Side 1/4

LEARN TO SOLDER CLASS PACK

DEVELOP YOUR SOLDERING SKILLS WITH THIS

ESSENTIAL INFORMATION

BUILD INSTRUCIONS

HOW THE KIT WORKS

Version 1.0

Learn to Solder

www.kitronik.co.uk/2163

Build Instructions

Before you start, take a look at the Printed Circuit Board (PCB). The components go in the side with the writing on

and the solder goes on the side with the tracks and silver pads.

Start with the resistor R1. The text on the PCB shows where R1 should go. It doesn’t matter which

way around the resistor goes into the board. Solder the resistor, remembering to trim the legs

afterward.

Repeat with R2, R3 and R4.

PCB

Ref

Value

Colour Bands

,R2, R3, R4

Brown,

black

, b

rown

Check there is a component in each place indicated on the PCB.

Check all the solder joints are good.

Place the PCB on a PP3 battery.

Check the LED lights up.

PLACE THE LED

INSPECT YOUR

WORK

TEST YOUR WORK

Solder the LED. Ensure that the positive leg is inserted into the correct hole.

The positive leg is the longer one. Use the PCB markings to help.

PLACE RESISTORS

Produkt Specifikationer

Mærke:	Kitronik
Kategori:	Ikke kategoriseret
Model:	2163
Bredde:	21 mm
Dybde:	31 mm
Højde:	1.5 mm
Produktfarve:	Grøn
Produkttype:	Breadboard Printed Circuit Board (PCB) kit
Indgangsspænding:	9 V
Oprindelsesland:	Storbritannien
LED farve:	Rød
Inklusive modstande:	Ja
Breadboard:	Ja
