Side 1/5

Table of Contents

1) Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2) Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

3) Package Contents . . . . . . . . . . . . . . . . . . . . . . . . 2

4) Unit Layout & Description . . . . . . . . . . . . . . . . . . . 3

5) Connection andOperation . . . . . . . . . . . . . . . . . . . 3

6) ConnectionDiagram. . . . . . . . . . . . . . . . . . . . . . . 4

7) Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Notice

KanexPro™ reserves the right to make changes in the hardware, packaging and any accompanying docu-

mentation without prior written notice.

1x2 VGA Extender over CAT5/6 with Audio up to 1,000ft. (300m)

e KanexPro 1x2 VGA extender over CAT5e/6 cable is designed for routing two high-resolution VGA

signals and stereo audio over remote distances up to 1,000ft. (300m). Each receiver set features a separate

gain and peaking rotary switch used in adjusting brightness and skew over long distances. e 15-pin

HD connectors are convenient and cost-eective for all input/ output connections supporting full band-

width compatible from VGA to WUXGA graphics card resolutions and HDTV’s to projectors. In addi-

tion, each output performs a separate buering to maintain signal integrity and reject noise interference.



Features:

• Extendtwoindependenthigh-resolutionVGAsignalwithaudiooverCat5e/6cableupto

1,000 feet (300m)

• AdjustGAINandPEAKlevelstoadaptforvariablelengthsofUTPcableonthereceiverside

• SupportsmaximumresolutionsuptoWUXGA(1920x1200@60Hz)

• Stereoaudiothrough3.5mmjack

• Dualoutputfortransmitter:VGAforlocaldisplayand2xCat5e/6

• EDIDCompliant

• Rackorunder-deskmountable

• 5VDCexternalpowersupplyincluded

Interface: Transmitter(TX)

Input: VGA x1/3.5mm Stereo x1

Output: Cat 5e/6 x2/VGA Output (Local) x1/3.5mm Stereo x1

Receiver(Rx)

Input: Cat 5e/6 x1

Output: VGA x1/3.5mm Stereo x1

Operating Frequency: VerticalFrequencyRange60/75/85Hz

Resolutions (PC):

 640x480 800x600 1024x768

 1280x720 1280x768 1280x960

 1280x1024 1600x900 1600x1200

 1920x1080 19200x1200

Power Supply: 5VDC@2A,5W

Environmental: Operating Temperature: 0°C to +70°C

 OperatingHumidity:10%to85%RH(nocondensation)

 StorageTemperature:-10°Cto+80°C

 StorageHumidity:5%to90%RH(nocondensation)

Regulatory Approvals Converter: FCC, CE, UL

Regulatory Approvals Power Supply: FCC, CE, UL

Dimensions: VGA Transmitter: 4”x4.6”x1” (102x102x25.5mm)

 Receiver:3.25”x1.4”x0.8”(82.6x35.6x20mm)

Weight: VGA Transmitter: 0.66lbs (300g)

Receiver:0.25lbs(115g)

Warranty: 1 Year limited

1)VGA UTP Extender Transmitter x1

2)VGAUTPExtenderReceiverx2

3)5V DC Power Supply x3

4) Mounting Kit x1
