SW1

120Vor240V

Circuit

Board

Connector

Ground

Screw

Location

SW1

120V 240V
