KanexPro VGAEXTX1 Manual

KanexPro AV forlænger VGAEXTX1

Læs gratis den danske manual til KanexPro VGAEXTX1 (5 sider) i kategorien AV forlænger. Denne vejledning er vurderet som hjælpsom af 47 personer og har en gennemsnitlig bedømmelse på 4.8 stjerner ud af 24 anmeldelser. Har du et spørgsmål om KanexPro VGAEXTX1, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/5

Table of Contents

1) Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2) Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

3) Package Contents . . . . . . . . . . . . . . . . . . . . . . . . 2

4) Unit Layout & Description . . . . . . . . . . . . . . . . . . . 3

5) Connection andOperation . . . . . . . . . . . . . . . . . . . 4

6) ConnectionDiagram. . . . . . . . . . . . . . . . . . . . . . . 4

7) Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Notice

KanexPro™ reserves the right to make changes in the hardware, packaging and any accompanying docu-

mentation without prior written notice.

1x1 VGA Extender over CAT5/6 with Audio up to 1000ft. (300m)

e KanexPro VGA extender over a single CAT5e/6 cable is designed for routing high-resolution VGA

signals and stereo audio over remote distances up to 1,000ft. (300m). Each receiver set features a separate

gain and peaking rotary switch used in adjusting brightness and skew over long distances. e 15-pin

HD connectors are convenient and cost-eective for all input/ output connections supporting full band-

width compatible from VGA to WUXGA graphics card resolutions and HDTV’s to projectors. In addi-

tion, each output performs a separate buering to maintain signal integrity and reject noise interference.



Features:

• Extendhigh-resolutionVGAsignalwithaudiooverasingleCat5E/6cableupto1,000feet(300m)

• AdjustGAINandPEAKlevelstoadaptforvariablelengthsofUTPcableonthereceiver

• SupportsmaximumresolutionsuptoWUXGA(1920x1200@60Hz)

• Stereoaudiothrough3.5mmjack

• Dualoutputfortransmitter:VGAforlocaldisplayand1xCat5e/6

• EDIDCompliant

• Rackorunder-deskmountable

• 5VDCexternalpowersupplyincluded

Interface: Transmitter(TX)

Input: VGA x1/3.5mm Stereo x1

Output: Cat 5e/6 x1/VGA Output (Local) x1/3.5mm Stereo x1

Receiver(Rx)

Input: Cat 5e/6 x1

Output: VGA x1/3.5mm Stereo x1

Operating Frequency: VerticalFrequencyRange60/75/85Hz

Resolutions (PC):

 640x480 800x600 1024x768

 1280x720 1280x768 1280x960

 1280x1024 1600x900 1600x1200

 1920x1080 19200x1200

Power Supply: 5VDC@2A,5W

Environmental: Operating Temperature: 0°C to +70°C

 OperatingHumidity:10%to85%RH(nocondensation)

 StorageTemperature:-10°Cto+80°C

 StorageHumidity:5%to90%RH(nocondensation)

Regulatory Approvals Converter: FCC, CE, UL

Regulatory Approvals Power Supply: FCC, CE, UL

Dimensions: VGA Transmitter: 4”x2.6”x1” (102x66x25.5mm)

 Receiver:3.25”x1.4”x0.8”(82.6x35.6x20mm)

Weight: VGA Transmitter: 0.47lbs (215g)

Receiver:0.25lbs(115g)

Warranty: 1 Year limited

1)VGA UTP Extender Transmitter x1

2)VGAUTPExtenderReceiverx1

3)5V DC Power Supply x2

4) Mounting Kit x1
