OLED DISPLAYMODUL 16X2
Controllable via SPI, Parallel 6800 and 8080
1. GENERAL INFORMATION
Dear customer,
Thank you for purchasing our product. In the following, we will show you
which things should be noted during the use.
Should you encounter any unexpected problems, do not hesitate to
contact us.
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
2. INTERFACES
This display can be controlled by dierent interfaces. It is possible to
switch between these interfaces by re soldering resistors on the back of -
the display.
The display is delivered in 6800 Parallel.
Parallel
6800 8080
SPI
The components marked in black (marked with X in the table) are Don't
Care components. This means that it does not matter, where these com-
ponents are set.
SPI Parallel
6800 8080
SHL HHH
J68 / J80 J68 J80 X
PS H H L
CS L L Open
JCS X X Short
