Side 1/2
190
FLOOR SCRUBBER DRIERS
STANDARD EQUIPMENT
RIDE ON WITH SWEEPING AND SCRUBBING SYSTEM
Equipped with:
• Comfort Duotech it is a 3 in 1 machine: it sweeps, washes, and dries
• Ultra compact dimensions and great handling like a walk behind scrubber dryer, ideal for maintenance cleaning
• Complete right/left side brush (1060 mm working width)
• Great battery autonomy (up to 4h) thanks to the very low consumption of washing solution and tanks large capacity
number of stops and maximum use of the battery charge for the effective operation of the machine
• Ergonomic steering wheel of new conception with very small turning radius (860mm) which allows it to
rotate practically on itself both to the right and to the left
• Self-leveling central brush that allows perfect work even on uneven surfaces
• Forced air flows keep the solution always within the washing track patended
• Sweeping, up to 1060mm, thanks to large diameter and intelligent side brushes (Active) which retract
automatically both in the event of an impact and when cornering to allow the perfect collection of all the material.
• Up to 30 L solid debris tank
• Double floor drying process that allows the rear wheels to travel without slipping on wet surfaces.
• Green feature: very low water consumption
• Seat hight kit available
Comfort Duotech 65 CS Comfort Duotech 85 CS
code 0.061.0061 0.061.0062
power supply
24V 24V
cleaning width with right side brush 880 mm 880 mm
cleaning width with two side brushes 1060 mm 1060 mm
scrubbing width/squeegeewidth 650/670 mm 850/900 mm
turningradius 860 mm 860 mm
cleanwatertankcapacity 90 l/23,77 gal 90 l/23,77 gal
dirtywatertankcapacity 100 l/26,41 gal 100 l/26,41 gal
chemicaltankcapacity 3 l/0,79 gal 3 l/0,79 gal
solid wastecontainercapacity 23 l/6,07 gal 30 l/7,92 gal
main brush size Ø300 x L 650 mm Ø300 x L 850 mm
main brush speed 900 RPM/min 900 RPM/min
main brush pressure adjustable from the control panel adjustable from the control panel
dimensions/weight 140x78x130 cm/350 kg 140x105x130 cm/374 kg
Comfort Duotech
NEW
•
0.961.1187 Main brush
PPL/Tynex Duotech 65
•
0.961.1188 Main brush
PPL/Tynex Duotech 85
•
2 x 0.961.1189 PPL
side brush dx/sx
•
0.961.1191 Front
squeegee blade Duotech 65
•
0.961.1190 Rear
squeegee blade Duotech 65
•
0.961.1193 Front
squeegee blade Duotech 85
LINATEX®/AIROFLEX
0.961.1192 Rear squeegee
blade Duotech 85 LINATEX
191
FLOOR SCRUBBER DRIERS
OPTIONAL
RIDE ON WITH SWEEPING AND SCRUBBING SYSTEM
Control panel with easy and
intuitive controls featuring: hour
meter, battery charge level
indicator, empty tank light and
forward/reverse drive indicator.
Speed adjustment, horn, main
brush pressure adjustment,
automatic squeegee height
adjustment. Detergent dosing
system. Very small turning radius.
Sturdy and large central brush
d.300 self-levelling, with
adjustable pressure and anti-
clockwise rotation.
It allows collecting solid debris.
Stainless steel brush assembly.
Innovative AIR RECOVERY system
(patented), thanks to compressed
air channelled in front of the
brush: the lateral dispersion of the
detergent solution is avoided.
Sturdy steel squeegee system.
Perfect drying even in the tightest
corners.
• 4x0.107.0034-Battery
box Pb-Acid 6V 240Ah
C5+3.099.2071 metal box for
battery
• 0.108.0080 Battery charger
24V-30A 115-240V 50-60 Hz
suggested for 240Ah battery
models
• 1x0.107.0096 Battery box
Pb-Acid 24V 320Ah C5
• 1x0.107.0097 Battery box
Pb-Acid 24V 360Ah C5 (1)
• 0.108.0082 Battery charger
24V-60A 230V 50-60 Hz
suggested for 360-320Ah
battery models
• 1x0.107.0098-GEL Battery
24V 320Ah C5 GEL
• 0.108.0082 Battery charger
24V-60A 230V 50-60 Hz
suggested for 360-320Ah
battery models
• 0.961.1198 Automatic
battery 240Ah topping up set
• 0.961.1199 Automatic
battery 320/360Ah topping
up set
• On Board Battery Charger
24V 20-35AH (on request)
• Front working light system
(on request)
• 0.961.1204 Seat belt
• 0.961.1205 Side carter inox
• Complete red Roll Bar model
65 (on request)
• Complete red Roll Bar with
sheet metal shed model 65 (on
request)
• Complete red Roll Bar model
85 (on request)
• Complete red Roll Bar with
sheet metal shed model 85 (on
request)
• 0.961.1210 raised seat kit
