Side 1/3
ABRA Wi-Fi Smart Plug with
Bluetooth
®
Gateway
SH-ABSP-WH
Quick Installation and Setup Guide
Libertyville, Illinois 60048
www.intermatic.com
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined
by the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of
20 cm (7.875 inches) between the radiator and your body.
RF Exposure: A distance of 20 cm (7.875 inches) shall
be maintained between the antenna and users, and the
transmitter module may not be co-located with any other
transmitter or antenna.
Non-modification Statement:
Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate this equipment.
ISED Statement
This Class B digital apparatus complies with Canadian CAN
ICES-3(B).
Cet apparel numerique de la classe (B) est conforme a la
norme NMB-3(B)du Canada.
This device contains license-exempt transmitter(s) /
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s license-exempt RSS9s).
Operation is subject to the following two conditions:
This device may not cause interference.
This device must accept any interference, including
interference that may cause undesired operation of the
device.
This equipment complies with ISED RSS-102 radiation
exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum
distance of 20 cm between (7.875 inches) between the
radiator and any part of your body.
WARNINGS/SAFETY
WARNING
• Keep the device away from water, fire, humidity or
hot environments.
• Do not attempt to disassemble, repair, or modify
the device.
• To reduce the risk of electric shock, use only
indoors.
• Do not overload power outlets. This can result in
the risk of fire or electric shock.
• Completely insert the product into the power
outlet. Failure to do so may cause electric shock
and / or excessive heat resulting in fire.
• Unplug from the power outlet if it emits smoke,
has an abnormal smell, or makes an unusual
noise.
• Do not use the product if the casing has been
broken due to danger of electric shock.
• Never touch the product with wet hands.
RATINGS
Operating Voltage 120 VAC, 50/60 Hz
Rated Current 15 A
Max. Power Up to 1800 W
Wireless Type Wi-Fi + Bluetooth
®
radio
Temperature Range 14°F to 104°F (-10°C to 40°C)
GETTING STARTED
WARRANTY
Download the App
The Intermatic ABRA app is available on
Google Play and the App Store.
Follow the instructions to create your
account.
Insert the Smart Wi-Fi Plug into a receptacle.
Press the Power button to turn the Plug/Gateway ON and OFF.
Press and hold the Power button for 10 seconds to enter the
Pairing Mode, indicated by a flashing blue light.
Select “Add Device” to discover the Smart Plug/Gateway and
add it to your ABRA system.
Select the desired Room and re-name the Plug/Gateway if
you’d like. Tap “Done” when finished.
On the ABRA app Home Screen, scroll to the assigned room.
Find the Smart Plug/Gateway in the “Other Devices” section.
Tap inside the Device Tile to open the Smart Plug/Gateway
Control Panel.
The Smart Plug/Gateway will be recognized in a few seconds.
Tap “Add” to connect it to your ABRA system.
Your Wi-Fi name and password should be retained in the app,
enabling the Plug/Gateway to automatically join your Wi-Fi
network.
Plug Controls
Tap the “Socket” tab to turn the turn the plug on and off, set
timers and schedules, and change user preferences.
Gateway Controls
Tap the “Gateway” tab to add, view or modify ABRA
Bluetooth
®
devices like the ABRA Surface Switch and ABRA
Motion and Brightness Sensor.
Once the Plug/Gateway has been successfully added, tap the
“Edit” tool to assign it to a Room.
While the Smart Plug/Gateway is in the pairing mode, tap the
“+” sign at the upper right of the app.
Press & Hold
Flashing
Blue Light
Wi-Fi Smart Plug with Bluetooth
®
Gateway Control Panel Interface
ONE-YEAR LIMITED WARRANTY
Wi-Fi Smart Plug with Bluetooth
®
Gateway Control Panel Interface
Edit device
details
Mode: Gateway
Existing ABRA
Bluetooth
®
device(s)
Add ABRA Bluetooth
®
devices, incl. Surface
Switch, Motion and
Brightness Sensor
Power
monitoring
Mode: Socket
Create schedules
Countdown timer
ON/OFF control
User preferences
Full programming instructions can be found in the Intermatic
ABRA App Guide at intermatic.com/abra/resources.
Full programming instructions can be
found in the Intermatic ABRA App Guide
at intermatic.com/abra.
Warranties are available by either (a) returning the product
to the point of purchase or (b) completing a warranty claim
online at www.intermatic.com. This warranty is made
by Intermatic Incorporated, Warranty Department, 1950
Innovation Way, Suite 300, Libertyville, IL 60048.
For warranty or product information please visit 
www.intermatic.com or call us at 815-675-7000.
158--02684
