KNX Observer 180

Standard / Universal

Ref.-no.: ..3180../..3180-1A..

Operating Instructions

Observer 180

1. System Information

This device is a product of the instabus EIB system and complies with

EIBA directives.

Detailed technical knowledge obtained in instabus EIB training courses is

a prerequisite to proper understanding.

The functionality of this device depends on the software.

Detailed information on loadable software and attainable functionality as

well as on the software itself may be taken from the manufacturer’s

product database.

Planning, installation and commissioning of the unit are performed by

means of EIBA certified software.

2. Installation Instructions

All attachment models are plugged onto an instabus bus coupler.

Instructions on how to fit and install a bus coupler can be obtained from

the technical documentation.

3. Safety warnings

Caution: The installation and assembly of electrical equipment may

only be carried out by a skilled electrician.

4. Function

This user module is designed for interior application. It responds to

thermal movements released by persons, animals or objects and

transmits corresponding telegrams to the instabus.

The device must be fitted at the opposite installation height (1.10 m or

2.20 m), depending upon the cap lens type.

Stand: Jan-08 825 588 03

KNX Observer 180

Standard / Universal

Ref.-no.: ..3180../..3180-1A..

1 Lens for 2.20 m and 1.10 m installation height.

2 Lens for 1.10 m installation height.

Detection Field Pictorial Schematic

Cap lens for 1.10 m installation height.

Size of detection field:

10 m x 12 m.

Details refer to an installation height of 1.10 m.

Detection Field Pictorial Schematic

Cap lens for 2.20 m installation height.

Detection field for 2.20 m installation height

Size of detection field: 12 m x 12 m.

Details refer to an installation height of 2.20 m.

Installation to different heights may vary the rated (recommended)

detection range.
