Light Management Radio-control pushbutton and pilot lamp
Ref.-no.: ..1561.07FKO..
Operating Instructions
Radio-control pushbutton and pilot lamp
1. Function
and dimming of lamps.The starting brightness can be stored in the device
as memory brightness. The pushbutton with radio-control receiver is
plugged onto one of the following inserts:
Universal touch dimmer 1254 UDE
Standard touch dimmer 1225 SDE
Relay insert single-channel 1201 URE
Relay insert two-channel 1202 URE
Tronic switching insert 1254 TSE
LV triac switching insert 1244 NVSE
Touch control unit 1240 STE
Relay insert with potential-free contact 1201-1 URE After reception of a
data telegram from a programmed radio-control detector and
corresponding darkness, the radio-contol pushbutton is switched on for
about 1 minute with the preset memory brightness. The radio-contol
pushbutton can be programmed to identify up to 30 radio channels.
Lightscapes
The radio-contol pushbutton can be included in up to five lightscapes
which are activated with the corresponding radio-control transmitters (e.g.
hand-held transmitter ‘Komfort’) and stored. The desired lightscape key
must be programmed beforehand into the radio-contol pushbutton.
All-ON / All-OFF
The programming of a radio channel (e.g. hand-held transmitter
‘Komfort’) always includes the simultaneous and automatic storage of the
functions of the All-ON or All-OFF key.The All-ON or All- OFF key of a
radio-control transmitter switches the load connected to the switching
actuator on or off.
Light control
In combination with a programmed radio-control presence detector, the
radio-contol pushbutton can be used for lighting control functions. For
more information, refer to the operating instructions of the radio presence
detector.
Stand: Mai-07 325 276 53
Light Management Radio-control pushbutton and pilot lamp
Ref.-no.: ..1561.07FKO..
Important
The present instructions describe the functions of the radio-control
pushbutton without lighting control. More information on light control with
a presence detector is set out in the operating instructions for these
devices.
WARNING!
Caution: The installation and assembly of electrical equipment may
only be performed by a skilled electrician.
2. Fitting
The radio-control pushbutton can only be operated in conjunction with the
inserts listed under ‘Functions’. Connection and fitting are described in
the operating instructions of the insert.
Procedure
1. Install the selected insert (1) in a flush-mounting box (deep model
recommended), the connecting terminals of the insert pointing
downwards.
2. Plug the radio-control pushbutton (2) together with frame (3) onto
the insert while the mains voltage is disconnected.
c
d
e
L The distance from electrical appliances (e.g. microwave oven, hi-fi and
TV sets) must be at least 0.5 m.
L To prevent saturation of the radio receiver (actuator), the radiocontrol
pushbutton must be at least 1 m away from the nearest transmitter.
Learning a Radio Transmitter
During programming of a transmitter, the sensitivity of a radiocontrol
receiver is reduced to a range of approx. 5 m. The distance between the
radio-control pushbutton and the transmitter to be programmed should be
between 0.5 m and 5 m.
Procedure
1. Switch off the load connected to the radio-control pushbutton by a brief
depression (< 0,4 s) of any of the two pushbutton rockers.
2. Depress both rockers of the radio-control pushbutton at the same time
for abt. 4 seconds (fig. B: double-sided operation) to switch over to the
programming mode. The LED blinks for abt. 1 min (Fig. C). The radio
pushbutton is then in the programming mode.
2
