USER MANUAL

Advanced 2/4/8-Port DisplayPort Secure KVM Switch

SA-DPN-2S 2-Port Secure Single-Head DisplayPort KVM with Audio

SA-DPN-2D 2-Port Secure Dual-Head DisplayPort KVM with Audio

SA-DPN-2S-P 2-Port Secure Single-Head DisplayPort KVM with Audio and CAC Support

SA-DPN-2D-P 2-Port Secure Dual-Head DisplayPort KVM with Audio and CAC Support

SA-DPN-4S 4-Port Secure Single-Head DisplayPort KVM with Audio

SA-DPN-4D 4-Port Secure Dual-Head DisplayPort KVM with Audio

SA-DPN-4S-P 4-Port Secure Single-Head DisplayPort KVM with Audio and CAC Support

SA-DPN-4D-P 4-Port Secure Dual-Head DisplayPort KVM with Audio and CAC Support

SA-DPN-4Q-P 4-Port Secure Quad-Head DisplayPort KVM with Audio and CAC Support

SA-DPN-8S 8-Port Secure Single-Head DisplayPort KVM with Audio

SA-DPN-8D 8-Port Secure Dual-Head DisplayPort KVM with Audio

SA-DPN-8S -P 8-Port Secure Single-Head DisplayPort KVM with Audio and CAC Support

SA-DPN-8D-P 8-Port Secure Dual-Head DisplayPort KVM with Audio and CAC Support

Release Date: June 1st, 2021

SA-DPN-4S-P

1 2 3 4

CONSOLE

12VDC

AUDIO

K/M

AUDIO AUDIO AUDIO AUDIO

K/M K/M K/M K/M

CAC

CAC CAC CAC CAC

IN-1IN-2IN-3IN-4

DP IN1DP IN2DP IN3DP IN4DP OUT

TABLE OF CONTENTS

TECHNICAL SPECIFICATIONS___________________________________________________________

WHAT’S IN THE BOX?_________________________________________________________________

SECURITY FEATURES_________________________________________________________________

FRONT AND REAR____________________________________________________________________

INSTALLATION_______________________________________________________________________

CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER__________________________

CAC PORT CONFIGURATION____________________________________________________________

AUDITING: Dumping the Event Log via User Menu Options___________________________________

RESET: Restore Factory Default_________________________________________________________

LED’s BEHAVIOR_____________________________________________________________________

SYSTEM OPERATION__________________________________________________________________

TROUBLESHOOTING__________________________________________________________________

TECHNICAL SUPPORT_________________________________________________________________

LIMITED WARRANTY STATEMENT_______________________________________________________

Advanced 2/4/8-Port DisplayPort Secure KVM Switch 2

Produkt Specifikationer

Mærke:	IPGARD
Kategori:	Ikke kategoriseret
Model:	SA-DPN-4D-P
Bredde:	319.27 mm
Dybde:	169.92 mm
Højde:	68.58 mm
Vægt:	1905 g
Produktfarve:	Black, Blue
Indbygget skærm:	Ingen
HD-type:	4K Ultra HD
Opbevaringstemperatur (T-T):	-20 - 60 °C
Strømforbrug (typisk):	24 W
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	3840 x 2160 pixel
Strømkilde:	DC
Certificering:	NIAP PP 4.0, UL, CE, ROHS
DC-in-stik:	Ja
Understøttede Windows-operativsystemer:	Ja
Understøttede Mac-operativsystemer:	Ja
Understøttede Linux-operativsystemer:	Ja
Indgangsstrøm:	2 A
DisplayPort-version:	1.2a
Antal DisplayPorts:	10
Ekstern strømadapter:	Ja
Antal kontrollerede computere:	4
Tastatur porttype:	USB
Mus porttype:	USB
Video porttype:	DisplayPort
Lydforbindelse:	Ja
Konsol porte:	DisplayPort, USB B
Antal USB 2.0 Type-B porte:	8
Video båndbredde:	30 Hz
Antal konsol displayporte:	8
