PV-CG20

1080p Car Charger DVR

(With Night Vision)

5. Format memory card

(1) Press and power on the DVR, the yellow LED will blink and

shut itself oﬀ .

(2) When the LED turns oﬀ, the format is completed.

V1.0

○

6. Download the video to PC

(5) : When you Charging the baery plug the DVR to the car

cigaree lighter socket and start the car, the internal baery

will be charged automacally (internal baery is only

used for saving the video clips when the engine is oﬀ).

(1)

Use memory card reader to retrieve video files.

(2) With the device powered on and memory card inserted,

plug the USB cable into , and plug the other end

into the PC.The device will be recognized by PC as an external

drive for user to retrieve the files.

* There are two ways to read the retrieve video files.

* Do not remove serial number stickers! Warranty is invalid

if the sticker is tampered!

3.3 Long Press and the device will be turned oﬀ

when the yellow LED is oﬀ.

○

* Battery-Powered,Car Engine is Off (Last Around 20 Minutes)

Short Press and the device will be turned on when the

yellow LED is on.

(1)

(2) : o start When youRecording Switch t the le to the Rec.

see the yellow/red LED is on, you know the Rec is on.

To turn oﬀ the Rec, switch to the right and the device

will enter the standby mode. Aer 3 minutes of inacvity

in standby mode, the device will be turned oﬀ automacally.

Long Press and the device will be turned oﬀ when the

yellow LED is oﬀ.

(3)

(1) : o start When youRecording Switch t the le to the Rec.

see the yellow/red LED is on, you know the Rec is on.

To turn oﬀ the Rec, switch to the right and the device

will enter the standby mode. Aer 3 minutes of inacvity

in standby mode, the device will be turned oﬀ automacally.

○

* Power On the DVR Via Car Cigarette Lighter Socket

(3) Power :oﬀ

3.1 If you turn oﬀ the engine, the DVR will also be turned

oﬀ automacally

3.2 Unplug the DVR from the car cigaree lighter socket, the

DVR will also be turned oﬀ automacally

* There are three ways to turn the power off:

(The video clip will also be saved simultaneously when the

power is turned off)

start the car.

(2) Plug the DVR directly to your car cigaree lighter socket and

LawMate, innovation never stops

2 1

1. Name and Parts 9

(6) Format Key

2. Package content

1 Car Charger DVR 2

User's manual

User manual 3

4GB

Lock

Adapter

Memory card

3. Date & Time setting (for Windows system)

(1) Power/Rec LED

(2) Camera lens

(3) Power Out:5V 1A

(4) USB Port

(5) Memory Card Slot

(7) Power On/Oﬀ Key

(8) IR On/Oﬀ Switch

(Le Oﬀ/Right On)

(9) IR LED

(1) From the desk top right-click to open Notepad, create a

text (.txt) ﬁle named seme

(2) On the ﬁrst line of the ﬁle, enter date and me informaon as

year.month.day hours.minutes.seconds. For example, suppose

the me is October 16th, 2018 15:00. Then, please enter

2018.10.16 15:00:00

Note: There should be a space le between date and hour;

me format should be the 24-hour format.

(3) Save the ﬁle to the root directory of the memory card.

Note: If the seng is completed, the seme.txt ﬁle will not be

visible when you connect the device to the computer

again.

Off

4. Operation

(1) The power keys/USB port and memory card slot are

designed on the side of the DVR that can be covered up by a

hard shell.

(2) You can decide whether to show or to hide the and

by rotang the hard shell(as above picture shows).

(3) You can adjust the camera lens direcon by panning, lng and

rotang the base of the DVR.

45 6

( :4) IR LED When you switch to on, the recording video color

will turn black and white.

To turn oﬀ the IR LED, just slid the LED switch to oﬀ.

7. Specification

Built-in image sensor Progressive 1/2.9 inch SONY CMOS

Sensor resolution 2000 x 1121

Sensor sensitivity 0.1 Lux @ F2.0 50IRE

Lens F/No. F2.0

Focal Length 4.6mm

Angle of View 78.2°

Algorithm H.264, JPEG

File Format MOV

Video recording mode Manual

Recoreding Capability 1920x1080

Frame rate Up to 30 fps

Memory type Micro SD Card ( Support SDHC max=32GB)

Data interface Mini USB 2.0

Date/Time Table YYYY/MM/DD, HH:MM:SS

Power Input DC 12-24V

Power Consuption 260-300mA IR OFF)(IR O（N+330mA)

Battery Input DC 3.7V / 130 mA polymers battery(XK032030)

Power Output 1.1A

Dimension 9.5x4x4 (cm)

Weight 57G

Misc.

Powe r

Physical

Video Spec.

Storage & I/O
