92798 Cape Arago Hwy, Coos Bay, OR 541 97420 | -888-3517 | Toll Free 1- -800 867 6863 | kksound.com-

B A S S M A S T E R R O C K A B I L L Y S Y S T E M

The Bass Master Rockabilly is a double bass

transducer system designed specifically for

Rockabilly and Slap Bass. It combines two

transducers (the Bass Max and a fingerboard

pickup) to create an integrated double bass pickup

system that brings out the percussive and subtle

fingerboard sounds, as well as strong and warm

bass tones. Each Bass Master Rockabilly can be

fine-tuned via the separate bass and treble controls

within the dual channel preamp, providing an

infinite range of combinations for every player and

any style of play.

The Bass Master RB Upgrade System includes a

fingerboard pickup and preamp to upgrade from an

existing wing transducer (or other compatible

pickup). Please skip this section (Installation and

Setup: Wing Transducer) for the Upgrade System.

INSTALLATION AND SETUP

Wing Transducer

You can attach the wing transducer on either side of

the bridge. We recommend trying the low string (E

string) side first. If the slot is too narrow, DO NOT

FORCE THE PICKUP INTO THE SLOT! YOU WILL

BREAK THE PIEZO CERAMIC ELEMENT AND VOID

THE WARRANTY!

For the right fit, you may have to remove some

material from the lower part of the bridge. You’ll

achieve best results with a snug fit. If the slot is too

big, please insert some cardboard or veneer to

build it up.

Fingerboard Pickup

We suggest you place the fingerboard pickup near

the top of your fingerboard, on the reverse side. The

wire should travel behind your fingerboard, through

the bridge center "heart" (or the unused wing slot, if

the heart is too small).

Before you proceed to attaching the fingerboard

transducer, thread the transducer and wire through

the heart. A small piece of foam is supplied to

isolate the wire from bridge vibrations; wedge it into

the bridge “heart” and cut a small slit in it. If the

foam block is too large, trim it, but allow enough

excess material so it stays in place when

compressed, isolating the wire.

Pickup Installation

1. Cut a small piece from the double-sided tape,

wide enough for the pickup, and peel the off the

wax paper. Press the tape (on the brown

backing) in place behind the fingerboard. See

the next section, Placement of the Fingerboard

Pickup, for more detailed placement instructions.

2. Peel off the brown paper to leave the thin

adhesive layer on the wood. Press the pickup

onto the adhesive. (Note: Never remove the

pickup by pulling on the wire. Carefully use a

thin blade to pry it off.)

3. You may want to use masking tape to secure the

wire along the back of the fingerboard while

you’re settling into the final position for the

pickup.

4. Once you’re ready for permanent installation,

tack the wire to the remaining double-sided

tape, taking care that it is firmly adhered and

there is no possibility of it vibrating or buzzing

against the fingerboard.

Placement of the Fingerboard Pickup

The fingerboard transducer delivers a very different

tonal character and resonant depth depending on its

placement. Fingerboard backside construction

varies, but most are squared off at the neck joint,

and then scooped out as the fingerboard continues.

The sound changes character as you move from the

solid section of the fingerboard towards the thinner,

hollowed out areas. The pickup's edges are cut to

allow flat placement in any location as the

fingerboard profile changes.

You are strongly encouraged to experiment with

placement at various thickness near the top of the

fingerboard, in order to produce the type of tonal

response that you desire. Sufficient double-sided

tape is included so that you can move the

transducer to a different location, listen, and move it

again.

PREAMP SETUP & SOUND ADJUSTMENT

Snap off the preamp lid and insert a 9-volt battery.

You do not need to remove any screws, the lid

simply snaps off. Important: Please do not tamper

with the screw on the bottom of the preamp!

You will find that the wing transducer has a higher

output than the fingerboard transducer, so we

recommend that you begin by reducing the internal

gain trimpot for the wing transducer (Channel 2) to

minimum, and adjust the fingerboard transducer

(Channel 1) gain trimpot to maximum; this can be

fine tuned later.

We also suggest that you begin with your

amplification system set flat, and proceed by

adjusting the internal bass and treble controls one

channel at a time, with the external volume for the

other completely off. Since each channel has a +/

20dB range, minor adjustments have a great effect

on the sound. Make changes very gradually.

Once each channel has been individually adjusted

to your preference, they can be blended using the

external volume controls. You may wish to leave

the preamp open to continue making adjustments, to

fine tune each channel's bass, treble, and gain

controls, as well as your amplification system, to

achieve the response you prefer.

Channel 1: Wing Transducer

Channel 2: Fingerboard Transducer

Unplug the output cable at the preamp when not in

use to conserve battery power.

TECHNICAL DATA

Wing: 22 mm diameter, 4 mm thick

Fingerboard: 12.5 (two edges trimmed), 0.7 mm

thick

Preamp: 3" x 3.5" x 1 "

Input Impedance: I Mega Ohm (each channel)

Output Impedance: I0 Kilo Ohms

Input: Stereo ¼” Output: Mono ¼”

Cable: 6 foot, ¼” stereo plugs

Power: 9-volt battery (not inclu ded)
