Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
14-8 Faucets Installation Manual
WARNING: Plumbing connections should be made by qualified personnel
who will observe all applicable plumbing, sanitary and safety codes.
Installation Instructions
1. Turn off water supply at main source before proceeding with installation.
2. Remove the two 1/2” threaded nipples from the wall mount kit inside the box. (A)
3. Apply thread sealant tape or pipe joint compound to one side of each of the two threaded
nipples (you will apply to the other side after step #4 is completed).
4. Install the sealant-applied side of the threaded nipples into the two 1/2” female threaded
coupling anges and tighten properly. Note that the coupling anges have eccentric (B)
centers, meaning if the holes in the mounting surface are not exactly 8” on center, you can
slightly adjust the center distance.
5. From the front of the sink, insert the threaded nipples into the faucet holes in the sink. Make
sure the coupling anges are turned so the brass nipples are at the 12 o’clock position. This
is necessary to make sure the faucet is level.
6. Apply thread sealant tape or pipe joint compound to the other side of each of the two
7. From the back of the sink, place the black rubber washer, rosette, and lock nut from the
included mounting kit onto the threaded nipples and tighten with a wrench.
8. From the front of the sink, insert the rubber washers into the coupling anges . (D) (B)
9. Install the faucet body onto the coupling anges and tighten properly with a wrench. If (E)
the faucet does not t on the coupling anges, they will need to be rotated to t the faucet as
10. From the front of the sink, install the spout and tighten properly. (F)
11. From the back of the sink, install the water supply lines and tighten properly.
Note: For easy installation, we highly recommend using our E-Z Install Flexible Water Lines
(Model 21-443L). They include 1/2” NPT close elbows with swivel compression ttings on the
faucet side and 3/8” compression ttings on the water supply side. No thread sealant tape or
