Universal automatic switch 180° 2.20 m
Light Management
Universal automatic switch 180° 2.20 m
Art.-No.: AS..1280-1..
Operating instructions
1 Safety instructions
Electrical equipment may only be installed and fitted by electrically skilled persons.
Failure to observe the instructions may cause damage to the device and result in fire and
other hazards.
Danger of electric shock. Always disconnect before carrying out work on the devise or
load. At the same time, take into account all circuit breakers that supply dangerous
voltage to the device or load.
Danger of electric shock. Device is not suitable for disconnection from supply voltage.
The load is not electrically isolated from the mains even when the device is switched off.
Do not press on the sensor window. Device can be damaged.
Disconnect before mounting the cover, malfunction possible.
Keep button cells out of reach of children! If button cells are swallowed, get medical help
immediately.
Risk of explosion! Do not throw batteries into fire.
Risk of explosion! Do not recharge batteries.
The device is not suitable for use as a burglar alarm or other alarm.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
Figure 1
(1) Insert
(2) Frame
(3) Motion detector
(4) LED red
(5) Button Off/Auto
(6) LED yellow
1/13
32576803
J:0082576803 03.05.2011
(7) Button On/Auto
(8) Lens
3 Function
Intended use
- Automatic switching of light, depending on heat motion and ambient brightness
- Operation with concealed insert for dimming, switching or extension insert, 3-wire
- Mounting indoors or outdoors on concealed insert
Product characteristics
- Adjustable functions with IR remote control
- Extension of the detection area in combination with the 3-wire extension insert
- Operation with IR remote control, buttons on the motion sensor, 2-wire extension or
installation button
- Teach function for adjustment of the brightness threshold in combination with IR remote
control
- Switch-on brightness permanently storable, with dimming insert
- Dimmable light with dim insert
- Dimming function, with dimming insert
- Short time operation, e.g. for controlling acoustic alarms, with switching insert
- Display LED
- Creep zone protection
- Presence simulation
- Night light function
- Run-on time limit
Automatic operation
The motion detector detects heat motions of people, animals and objects.
- The light is switched on if a person enters the detection area and the brightness is below
the set threshold.
The run-on time restarts with each detected motion.
- The light is switched off if no motion is detected in the detection area and the run-on time
has elapsed or the run-on time limit is reached.
To avoid any light swings caused by a cooling illuminant, the motion detector does not evaluate
any motion signals for a brief lockout time after switching off. The motion detector adjusts itself
to the ambient conditions to keep the time as short as possible.
The day/night switchover takes place after a delay of 30 seconds. Switching over is thus
prevented by briefly illuminating or shadowing to the day/night operation.
Short time operation
The motion detector is combined with a switching insert. Depending on motion and ambient
brightness a short pulse is triggered The pulse is cyclically repeated as long as motions are
detected.
Dimming phase
If the motion detector is combined with a dimming insert, the light is dimmed to minimum
brightness after the run-on time and then switched off The time from the start of dimming until
switching off is approx. 30 seconds. If a motion is detected during the dimming phase, the
motion detector switches the light to the saved switch-on brightness again.
Run-on time limit
The light is switched off after 90 minutes at the latest even if there is constant motion in the
detection area. The light is only switched on again if the brightness drops below the threshold
and motions are detected.
i Exception: After switching off the continuous On or On for 2 hours operating modes, the
lighting is switched off after 30 minutes at the latest.
2/13
32576803
J:0082576803 03.05.2011
Light Management
Universal automatic switch 180° 2.20 m
