Specifications
Input
12VDC-24 VAC/VDC, 50/60 Hz (FM1D14-LV)
120-277 VAC, 50/60 Hz (FM1D14-AV)
Output
NO Contact
General Purpose: 15 A, 277 VAC
Tungsten: 1000 W, 120 VAC
Ballast : 8 A, 277 VAC
Electronic Ballast: 4.9 A, 120 VAC
Motor: 10 FLA, 60 LRA @ 250 VAC; ½ HP,
120 VAC; 1 HP, 250 VAC
NC Contact
General Purpose: 15 A, 277 VAC
Resistive: 12 A, 24 VDC
Ballast : 8 A, 120 VAC
Motor: 10 FLA, 60 LRA @ 250 VAC; ½ HP,
120/240 VAC
Operating Temperature: 5˚ F to 135˚ F (-15˚ C to 55˚ C)
Carry-over: 2500 hours fully charged
Description
This manual provides installation and
programming instructions for the FM1D14
series timer.
Timer
Day
h+ m+
+1h
OVR
Reset
Figure 1. FM1D14 Timer
1.26 in.
[32 mm]
.14 in
[3.56 mm]
1 2 3 4
5
2.36 in.
[60 mm]
.14 in
[3.56 mm]
2.36 in.
[60 mm]
2.13 in.
[54 mm]
Figure 3. Connect FM1D14 Wiring (Front View Shown).
COM NCNO
M
1
2
3 4
5
LOAD
12 VDC
(+) (-)
Typical Wiring (12 VDC Application)
COM NCNO
M
1
2
3 4
5
LOAD
24 VDC
(+) (-)
Typical Wiring (24 VDC Application)
COM NCNO
1
2
3 4
5
LOAD
24-277
VAC
L1 L2/N
Typical Wiring (24-277 VAC Application)
COM NCNO
M
1
2
3 4
5
L1 L2/N
NO
(Dry Contact)
NC
(Dry Contact)
M
+
-
+
-
FM1D14 Series 24-Hour/7-Day Time Switch Operation and User Instructions
• Disconnect power prior to installation.
• Connect FM1D14 wiring in accordance with all applicable national and local
electrical code requirements.
Risk of Fire or Electric Shock
WARNING
Setting the Time of Day
Follow this procedure to set the time of day and day of the week.
1. Press and release the button with a blunt object to reset the unit. Reset
The timer screen ashes.
2. Press and hold and h+ simultaneously to access the 12:00 AM
screen.
3. Take one of these actions.
If… Then…
Your time zone currently is in
Daylight Saving Time,
Press the +1h button.
Go to step 4.
Your time zone is not in
Daylight Saving Time,
Go to step 4 to set the
4. Press and hold and press repeatedly until you advance to the h+
current hour.
5. Press and hold and press repeatedly until you advance to the m+
current minute.
6. Press and hold and press repeatedly until you advance to the Day
current day.
Programming Events
To set ON/OFF event pair, set ON event and
then repeat procedure to set OFF event.
The timer enables up to 7 ON/OFF event
pairs.
1. Press the button. Dashed lines Timer
appear to indicate no event is set for
event 1.
2. Press to select the days of the week for the ON event. Day
NOTE: To set the ON event:
ON a Specic Day Select: The desired day
Every Day of Week Select: MO, TU, WE, TH, FR,
SA, SU
Every Weekday: Select: MO, TU, WE, TH, FR
Every Weekend: Select: SA, SU
Monday through Saturday Select: MO through SAT
Monday, Wednesday, Friday Select: MO, WE, FR
MO
TU WE TH
FR SA SU
ON
Figure 2. FM1D14 Timer Dimensions
Mounting the FM1D14 Series Timer
The standard FM1D14 timer can be surface mounted inside a panel or ush
mounted. Mount the timer as required. Refer to the dimension drawing in
Figure 2.
Connecting the FM1D14 Series Timer Wiring
Follow this procedure to connect the FM1D14 timer wiring.
1. Make sure supply power is disconnected.
2. Check input and output ratings marked on timer to verify the product is
suitable for your supply voltage, load, and application.
