LawMate, innovation never stops

V1.0

PV-500NP Bundle

BU-18Neo + PV-500Neo Pro Package

1. BU-18Neo Names and Parts

a. BU-18Neo 2MP Camera

b. Button & Screw Kit

c. 3M Double Coated Tape

d. DIY Lens Cover Button

e. User’s Manual

3. PV-500Neo Pro Names and Parts

4. Package Content of PV-500Neo Pro

5. Install and Remove Battery

To ve remo the ba ery gen ly unloctt , t k

by wi ching s t LOCK tcswi h to the right side

and push battery in red arrow pointed

direction.

To install the battery, attach the battery to

the DVR, gently push the battery in red

arrow pointed direction. tLa ly don’st , t forge

to slide LOCK swith o t the o s left t en ure it is

locked properly.

4GB

6. Battery Charging

1. Connect the charger plug to the DC In Jack .

2. Plug the power cord of the charger to an AC wall outlet.

The charging starts automatically. The device can record

while charging.

● Solid green LED - the device is charging.

● Green LED goes off - the deviced is fully charged.

7. Connecting camera to DVR

To connect the camera, plug the

camera’s connector end into ,

insert fully in to the socket and

screw firmly in to place

※ Only to connect the camera

to DVR when system is turned off.

※ Both camera and memory card

need to be inserted to DVR

to turn the system on.

Battery Pack

DC 5V 2A Charger

Memory Card

USB Cable

Controller Cable

European Adapter

Head

Pouch

1. From the desktop right-click to open Notepad, create a text

file named settime.txt

2. On the first line of the file, enter date and time information as

year.month.day hours.minutes.seconds

For example, suppose the time is October 16, 2015 15:00.

2015.10.16 15:00:00Then enter

※

There should be a space left between day and hours,

and the time format should be of 24-hour clock.

3. Save the file to the root directory of the memory card.

Insert the memory card into the slot, and power on the device.

The date and time setting is now completed.

※

W te hen the da and time ing is omple ed sett c t . T he setti . tme tx

file should not be visible when you connect the device to

the computer again.

11. Date and time setting (for Windows system)

Knowing that all video files are stored in the memory card,

you can process the following steps to download videos.

1. Use a memory card reader to transfer files from the card to

the computer.

2. Or, connect the device to the computer with memory card

inserted. Turn on the device and it will work as a flash drive.

13. Download videos and photos from DVR

10. Format the memory card

9. Connect the DVR to the computer

14. Put on DIY lens cover button

Stick the tape on the button and screw it on the camera.

8. Connect the wired controller to the DVR

User's Manual

● Solid green LED on Controller - the controller is connected.

● Solid red LED on Controller - the device is recording.

1. Plug in the Controller Cable into the Control port .

2. Turn on the Controller, the device starts recording instantly.

When turned off, the recording stops and device powered off.

3. To turn on the device, slide the controller toggle downward

and hold for 3 seconds.

4. To turn off the device, slide the controller toggle downward

again and hold for 3 seconds.

With the DVR powered off, plug the USB Cable

into the USB port on DVR and the

other end to the computer.

1. The camera must be connectd to the DVR first.

Insert the memory card into as the icon shown on the device.

3. With device powered off, press and hold Rec button .

4. And then press Power button for 3 seconds until you

see the blinking red LED.

5. Lastly, release both buttons at the same time.

● Blinking Red LED + Solid Blue LED - the memory

card is being formatted.

● All lights go off - the formatting is completed.

Cau iont : To se make the memor cardy recognizable plea, be

sure orma he memor ard be ore t fo t t y c f us i . ing t for t fhe irst time

P se te t c , lea no that formatting on compu er is no ret ommended

f i s t o c ze or t t migh re ul int t f f the ailure or he compu er t re ogni

t .he card

12. Operation

1. Power on: Press for 3 seconds.

2. Recording: With device powered on, press to start or

stop recording.

3. Wi-Fi: With device powered on, press to turn on/off Wi-Fi.

4. Power off: With no ongoing recording, press for 3 seconds.

5. Reset: When the device functions abnormally, press .

6. Restore default Wi-Fi password: long press for 4 seconds.

7. Restore default setting : press for 10 seconds.

● Solid blue LED - power on

● Solid red LED - recording on

● Blinking orange LED - device searching for Wi-Fi connection

● Solid orange LED - device is connected to Wi-Fi

※

The device powers off itself when memory card is full.

1.Battery Pack

2.Battery Lock Switch

3.Controller Port

4. Charge - Green LED

5. Rec - Red LED

6. Wi-Fi - Orange LED

7. Power - Blue LED

8. Camera In Port

9. Power / Wi-Fi on &

off Button

10. Rec on/stop Button

11. Memory Card Slot

12. DC 5V in Jack

13. Reset Key

14. USB Port

15. Default Key

16. Touch Screen

Rec

Stop

1011

Camera Lens

Microphone

Locking Connector
