Superb Speaker Charging Dock
For N-Switch Lite/ N-Switch
Product Manual PG-9171
1.Type-C plug: Connect N-Switch console, use for
extracting the audio from console and charging;
2.Speaker1#: Diameter 31mm , 2W, hi-fi tone;
3.Speaker volume "-": Turn down the volume;
4.Product ON/OFF;
6.Indicator: Red, Blue; (Blue LED lit when turn on,
Red LED lit when charging and off after fully charged)
7.Speaker2#: Diameter 31mm , 2W, hi-fi tone;
8.TYPE-C port: External power connector, for
charging console/product simultaneously;
9.Built-in 3.5mm audio port;
10.3.5mm earphone connector(with two male
connector),length 50m,diameter 2.8mm;
Product appearance & connector
1. This product is a speaker holder which compatible
with N-Switch lite/ N-Switch console, fashion design,
simple operation;
2.This speaker is directly extracting the audio from
N-Switch lite/ N-Switch through Type-C plug, and
play the sounds from the speaker;
3.External 3.5mm audio connector, extracting the
audio devices with 3.5mm port (e.g. mobile), and play
the sounds from the speaker;
4.Built-in Li-battery, support to charge the product
and N-Switch lite/ N-Switch console simultaneously
through Type-C port;
11.USB charging cable, length 80cm flat cable(One
side is USB port to plug in computer or the adapter
with 5V, the other side is type-C connector),
Product Application:
1.Audio play function
①When the product is turned off, a gentle press
button and the indicator light will be always on. When
the product is turned on, hold down button and the
indicator light will be off and the product will be turned
off;
②Plug in N-Switch lite/ N-Switch console, the product
play the game sound of Switch console;
③Connect other audio devices (e.g. mobile) to the
speaker through audio cable,priority to play the sound
of the audio device with 3.5mm port;
④Adjust the volume through product "-"+""button;
⑤ Charge the speaker battery(5V/300mA) through
N-Switch lite/ N-Switch original adapter,Red led will be
always on when charging, the light will be off after fully
charged; Through Type-C cable to charge N-Switch
lite/ N-Switch simultaneously;
⑥This product simultaneously support to play sounds
from N-Swithc console/3.5mm audio devices while
charging the N-Switch console;
Product Operation
1.Type-C input voltage: DC/5V 100MHz
Charging current: 300MA
2.Battery: 300MA/3.7V, takes 2H to charge
3.Battery life: 2.0H
4.Output power:2*3W
5.Frequency response:90Hz-16KHz
6.External audio:AUX
7.SNR：80db
8.Distortion：0.1%
Product Electrical Parameters
1.This product only support 5V input and output;
2. Please do not store this product in wet or high-
temperature areas.
3. Dont knap, beat, drub, pierce, ortiy to
decompose this product, to avoid unnecessary
damage to the product;
4.Non professional personnel should not
disassemble the product, otherwise it will not be
covered in the after-safes warranty service.;
Notes
Product list
Manual*1 Speaker Charging Dock*1
Audio converter*1Charging cable*1
1110
2
8 9
1
7
345
6
魔音N-Switch Lite/N-Switch音箱支架
产品说明书 PG-9171
1.Type-C公插头：连接主机，用于提取主机音频
和给主机充电；
2.扬声器1#：直径31mm，2W，HI-FI音质；
3.音响音量调节“-”：音响音量减小键；
4.产品开/关机；
5.音响音量调节“+”：音响音量增加键；
6.指示灯：红色、蓝色；(开机蓝灯常亮，充电时
红灯常亮，充满指示灯灭)，边充边用时，红灯/蓝
灯同时亮；
7.扬声器2#：直径31mm，2W，HI-FI音质；
8.TYPE-C母座：外部电源输入接口，给主机/产
品同时充电；
产品外观及接口定义
1.产品为N-Switch lite/ N-Switch主机支架音响，外
形时尚，操作简单；
2.产品直接通过Type-C公插向N-Switch lite/
N-Swicth主机提取音频，然后通过音箱播放出来；
3.产品外引3.5mm音频母座，获取带有3.5mm音
频设备的音频(例如: 手机)，通过音
箱播放出来；
4.产品内置可充电锂电池，通过Type-C母座可以
同时为产品充电和N-Switch lite/ N-Switch主机充电；
9.产品自带3.5mm音频母座；
10.产品附带3.5mm耳机插头(两端公头)长50CM，
直径2.8MM；
11.产品附带USB充电线，长80CM 扁线(一端USB
母座，插电脑或者适配器5V，一端是Type-C公头)；
产品适用
1.音频播放功能
①关机状态下，短按 键，指示灯长亮，产品开机，
开机状态下，长按 键，指示灯熄灭，产品关机；
②将N-Switch lite/ N-Switch主机插入产品，产品
播放主机的游戏声音；
③将产品的音频线插入带3.5mm音频孔的设备(例
如：手机)，产品优先播放3.5mm孔输入的音频；
④通过产品“+”“-”键，可以调节音响的音量
大小；
2.产品充电功能
①外接N-Switch lite/ N-Switch原装适配器，可以
给产品内置电池充电(5V/300mA)，充电时红色指
示灯亮，充满电红色指示灯灭；同时通过Type-C
公头也可以给N-Switch lite/ N-Switch主机充电；
②产品边给N-Switch lite/ N-Switch主机边充电，
也可以边播放N-Switch lite/ N-Switch主机或3.5音
频口输入的音频；
产品操作说明
1.Type-C输入电压：DC/5V 100MHz
充电电流：300MA
2.锂电容量：300MA/3.7V 充电约2H满
3.续航时长：2.0H
4.输出功率：2*3W
5.频响：90Hz-16KHz
6.外接音源：AUX
7.信噪比：80db
8.失真度：0.1%
产品特性参数
1.本产品只支持5V供电；
2.请不要把本产品放在潮湿或高温地方存储；
3.不要敲击、摔打、棒打、刺穿、或试图去分解
本产品，以免对产品造成不必要的损害；
4.非专业人员请勿拆卸本产品，否则不在售后保
修服务内；
注意事项
产品清单
说明书 x1音箱支架 x1
音频转接线 x1充电线 x1
1110
2
8 9
1
7
345
6
Patent NO.: 2019307079840
专利号：2019307079840
