Introduction
Key Digital’s 1080p AV over IP Solution, KD-IP1080Tx & KD-IP1080Rx, is an
infinitely expandable HDMI over IP system where video inputs and video outputs
may be scaled to fit any installation.
Key Features
› Custom System:
Add Tx and Rx extenders to an existing system to expand it up to
1024 Tx units and unlimited amount of Rx units
› Signal Extension:
Up to 400 ft. @ 1080p@60 (2.25Gbps) using any generic CAT6A cable
› POE:
Carry power to Tx and Rx units with a Power Over Ethernet enabled Smart
Managed Switch
› Web Control Interface:
Reduces installation time and provides basic video setup
› Full Buffer System
™
:
Manages TMDS re-clocking / signal re-generation, HDCP
authentication to source & display, and EDID Control handshake
› Resolution Support:
Supports up to 1080p@60 (2.25Gbps) and compatible
with DVI1.0/HDMI/HDCP1.x
› HDMI Pass-through:
Tx unit support HDMI Pass-through to receive video or extract audio
on the transmit side
› Audio Format:
Supports 2ch PCM at 44.1/48kHz
› A/V Bitrate:
Supports Stream Bitrate up to 15Mbps.
› TMDS re-clocking:
Support for long HDMI connectivity using Key Digital
®
HDMI cables
› Deep Color Support:
Up to 12 bits/color
› Licensing:
Fully licensed and compatible with all HDMI and HDCP technologies
› Control:
UDP and Web Browser Control through PC; Control System via Compass Control
MC gateway; Key Digital
®
App Ready.
› Major Control System Support:
Compass Control
®
, AMX
®
, Control4
®
, Crestron
®
, Extron,
Leviton
®
, RTI
®
, Savant, URC
®
, etc.
Accessories
› Power Supply: KD-PS5V2ASC, 5V/2A, Screw-in type
› Shelf-mount L brackets
› Operating Instructions
› Warranty Card
Table of Contents
Table of Contents .........................................................4
Introduction ..............................................................1
Recommended Equipment ..................................................2
Quick Setup Guide ........................................................2
Connections .............................................................4
KD-IP1080 Utility ..........................................................7
Web Interface ...........................................................10
Protocol: RS-232 and TCP/IP Commands......................................11
Specifications ...........................................................12
System Examples ........................................................14
Important Product Warnings & Safety Instructions: ...............................16
How to Contact Key Digital .................................................17
Warranty Information ......................................................17
Always follow the instructions provided in this Operating Manual.
Please check the Key Digital Website for the most up-to-date Manual.