3. Connect the FM1D14 wiring. See Figure 3 for reference.
LIMITED WARRANTY
Warranty service is available by either (a) returning the product to the dealer from whom the unit was purchased or (b) completing a warranty claim online at www.intermatic.com. This warranty is made by: Intermatic
Incorporated, 1950 Innovation Way, Suite 300, Libertyville, IL 60048. For additional product or warranty information go to: http://www.Intermatic.com or call 815-675-7000..
INTERMATIC INCORPORATED
LIBERTYVILLE, ILLINOIS 60048
www.Intermatic.com
Figure 4. Reset Button
Reset
Button
Timer
Day
h+ m+
+1h
OVR
Reset
Mode Timer Display Description
Auto ON
MO TU WE TH
FR SA SU
OVR
AUTO
ON
OFF
AM
PM
h
Appears when an
ON setpoint has
been triggered
Auto OFF
MO TU WE TH
FR SA SU
OVR
AUTO
ON
OFF
AM
PM
h
Appears when an
OFF setpoint has
been triggered
OVR ON
MO TU WE TH
FR SA SU
OVR
AUTO
ON
OFF
AM
PM
h
Indicates relay has
been overridden to
ON status
MO TU WE TH
FR SA SU
OVR
AUTO
ON
OFF
AM
PM
h
OVR OFF Indicates relay has
been overridden to
OFF status
158--02542
3. Press to scroll to the desired hour for ON event.h+
4. Press to scroll to the desired minute for the ON event.m+
5. Press to advance to the OFF event screen.Timer
6. Press to select the days of the week for the OFF event.Day
7. Press to scroll to the desired hour for the OFF event.h+
8. Press to scroll to the desired minute for the OFF event.m+
Take one of these actions.
If… Then…
You need to program another ON/
OFF event pair,
Press Timer to advance to the
next event ON screen and repeat
steps 2 through 8.
All the required ON/OFF events
are programmed,
Press to return main screen.
The procedure is complete.
NOTE: If events include or intersect with each other, each ON/OFF event
can be independently executed at the setpoint.
NOTE: If an ON event and OFF event occur at the same time, the
timer will run the OFF event.
Daily Operation
Below is an overview of the different operation modes for FM1D14.
If you want to modify the… Then…
Days of the week for
ON/OFF event,
Press repeatedly to scroll to Day
desired days of the week
Go to step 3.
Hour for ON or OFF event, Press to scroll to desired hour h+
Go to step 3.
Minute for ON or OFF event, Press to scroll to desired minute m+
Go to step 3.
3. Repeat steps 1 and 2 as needed to modify additional events.
4. When all the desired events are modied, press to conrm event
settings and return to the time of day screen.
Deleting an Event
Follow this procedure to delete an event.
1. Press to scroll to ON or OFF event you want to delete.Timer
2. Press to delete the event. Dashed lines appear in place OVR
of the time to indicate the event is deleted.
NOTE: If necessary, repeat this procedure to delete both ON and OFF
settings for the event.
3. When the modications are complete, press to return to time of day
screen.
Retrieving an Event
The timer enables deleted events to be retrieved. All deleted events can be
retrieved until a new event is programmed in place of event.
1. Press to scroll to the ON/OFF event you previously deleted. Timer
Dashed lines appear in place of the event time.
2. Press to retrieve deleted event. The event ON or OFF time replaces OVR
the dashed line indicating that the event is retrieved.
NOTE: If necessary, repeat this procedure to retrieve both ON and OFF
settings for the event.
3. When the modications are complete, press to return to time of day
screen.
Adjusting Daylight Saving Time
Press button to add the Daylight Saving Time hour to the current time or +1h
remove the hour to return to standard time.
NOTE: Do not perform this procedure if your area does not use Daylight
Saving Time.
Resetting the Timer
In case of a timer malfunction or to
delete all previous settings, the unit
can be reset.
To reset the timer, use a blunt pointed
object to press as shown in Reset
Figure 4. The timer resets and deletes
all the settings in the unit.
NOTE: To execute an ON/OFF status override, press the button on the OVR
timer to override an ON or OFF status. The override remains active until the
next programmed event.
Modifying an Event
Follow this procedure to review or modify an event.
1. Press to scroll to ON or OFF event you want to modify.Timer
2. Take one of these actions.
Overview of FM1D14 Power Loss Functions
In the event of a power loss, the FM1D14 does the following:
• Relay will be in the OFF state.
• Upon power restore, relay will go to the current programmed state.
