2
SAFETY and GENERAL INFORMATION
For your safety, read, understand, and follow the information provided with and on this folding creeper. The owner
and operator shall have an understanding of this product and safe operating procedures before attempting to use.
The owner and operator shall be aware that use of this product may require special skills and knowledge. Make
certain that the operator thoroughly understands the inherent dangers associated with the use and misuse of the
product. If any doubt exists as to the safe and proper use of this product, remove from service immediately.
Inspect before each use. Do not use if there are broken, bent, cracked or damaged parts (including labels).
Any folding creeper that appears damaged in any way, or operates abnormally shall be removed from service
immediately. If the folding creeper has been subjected to a shock load (a load dropped suddenly, unexpectedly
upon it), immediately discontinue use until it has been inspected by KRAFTWERK authorized service center. It
is recommended that an annual inspection be done by qualified personnel. Labels and Operator’s Manuals are
available from manufacturer.
PRODUCT DESCRIPTION
This device is designed to be folded in a ‘Z’ shape for use as a mechanics seat or unfolded for use as a mechanics
creeper. It is intended to be used to support and move, along a smooth and level surface, rated capacity loads
consisting of a single person weighing no more than *150 kg for the purpose of performing automotive maintenance
or service. This device is not intended, designed or engineered to be used for any other purpose.
* Rated Capacity: One (1) person weighing 150 kg. or less- includes person, tools, equipment, personal items.
SPECIFICATIONS
Do not use this device for any purpose other than that for which it is expressly intended.
Model Capacity Seat Size Creeper Size
3989 *150 kg 380 x 270 mm 1020 mm
Head Frame
Middle Frame
Rear Frame
Locking Pin
Figure 1
Head Cushion
Casters (6)
Fasteners (6)
COMPONENTS
Art. 3989-04
